- Page 1 ™ Horizon Icemaker Installation Instructions ™ for Harmony Top-mount Applications H_C700AHT, H_C700WHT, H_D700AHT, H_D700WHT H_E700AHT, H_E700WHT (See model number confi gurator on page 2 for details.) Order parts online www.follettice.com self-contained Horizon top-mount icemakers fi t most countertop dispensers manufactured by Cornelius •...
- Page 2 Horizon Series Ice Machine Model Number Configurations Icemaker Voltage Series Condenser Application Configuration HC Horizon C 208-230/60/1 up to Air-cooled, self-contained V Vision™ S RIDE™ (self-contained only) Chewblet ® 750 lbs W Water-cooled, self-contained H Harmony™ (RIDE remote D 115/60/1 self-contained (340kg) HM Horizon ice delivery...
- Page 3 Read and complete the following 8 installation steps Unpack Site preparation Dispenser preparation Louvered docking assembly Ice transport tube External connection Internal connection Front cover HARMONY • TOP-MOUNT self-contained...
- Page 4 Unpack Carefully unpack and inspect the contents of your Follett icemaker. Unpack icemaker 7/16" 7/16" HARMONY • TOP-MOUNT self-contained...
-
Page 5: Site Preparation
Site preparation Prepare the installation site. Provide drainage, water supply and electrical power to within 6 feet (2m) of icemaker in accordance with local and national codes. Outdoor installation is not recommended and will void warranty. Installation site requirements H_D700A/W NEMA 5-15 H_C700A/W... -
Page 6: Dispenser Preparation
Dispenser preparation Prepare the dispenser. Note: The instructions below only apply to 22" & 30" wide dispensers. 44" wide dispenser instructions may be found with the top kit. Top preparation – ALL Top preparation – ALL ➊ ➊ ➌ ➊ ➋... - Page 7 Agitation adjust. – CORNELIUS Top preparation – LANCER ➊ ➋ ➋ Cornelius models ED, DB, DF, IDC Lancer models only and Flavor Fusion ➊ • Remove protective tape ➋ Adjust the agitation timer located on the • Apply gaskets Cornelius PC board to 1 second on, 1 hour off.
- Page 8 Agitation adjustments – LANCER FS SERIES Initialization Screen (Boot Up Only) Lancer FS-16 Ver. 0.200 ➊ Main Menu Sub-Catagory FS-16 Setup Brands Per Side Major/Minor V:1 L:2 R:1 FS-16 Setup Bonus Key Setup Config Bonus Key V:1 T:F M:S B:W FS-16 Setup Soda/Plain Water Cancel...
- Page 9 3.10 Dispenser diverter plate installation – CORNELIUS ED, DF and DB SERIES storage bin ➊ gate gate restrictor mounting plate plate ➋ ice diverter (supplied) gasket ice chute flange extends into storage bin through gate opening flat washer apply food-grade silicone sealant 10-32 nut to this surface...
- Page 10 3.11 Restrictor plate adjustment – CORNELIUS IDC and FLAVOR FUSION ➋ adjust restrictor plate to fully open position ➊ Cornelius IDC and Flavor Fusion These dispensers require the adjustment of the ice restrictor plate. ➊ • Loosen four nuts on ice chute assembly ➋...
- Page 11 Louvered docking assembly Install the louvered docking assembly. WARNING • Docking station must be secured in accordance with these instructions to ensure icemaker stability. • Ventilation openings in the louvered docking station should be clear of obstruction. Failure to do so could result in damage to equipment.
-
Page 12: Ice Transport Tube
Ice transport tube Install the ice transport tube. Hot Water 160 F (71 C) • Cut transport tube to 26” (66 cm) length • Install supplied ice transport tube insulation ➊ • Heat end of transport tube in cup of 160 F (71 C) hot water to soften and spread with pliers before making connection to ease assembly ➋... -
Page 13: External Connections
External connections Connect utilities to louvered docking assembly. Air-cooled icemakers only Water-cooled icemakers only ➋ ➍ ➋ ➌ ➊ ➊ • Remove access panel if necessary • Remove access panel if necessary ➊. ➊ • Install drain line • Install drain line The rigid drain line from the icemaker The rigid drain line from the icemaker must be vented and have at least 1/4"... -
Page 14: Internal Connections
Internal connections Connect louvered docking assembly to icemaker. CAUTION • Plug must be accessible after fi nal installation. Air-cooled icemakers – follow steps 7.1 through 7.4. Ice transport tube Potable water and drain lines ➋ ➊ • Slide icemaker into louvered docking ➊... - Page 15 Water-cooled icemakers – follow steps 7.5 through 7.10. Cooling lines Ice transport tube ➋ ➊ • Install icemaker cooling water lines to • Slide icemaker into louvered docking ➊ louvered docking assembly assembly • Insert ice transport tube into coupling and ➋...
- Page 16 7.10 Power cord Power cord • Remove twist tie • Position plate into opening and secure with supplied screw • Carefully pass plug thru opening and plug into wall outlet HARMONY • TOP-MOUNT self-contained...
-
Page 17: Front Cover
Front cover Install front cover to icemaker. Install cover • Slide icemaker cover over machine, ensuring that tabs on back of cover slip under louvers on back of louvered ➊, docking assembly then tighten two screws through cover ➋ • Place louvered front cover on machine NOTICE Icemaker MUST be sanitized prior to operation! Consult Operation and Service Manual provided with icemaker for sanitizing instructions. - Page 18 HARMONY • TOP-MOUNT self-contained...
- Page 19 HARMONY • TOP-MOUNT self-contained...
- Page 20 Horizon, RIDE, and Harmony are trademarks of Follett Corporation. Follett and Chewblet are registered trademarks of Follett Corporation, registered in the US. 801 Church Lane • Easton, PA 18040, USA 00978775R00 Toll free (877) 612-5086 • +1 (610) 252-7301 © Follett Corporation 7/12...
