details of our after-sales service and
contacts are available on the Internet at:
www.2helpU.com.
Battery ( g. L)
If you want to dispose of the
product yourself, the battery
must be removed as described
below and disposed of in
accordance with local
regulations.
Preferably discharge the battery by
operating the appliance until the
motor stops.
Press the release button (3) and
remove the dust collector (2).
Remove the filters (10 & 11) by
twisting them clockwise (fig. I).
Remove the seven screws holding
the body of the appliance together.
Pull the cover half away from the
location half.
prise the small cover from the filter
cleaning slider and remove the slider
securing screw.
lift out the full motor/fan/battery
assembly
Unplug the battery assembly from
the main assembly.
Place the battery in a suitable
packaging to ensure that the
terminals cannot be short-circuited.
Take the battery to your service
agent or to a local recycling station.
Once removed, the battery cannot be
refitted.

Instruction manual

This instruction manual is made from
100% recycled material and can be
recycled when it is of no further use to
you.
10
Technical data
Voltage
Battery
Weight
Voltage
Battery
Weight
Charger
Model
Input voltage
Output voltage
Output current
Approx. charging
time
Weight
Level of sound pressure, measured
according to EN60704-1: <70 dB(A)
Guarantee
Black & Decker is confident of the quality
of its products and offers an outstanding
guarantee. This guarantee statement is in
addition to and in no way prejudices your
statutory rights. The guarantee is valid
within the territories of the Member States
of the European Union and the European
Free Trade Area.
If a Black & Decker product becomes
defective due to faulty materials,
workmanship or lack of conformity, within
24 months from the date of purchase,
Black & Decker guarantees to replace
defective parts, repair products subjected
to fair wear and tear or replace such
products to make sure of the minimum
inconvenience to the customer unless:
The product has been used for trade,
professional or hire purposes.
The product has been subjected to
misuse or neglect.
The product has sustained damage
through foreign objects, substances
or accidents.
DV9605EN H3
Vdc 9.6
type NiMH
kg 1.3
DV1205EN H3
Vdc 12.0
type NiMH
kg 1.4
CHA010013B
DV1205EN
DV9605EN
Vac 100-240
Vdc 7-26
mA 400
h 5
kg 0.3
