Summary of Contents for ACM Security System Advanced MPEG-4 DVR
- Page 1 Stand Alone Digital Video Recorder Advanced MPEG-4 DVR 4, 8, 16 Channel Models User’s Manual V2.04-2249 This document contains preliminary information and subject to change without notice.
-
Page 2: Fcc Compliance Statement
FCC Compliance Statement Notice to Users This equipment has been tested and found to comply with the limits for a Class A digital device. Pursuant to Part 15 of the FCC Rules, these limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: Important Safeguards
This product has multiple-rated voltages (110V and 220V). See installation instructions before connecting to the power supply. This product uses a Lithium battery. To avoid a risk of explosion, do not replace the battery on the main board by anything other than a Lithium battery. Dispose of used batteries according to the manufacturer’s instructions. - Page 4 Do not attempt to service this equipment yourself. Refer all servicing to qualified service personnel. 13. Damage Requiring Service Unplug this equipment from the wall outlet and refer servicing to qualified service personnel under the following conditions: When the power-supply cord or the plug has been damaged If liquid is spilled or objects have fallen into the equipment If the equipment has been exposed to rain or water If the equipment does not operate normally by following the operating instructions, adjust only those controls that are...
- Page 5 THE LIST OF CONFIGURATION A Type 16CH B Type DVR Set 16CH CD (Software/Manual) Remote Controller Manual Screws HDD Brackets (Optional)
-
Page 6: Operation Precautions
Operation Precautions Power Off Do not turn DVR off, or plug off the power adapter while DVR is in operation (record/playback). Otherwise, it may cause permanent damage to the equipment. Please click ( ) SETUP>SYSTEM>Shutdown sequentially and then remove the power after DVR is shutdown completely. -
Page 7: Table Of Contents
Table of Contents SERVER New User Product Features ---------------------------------------- 8 4.2.4 Unpacking ------------------------------------------------------ 8 System Log ---------------------------------------------------- 26 4.2.5 Service ---------------------------------------------------------- 8 Exit --------------------------------------------------------------- 26 4.2.6 System Connection Diagram------------------------------ 8 Shutdown ----------------------------------------------------- 27 DISPLAY ----------------------------------------------------- 27 4.3.1 Installation - OSD ------------------------------------------------------------- 27 ------------------------------------------------ 10 4.3.2 Main Monitor -------------------------------------------------- 28... - Page 8 5.1.8 Emergency Recording------------------------------------- 46 Others --------------------------------------------------------- 69 Search --------------------------------------------------------- 46 10.1 Viewer ----------------------------------------------------------- 69 5.2.1 Date/Time Search ------------------------------------------ 46 10.2 E Map ------------------------------------------------------ -69 5.2.2 Calendar Search -------------------------------------------- 46 10.3 Watermark Check System----------------------------- 70 5.2.3 Event Search ------------------------------------------------- 47 10.4 Estimator ------------------------------------------------ -- 71 Playback------------------------------------------------------- 48 One-touch Playback---------------------------------------- 49...
-
Page 9: Product Features
Product Features Unpacking This equipment is an electronic appliance, so it should be handled with special care. After unpacking, please check if all the following items are included. DVR Main body Power Supply Adapter (DC 12V, 5A) or Power Supply Cable Remote Control With 2 AAA batteries Installation CD (CMS Software &... - Page 10 B Type - 4 / 8 / 16 Channel Series DVR...
