Owner's Operation and Instruction Manual
MODELS: 2000(L)(LN), 2500(L)(LN)
US ENVIRONMENTAL PROTECTION AGENCY PHASE II CERTIFIED WOODSTOVE
CAUTION!
Please read this entire manual before you
install or use your new room heater.
to follow instructions may result in property
damage, bodily injury, or even death.
Improper Installation Could Void
Your Warranty!
THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE YOU
TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
S
C
U
S
SAFETY TESTED TO UL 1482 and ULC-S627
WASHINGTON STATE APPROVED
MOBILE HOME APPROVED (U.S. ONLY)
Failure
SAVE THESE INSTRUCTIONS
United States Stove Company
227 Industrial Park Road
P.O. Box 151
South Pittsburg, TN 37380
SAFETY NOTICE:
If this heater is not properly installed, a house
fire may result. For your safety, follow the in-
stallation instructions. Never use make-shift
compromises during the installation of this
heater. Contact local building or fire officials
about permits, restrictions and installation
requirements in your area.
TESTED &
PORTLAND,
LISTED BY
OREGON, USA
2000 Report #: 215-S-29-2
2500 Report #: 215-S-23-2
851710 rev C
Advertisement
Table of Contents
Related Manuals for Country Hearth 2000
Summary of Contents for Country Hearth 2000
- Page 1 TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE. United States Stove Company TESTED & PORTLAND, 227 Industrial Park Road LISTED BY OREGON, USA P.O. Box 151 2000 Report #: 215-S-29-2 South Pittsburg, TN 37380 2500 Report #: 215-S-23-2 851710 rev C...
- Page 2 Minimum Chimney Hieght : 12’ (3.7m) Maximum Log Length : 21” (533.5mm) Dimensions ” Overall : 2000 ” x 27” x 28 (521mm x 686mm x 727mm) Depth x Width x Height : ” 2500 25” x 27” x 28 (635mm x 686mm x 727mm) ”...
- Page 3 WARRANTY INFORMATION CARD Name__________________________________________ Telephone #: (_____)_____________ City____________________________________________ State_______ Zip_________________ Email Address __________________________________________________________________ Model # of Unit________________________________ Serial #___________________________ Fuel Type: qWood qOther _________________________ qCoal qPellet qGas Place of Purchase (Retailer)______________________________________________________ City____________________________________________ State_______ Zip_________________ If internet purchase, please list website address___________________________________ Date of Purchase _______________________________________________________________ Reason for Purchase: qAlternative Heat...
- Page 4 Ê É Fold Here Fold Here Fold Here PlACE STAMP HERE United States Stove Company P.O. Box 151 South Pittsburg, TN 37380 Ussc...
-
Page 5: Assembly
1. Locate the Room Air Deflector. Using the three(3) 1/2 Tek Screws provided, mount the deflector to the unit as shown in the diagram. Firebrick Configuration: 1. Replace the Firebrick as shown in the illustration below. Side view of flue collar 5/16-18 x 1-1/2 mount to heater top BOLT HEATER WELD Brick Configuration 2000 2500 Ussc... -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS Blower Assembly THE BLOWER ASSEMBLY MUST BE DISCONNECTED FROM THE SOURCE OF ELECTRICAL SUPPLY BEFORE ATTEMPTING THE INSTALLATION. THE BLOWER ASSEMBLY IS INTENDED FOR USE ONLY WITH A STOVE THAT IS MARKED TO INDICATE SUCH USE. DO NOT ROUTE THE SUPPLY CORD NEAR OR ACROSS HOT SURFACES! Step 1. -
Page 7: Installation
INSTALLATION SAFETY NOTICE • IF THIS STOVE IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. • CONSULT YOUR MUNICIPAL BUILDING DEPARTMENT OR FIRE OFFICIALS ABOUT PERMITS, RESTRICTIONS AND INSTALLATIONS REQUIREMENTS IN YOUR AREA. •... -
Page 8: Floor Protector
Total R = Rbrick + Rmineral = 0.8 + 0.431 = 1.231 Total R is greater than 1.2, the system is acceptable. The floor protector should exceed the stove as follows: Model Front Sides Rear 2000 25” 8” ¶6” (635mm) (203mm) (152mm) 2500 26”... -
Page 9: Clearances To Combustibles
CLEARANCES TO COMBUSTIBLES It is of utmost importance that the clearances to combustible materials be strictly adhered to during installation of the stove. Refer to the tables below : Single Wall Pipe (Double Wall Pipe) Model A 2000 20(14) 22(20) 22.5(16.5) 32(30) -
Page 10: Chimney Connector (Stove Pipe)
CHIMNEY CONNECTOR (STOVE PIPE) Your chimney connector and chimney must have the same diameter as the stove outlet (6”). If this is not the case, we recommend you contact your dealer in order to insure there will be no problem with the draft. - Page 11 CHIMNEY Your wood stove may be hooked up with a 6” factory built or masonry chimney. If you are using a fac- tory built chimney, it must comply with UL 103 or CSA-B365 standard; therefore it must be a Type HT (2100°F).
-
Page 12: Factory Built Chimney
FACTORY BUILT CHIMNEY : When a metal prefabricated chimney is used, the manufacturer’s installation instructions must be followed. You must also purchase (from the same manufacturer) and install the ceiling support package or wall pass-through and “T” section package, firestops (where needed), insulation shield, roof flashing, chimney cap, etc.
