[4] button
Adjustment Item
Display
Treble Center
"TRE F"
Frequency
**
Treble level
"Treble"
[5] button
Adjustment Item
Display
Balance
"Balance"
Fader
"Fader"
• According to the Bass Q Factor setting value, the frequencies that
can be set in Bass Center Frequency change as shown below.
Bass Q Factor
1.00/1.25/1.50
2.00
• When the bass extend is set to ON, low frequency response is
extended by 20%.
• ** Function of the KDC-X769
2nd section
[2] button
Adjustment Item
Display
Front High Pass Filter
"HPF F"
**
Rear High Pass Filter
"HPF R"
**
Front/Rear
"HPF"
High Pass Filter
[3] button
Adjustment Item
Display
Non-Fading
"LPF NF"
Low Pass Filter
Range
10.0/12.5/15.0/17.5 kHz
–8 — +8
Range
Left 15 — Right 15
Rear 15 — Front 15
Bass Center Frequency
60/70/80/100
60/70/80/150
Range
Through/100/125/170 Hz
Through/200 Hz
Through/100/125/170 Hz
Range
50/80/120/Through Hz
[4] button
Adjustment Item Display
Loudness
"LOUD"
[5] button
Adjustment Item Display
Non-Fading level
"NF Level"
• Loudness: Compensating for low and high tones during low
volume.
• When the Dual Zone System is ON, the setting for the High Pass
Filter is nullified.
• ** Function of the KDC-X769
3rd section
[2] button
Adjustment Item Display
Volume offset
"V-Offset"
Volume offset: Each source's volume can be set as a difference
from the basic volume.
— 13 —
Range
ON/OFF
Range
–15 — +15
Range
–8 — ±0