-
Page 11: Installation
2. Installation Hard disk and CD-RW Installation 2.1.1 SATA Port Main substrate of this DVR has three SATA ports: they are indicated as SATA 1,2 and SATA 3.( A Type ) Main substrate of this DVR has four SATA ports: they are indicated as SATA 1,2 and SATA 3,4.( B Type ) Up to two SATA devices (hard disk, CD-RW, and DVD-RW) are connected in Serial to the SATA ports, but the devices must be connected correct SATA port. -
Page 12: Connector Wiring
CAUTION For installation/addition/replacement/Removal of HDD (CD-RW, DVD-RW), make sure that DVR is turned off. Otherwise, it may cause permanent damage to the HDD (CD-RW, DVD-RW). Installation/Addition/Moving/Replacement: You should start ‘HDD initialization’ including formatting. Otherwise, DVR won’t recognize the hard disk and may begin to function abnormally. Please follow the below procedure for ‘HDD initialization’. ①... -
Page 13: Usb Connections
2.2.7 USB Connections There are three identical USB (2.0) ports in front and in rear. You may connect an external hard disk, an external USB CD/DVD-RW, and a USB memory stick to the USB ports. When you use an external hard disk, please assure the connecting cable is not longer than 1.8m (6 ft). 2.2.8 RS-232 Connection This connector is for manufacturer only. -
Page 14: Input Device And Screen Icons
3. Input Device and Screen Icons Keys and LEDs KEYS PTZ KEY Operating mode Setup mode • Up/Down/Left/Right on ▲, ▼, ◄, ► • Control Pan/Tilt rotation of up/down/left/right in PTZ mode screen cursor control 1 ~ 8 • Camera select keys Type: 4/8/16 channel DVR) 1 ~ 10 •... -
Page 15: Camera Select Keys For 4/8 Channel Dvr
Camera Select Keys for 16 channel DVR A Type model Below shows how to select camera channel for 4 channel DVR – Select Camera No. 1~4: press key and use 1~4 key Below shows how to select camera channel for 8 channel DVR –... -
Page 16: Using A Remote Controller
B Type model 4 Channel DVR 8 Channel DVR 16 Channel DVR Using a Remote Controller Usage of a remote controller is same as the front panel keys. Follow the procedure below when you use the remote controller for multi DVRs. ①... -
Page 17: Screen Icons
Screen Icons Icon Description Icon Description Continuous recording mode In Audio recording Event recording mode CMS access indication/ No. of accesses (Alarm In/Motion) (up to 4) In recording In channel sequencing PTZ registration / PTZ mode Lock Remote Controller Setup in HDD Overwrite mode Setup in HDD No Overwrite mode Setup in HDD No Overwrite mode (HDD Full) -
Page 18: Setup
4. Setup Login/Logout At the default setting of DVR, you have to input the password to enter the set up menu. Please press SETUP key to enter the setup menu and the following screen will appear. In order to use all functions and privileges, login is as ID: admin. Default Password is “1111”. -
Page 19: System
(NOTE) Press AUDIO/ESC in the setup screen, start operation alike CANCLE (ESC). It will not operate live or playback mode but only in the setup menu. SYSTEM 4.2.1 Information Please click ( ) SYSTEM>Information, and the following screen will appear. Status Site Description Decide name of DVR. -
Page 20: Version
Import: Copy the Menu setup stored in USB memory stick into DVR. Please plug in the memory stick and then click ( ) Import. Export: Store the Menu setup of DVR in USB memory stick. Please plug in the memory stick and then click ( ) Export. When you are working on Default, Import, Export, a message box will ask the progress and click the confirmation icon, then a message box will show whether its success or failure. -
Page 21: Admin
Overwrite Setting Click( ) Overwrite Setting button and the following screen will appear. You may set for beeping or notifying messages that notify the used percentage of disk. Check Disk Overwrite and you may activate the overwrite function. This function makes restart the recording from the beginning when the HDD is full. The previous recorded data will be erased from the first one. -
Page 22: Date/Time
Date/Time Date This menu will allow you to adjust the settings. Please follow the procedure below for time adjustment. ① Click ( ) items (Y, M, D) you want to change. A designated item will be highlighted in a box (Y: Year, M: Month, and D: Day). -
Page 23: Ntp
Time Format Set time indication format. Please click ( ) Time Format frame to select a format you like from the list. When you complete Date/Time input, please click ( ) NTP and the following screen will appear. This menu is for accurate setting of time of day clock in DVR. You may check only one of Run as Server and Use NTP. - Page 24 Four rows will show as follows: – 1: SATA 1 Port – 2: SATA 2 Port – 3: SATA 3 Port – 4: SATA 4 Port( B type model only ) Format You must format when you: – install new HDD –...
