Summary of Contents for Pure Water ULTIMA 888
- Page 1 ULTIMA ™ Installation Manual For models produced after September 1, 1998 © Copyright Pure Water 1995, Rev 4/07 All Rights Reserved.
-
Page 2: Table Of Contents
How the ULTIMA 888 Works ..................9 Ultima 888 Flowchart....................10 Preparing for Installation .................... 11 Installation of the Ultima 888 ..................14 Ready for Operation ....................15 Quick-Connect Fittings ....................16 Ladder Diagram .......................17 Trouble-Shooting Guide ....................18 © Copyright Pure Water 1995, Rev 4/07 All Rights Reserved. Page 2... -
Page 3: Important Safety Information
Wait at least 30 minutes after the distiller is off before draining the boiling chamber. • Important Notice: This distiller is designed to be used only with Pure Water accessories and replacement components. For the Record .. -
Page 4: Operating Parameters
The ULTIMA 888 is not designed for the outdoor environment nor exposure to direct sunlight. Suitable Location for Installation ..The location where the ULTIMA 888 is placed in an office or home is very important. Several factors must be considered: 1. -
Page 5: The Ultima 888
Getting to Know the Ultima 888 ..Front View Feed Water Tank Distilled Water Tank Back View Condensing Coil (inside) Figure 1 Fan (inside) Power Cord Receptacle Circuit Breaker Dispenser Plug Side View Distilled Water Outlet Feed Water Inlet... -
Page 6: The Cooler (Dispenser)
Otherwise damage can be caused to the cooling system. The coolers that are used with the Ultima 888 are a uniques design. Since there is no 5 gallon bottle with this system, we have chosen to use a cooler that has a reservoir with a 5 gallon capac- ity inside the cooler itself. - Page 7 Figure 12 Temperature Baffle Below the baffle Hot Temperature Inlet Figure 13 Room Temperature Inlet Figure 14 © Copyright Pure Water 1995, Rev 4/07 All Rights Reserved. Page 7...
-
Page 8: The Minisoft
2800 Grains Capacity (of the minisoft) DIVIDED BY Number of Grains per gallon in the water EQUALS Total number of gallons that the minisoft can soften before regeneration © Copyright Pure Water 1995, Rev 4/07 All Rights Reserved. Page 8... -
Page 9: How The Ultima 888 Works
How the ULTIMA 888 Works ..Raw water moves through a mini-softener (1), which removes hardness scale and minimizes maintenance of the boiling chamber, and is then stored in the Feed Water Tank (2). Water is drawn from the Feed Water Tank into the Level Control Housing attached to the Boiling Tank. -
Page 10: Ultima 888 Flowchart
ULTIMA 888 Flowchart ..Condensing Coil Raw Water Tank Level Control Boiling Housing Minisoft Tank Distilled WaterTank Dispenser Reservoir Tank Figure 17 © Copyright Pure Water 1995, Rev 4/07 All Rights Reserved. Page 10... -
Page 11: Preparing For Installation
Clean exterior or tanks and unit. Drain unit completely before transporting (top tank, lower tank, boiler, and cooler) See Page 6 Figure #7 if you have a 3 temperature dispenser. © Copyright Pure Water 1995, Rev 4/07 All Rights Reserved. Page 11... - Page 12 12. Clean the baffle with a solution of bleach and water. Rinse Figure 19 thoroughly with purified water and reinstall in the dispenser. © Copyright Pure Water 1995, Rev 4/07 All Rights Reserved. Page 12...
- Page 13 2. Connect the speedfit elbow with a piece of 1/4” tubing to a distilled water source. 3. Run Distilled water through the filter until there is a clear stream of water. © Copyright Pure Water 1995, Rev 4/07 All Rights Reserved. Page 13...
-
Page 14: Installation Of The Ultima 888
Note: In this section, we give instructions for using a saddle tapping valve to connect a waterline to the Ultima 888 distiller. The saddle-tapping valve and tubing is not included with the Ultima 888, but can be ordered from Pure Water under part #9514 for the saddle-tapping valve, and 9526-25R for 1/4"... -
Page 15: Ready For Operation
Note: The Hot Water Tank Drain Valve is located at the lower right on the rear of the unit. If you need to drain the hot water tank entirely, simply open the valve by turning it counterclockwise. After the water has drained, be sure to close the valve. © Copyright Pure Water 1995, Rev 4/07 All Rights Reserved. Page 15... -
Page 16: Quick-Connect Fittings
Push the tubing firmly into the connector. b. With your fingers or suitable tool, push and hold the collet against the fitting body. c. Pull the tubing free. Figure 23C © Copyright Pure Water 1995, Rev 4/07 All Rights Reserved. Page 16... -
Page 17: Ladder Diagram
HE AT ING E LE ME NT S WIT C H F AN MOT OR ON/OF F S WIT C H ON LIG HT HOUR ME T E R © Copyright Pure Water 1995, Rev 4/07 All Rights Reserved. Page 17... -
Page 18: Trouble-Shooting Guide
Cut damaged area from tube or replace the tube. Worn or damaged o-ring. Replace o-ring. Water has bad taste Post filter is depleted. Replace post filter. Drain distilled or smell. water completely. © Copyright Pure Water 1995, Rev 4/07 All Rights Reserved. Page 18... - Page 19 Adjust or replace float valve. leaks from dispenser. obstructed or faulty valve. Dispenser not cooling. Coolant gone from compressor. Remove and deliver to dispenser manufacturer's approved service center. © Copyright Pure Water 1995, Rev 4/07 All Rights Reserved. Page 19...
- Page 20 © Copyright Pure Water 1995, Rev 4/07 All Rights Reserved.
