Specifications - Jvc Kd-G547 Instruction Manual

Specifications

AUDIO AMPLIFIER SECTION
Maximum Power Output:
Continuous Power Output (RMS): Front and Rear:
Load Impedance:
Tone Control Range:
Frequency Response:
Signal-to-Noise Ratio:
Line-Out Level/Impedance:
Output Impedance:
Subwoofer-Out Level/Impedance:
Other Terminal:
TUNER SECTION
Frequency Range:
FM Tuner:
MW Tuner:
LW Tuner:
22
Front and Rear: 50 W per channel
19 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more
than 0.8% total harmonic distortion.
4 Ω (4 Ω to 8 Ω allowance)
Bass: ±12 dB at 60 Hz
Middle: ±12 dB at 1 kHz
Treble: ±12 dB at 7.5 kHz
40 Hz to 20 000 Hz
70 dB
2.5 V/20 kΩ load (full scale)
1 kΩ
2.5 V/20 kΩ load (full scale)
AUX (auxiliary) input jack
FM1/FM2: 87.5 MHz to 108.0 MHz
FM3: 65.00 MHz to 74.00 MHz
AM: (MW)
(LW)
Usable Sensitivity: 11.3 dBf (1.0 μV/75 Ω)
50 dB Quieting 16.3 dBf (1.8 μV/75 Ω)
Sensitivity:
Alternate Channel 65 dB
Selectivity (400
kHz):
Frequency 40 Hz to 15 000 Hz
Response:
Stereo Separation: 30 dB
Sensitivity/ 20 μV/35 dB
Selectivity:
Sensitivity: 50 μV
522 kHz to 1 620 kHz
144 kHz to 279 kHz