-
Page 25: Account
4.2.3 Account Please click ( ) SYSTEM>Account, and the following screen will appear. New Group Please click ( ) New Group, and the following screen will appear. Click ( ) keyboard icon on the right-hand side of Group Name frame. Then, the virtual keyboard will show. Please click ( ) desired characters (up to 20) on the virtual keyboard. -
Page 26: New User
New User Please click ( ) New User, and the following screen will appear. Click ( ) the keyboard icon on the right-hand side of User Name frame, and the virtual keyboard will appear. Click desired characteristics (up to 20 characteristics) on the virtual keyboard. Input Password and Confirm. -
Page 27: System Log
key if you wish to erase password on keyboard. 4.2.4 System Log Please click ( ) SYSTEM>System Log, and the following screen will appear. System Log System Log displays diverse events. – Setup (Menu) Enter/Exit – Playback Mode Enter/Exit – Network Access Enter/Exit –... -
Page 28: Shutdown
4.2.6 Shutdown Shutdown is a function to help you safely turn off DVR. Please use the proper shut down procedure to avoid damaging to our DVR system. Do not remove the power during shut down. CAUTION DO NOT TURN DVR OFF WITHOUT USING THE PROPER SHUT DOWN PROCEDURE. OTHERWISE, IT MAY CAUSE DAMAGE TO YOUR DVR. -
Page 29: Main Monitor
object or substance has when you can see through it. Transparency range is between 0 and 100, with a larger number representing can see through it. (default 0) While pressing (+) or (-) button, a target value increases or decreases by 10 units. 4.3.2 Main Monitor Please click ( ) DISPLAY>Main Monitor, and the following screen will appear. -
Page 30: Spot Monitor Control On Display Mode
This menu will allow adjust interval of channel sequencing of Spot monitor. Click ( ) Spot Select to choose Spot monitor to be set up. Check (check box next to the camera you want to include in sequencing. Any camera with unchecked check box will be excluded from channel sequencing. -
Page 31: Lan
Network Type Please click ( ) Network Type. Every time you click ( ), it changes to Static (fixed IP) and DHCP (floating IP). In Static, user must manually set the static IP address for use. – Set IP Address, Subnet Mask and Gateway. Please ask your network administrator for more details. –... -
Page 32: Port
‘Floating IP system’, although being predominantly used over Internet, is very inconvenient for users because its address varies every time you access. The best alternative is DDNS (Dynamic Domain Naming System) which uses name (domain name) instead of IP address (numbers). DDNS automatically recognizes ever changing, floating IP addresses, so it will allow easy Internet access. -
Page 33: Notification
Network video transmission speed and quality can be configured by pressing “Frames” and “Quality” buttons as follows. Frames : 1, 7, 15, 30 frames for NTSC(1, 6, 12, 25 frames for PAL) Quality : Std. 1, Std. 2, Std. 3, Std. 4 (standard), High 1, High 2, High 3, Super 1, Super 2, Super 3 The Port Number Setup menu will allow you to set Administrator and Port Number for Video/Audio and Web Port. -
Page 34: Audio
Give titles to cameras and choose PTZ protocols. Click ( ) the keyboard icon on the right-hand side of each frame on Title column, and the virtual keyboard will appear. Then, register titles of cameras. If you check a check box on No column, a video of the corresponding camera is recorded and displayed on the monitor. However, if you do not check the checkbox, both recording and monitor display stop. -
Page 35: Alarm In
The Audio menu will allow you to choose whether to record Audio. When you check a check box on No column, corresponding audio and video are recorded. However, if you do not check the check box, recording stops. Choose ‘OK’ to confirm the setting. 4.4.4 Alarm In Please click ( ) DEVICES>Alarm In, and the following screen will appear. -
Page 36: Record
Click ( ) the keyboard icon on the right-hand side of each frame on Title column, and the virtual keyboard will appear. Then, please register the title of Alarm output. When you check a check box on No column, a corresponding Alarm output starts operating. However, if you do not check the check box, the operation stops. -
Page 37: Event
8 Channel DVR 240(200) 120(100) 60(50) 16 Channel DVR 480(400) 240(200) 120(100) Click ( ) each frame on Quality column to select recording quality of a corresponding camera. You may select one of Super, High, and Std. Choose ‘OK’ to confirm the setting. Event Please click ( ) Event, and the following screen will appear. -
Page 38: Schedule
Click ( ) each frame on Resolution column to select recording resolution of a corresponding camera. You may select one of 704x480, 704x240, and 352x240. Click ( ) each frame on Frames column to select recording rate of a corresponding camera. Recording rate varies by camera. -
Page 39: Pre Alarm
Motion / Alarm In / PreAlarm Choose ‘OK’ to confirm the setting. (NOTE) Holiday (H) registration is done with a separate menu. 4.5.3 Pre Alarm Please ( ) RECORD>Pre Alarm, and the following will appear. Pre Alarm is effectively used when you selected recording mode by Alarm or Motion. The Pre Alarm will allow you to check, during playback, the previously recorded video before the record start time. -
Page 40: Holiday
SETUP menu descriptions. – Camera: select camera for setup. – Sensitivity: select sensitivity (Low, Normal, and High) – Reverse Vert: activate the entire column at the cursor’s position. – Reverse Horz: activate the entire row at the cursor’s position. – Select All: active all blocks. -
Page 41: Alarm In
The LINK menu will allow you to set recording modes of all kinds of alarms (Sensor, Motion Event, Video loss, System Event, etc.), alarm output, e-mail notification and the like. 4.6.1 Alarm In Please click ( ) LINK>Alarm In, and the following screen will appear. Select cameras for recording while the motion sensor is in operation, and alarm outputs, and set up E-mail addresses for notification. -
Page 42: Video Loss
Click( )By Duration box to set up the recording duration and prevent recording caused by event. The duration time can be controlled by previous setting mode: RECORD>Settings>Event Choose ‘OK’ to confirm the setting. 4.6.3 Video Loss Please click ( ) LINK>Video Loss, and the following screen will appear. Select cameras for recording while the motion sensor is in operation, and alarm outputs, and set up E-mail addresses for notification. -
Page 43: Popup Link
④ Select E-mail addresses for notification when emergency occurs. Please check a check box under Link Notification. More than two E-mail addresses can be set. Choose ‘OK’ to confirm the setting. 4.6.5 Popup Link Please click ( ) LINK>Popup Link, and the following screen will appear. When Motion or Alarm-In is detected, you can select a popup or beep sound for warning, or have a particular channel of interest to pop-up on Spot Screen. -
Page 44: Operation Instruction
5. Operation Instructions Viewing 5.1.1 First Image Power on DVR, and the following live video will appear, while viewing and recording at the same time. The screen will display date/time and icons below. Icon Description Continuous recording mode Event recording mode (Alarm In/Motion) In recording PTZ registration/PTZ mode In Audio recording... -
Page 45: Digital Zoom
(NOTE) Using a mouse: Double click to view the corresponding camera image in full view format, and click one more time to back to Split Screen. – Split Screen: Please press DISPLAY key, and the available split screens (or multi-window view formats) will display alternately (i.e., 2x2, 3x3, and 4x4). -
Page 46: System Log
Run Group Tour 1~9 Run Pattern 1~9 To use a mouse in Pan/Tile mode, please move the cursor to the lower portion near the center of the screen. To use front button in Pan/Tilt mode, please push setup button. A key pad control will show as follows: To save current camera number, select Preset No and button click. -
Page 47: Emergency Recording
Once the Key Lock function is on, you cannot use any key. If you want to use a key, please enter the correct password to release the key lock function. If Password is not required, simply press ENTER key. 5.1.8 Emergency Recording When you press EMERGENCY key, recording starts right away regardless of preset recording mode. -
Page 48: Event Search
Dates and Time with recorded data available will be high-lighted. Follow the procedure below to search video by calendar. ① Select Year and Month by using the arrow buttons in the calendar. – : search subsequent ‘Year’ – : search previous ‘Year’ –... -
Page 49: Playback
① Designate Event Search start time. ② Designate Event Search end time. ③ Select camera (video) to search data. ④ Check a check box (Motion / Alarm In / Emergency) Check box. ⑤ Click on Search Index button to recorded search event data. Playback This involves searching recorded video to playback the wanted video of a specific date and time in search mode. -
Page 50: One-Touch Playback
(NOTE) Using a mouse: Double click to view the corresponding camera image in full view format and click one more time to back to Split Screen. Move the cursor of the mouse, and the keypad control will appear at the bottom near the center of the screen. Every time you press the PLAY/PAUSE key during playback mode, it is changed to ‘1X PLAY’... -
Page 51: Color Control And Position
② Click ( ) Format frame to select EXE or JPEG. Choose EXE for storing moving images; and JPEG for still images. ③ Click ( ) the keyboard display on the right-hand side of FROM frame to set the storage start time. ④... -
Page 52: Alarm Out Control
If you click (Default), proper number of Color Control or HSTART/VSTART will appear automatically. Please choose ‘OK’ to confirm the setting. Click ( ) ▲, ▼ direction buttons on the right-hand side of Brightness/Contrast/Saturation to set adjust color of the screen (i.e. -
Page 53: Cms
Stand Alone Digital Video Recorder (Central Monitoring Station) User’s Manual V2.04-2249 This document contains preliminary information and subject to change without notice. -
Page 54: Program Installation
6. PROGRAM INSTALLATIONS SYSTEM RECOMMENDATIONS The followings are our recommendations for system configurations/specifications used with CMS. Processor: Intel Pentium(R) (at 2.8GHz or better) Memory: 1.00GB or more Video: 128 MB AGP VGA card, 1024 x 768 Resolution, 32-bit Color, DirectX® 8.1 version or later HDD Space: 500 MB of space Monitor: SVGA or XGA, 1024 x 768 Resolution, 32-bit Color OS: Windows®... -
Page 55: Login
⑦ When the following screen appears, click Install. ⑧ When the following screen appears, click Finish to complete the installation. LOGIN After you install CMS software, CMS icon below appears on your desktop. Please double click on the icon to execute the program. -
Page 56: Function And Instructions
7. FUNCTIONS AND OPERATING INSTRUCTIONS Below lists are functions of the program. ICON ICON NAME WATCH MODE SEARCH MODE REMARKS System Log DVR System Log PTZ Control DVR PTZ Control System Health Check DVR System Health Check DVR Data Playback DVR Data Playback CMS(PC) Data Playback CMS(PC) Data Playback... -
Page 57: Watch Mode
WATCH MODE LOGIN SCREEN When you login CMS, the following screen will appear. This screen is of Watch mode. Because it is not connected to DVR, images do not show. Please do Local Setting first before connecting to DVR. LOCAL SETTING Please click LOCAL SETTING button of Toolbar and the following screen will appear. -
Page 58: Remote Site
Manager/User: allow user to authority. Save Option: allow user to select Drive(C, D) and folder to save data. Choose ‘OK’ to confirm the setting. 8.2.2 Remote Site This menu is for Network setup. Make CMS IP address and Port coincide with DVR. Remote Site Connection Setup: Site Name: input DVR site name to be displayed on the right-hand side of DVR icon. -
Page 59: Live Video
Please choose ‘OK’ to confirm the setting. LIVE VIDEO 8.3.1 Network Connection As the setup is completed, you are now ready to connect CMS to DVR over Network. Please click in REMOTE DVR on the screen. It will turn to yellow, while being activated. Please click REMOTE CONNECT button. -
Page 60: Watch Mode
Date/Time LED Site Tree (DVR and Channels) Color Control Bar Instant Record Button System Log Alarm Out Channels Audio Channels Two way Audio Video Display Screen Network Connect/Disconnect Button/Exit CMS 8.3.2 Watch mode The first image (or the initial image) shows the available maximum split screen format, but you can choose a watch mode you want. -
Page 61: Multi Screen
E Map: load and close E Map image program. Mouse Double Click: If you double click the mouse on a split screen, it will turn to full screen mode. Double click the mouse to back to the previous watch mode. 8.3.3 Multi Screen CMS supports multi remote site connections simultaneously. -
Page 62: Alarm Out
8.3.7 Alarm Out This is for operating Alarm Out of a selected DVR from a remote distance. Click a channel number, and Alarm Out of the corresponding channel will operate. If you see an intruder, use this function to turn on a siren in an area where the DVR is installed. 8.3.8 One Touch Recording Click on INSTANT RECORD button to save video of every channel in HDD of Local System (PC with CMS... -
Page 63: Health Check
Zoom Out/ In Focus Near / Far Iris Close / Open Preset Control / Back to Preset ③ Preset Control button The completed Preset Click on Preset Control button, and the following screen will appear. Please input Title and Preset Number. When you completed input, please choose ‘OK’... -
Page 64: Camera Connection And Operating Status
Motion recording status Alarm In connection and operating status Alarm Out connection and operating status Version Recording start/end date and time 8.5.1 Camera Connections and Operating Status Camera is in normal operation. Camera is not in use. Camera is not connected or Video Loss. Camera is Covert status. - Page 65 Click on REMOTE SETTING button in Watch mode, and the following SETUP menu same as DVR’s will appear on CMS screen. The setup procedure is same as that of DVR. When the setup is completed, do not click Exit button on the SETUP screen, but click OK or Cancel button on the Remote Setup screen.
-
Page 66: Search Mode
9. SEARCH MODE SEARCH SCREEN This menu is for playing back from recorded data. Click on REMOTE SEARCH button in Watch mode, and the following Screen mode screen will appear. Search mode provides three search functions. One is for searching DVR video by clicking REMOTE SEARCH button, and another is for searching video stored in CMS (HDD of PC) by clicking LOCAL REARCH button and the other is for searching event recorded data stored in DVR by clicking REMOTE EVENT button. -
Page 67: Local Search
Search previous ‘Year’ Search subsequent ‘Year’ Search previous ‘Month’ Search subsequent ‘Month’ ② ① ④ ③ ⑤ Fast Forward/Backward & Playback (Click to increase the speed by x1, x2, x4, x8, x16, x32, x64 and Extreme) Select Camera to be played back Time LED (24 Hour) Data Bar (Recorded data) Time Select Bar... -
Page 68: Playback
① Designate Event Search start time. ② Designate Event Search end time. ③ Select camera (video) to search data. ④ Check a check box (Motion/Alarm In/Emergency) Check box ⑤ Click on Search Index button to recorded search event data. PLAYBACK 9.5.1 Playback Control Button Select time and click Fast Forward/Backward button. -
Page 69: Save
9.5.3 Save This is for saving still image(s) in Bitmap or JPEG file. Click IMAGE SAVE button, and the following screen will appear. Input the name of the file to save, and execute Save. CAUTION If images are not saved properly, click UNDO button and save again. 9.5.4 Archive This is to back up the DVR’s moving image data to AVI file in PC(CMS). - Page 70 ② Designate Archive end time. ③ Designate file name. ④ Select camera (video) to save. ⑤ Click on Start button to begin Archive.
-
Page 71: 10. Others
10. Others 10.1 Viewer The Format of archive file is .exe(executable file). Please double click on the icon to execute the program. PLAY • Playback mode: 1X PLAY • Playback mode: PAUSE PAUSE • Frame-by-frame backward still image BACKWARD playback •... -
Page 72: Watermark Check System
Please click on the icon to load the image file. To move the icon just drag and drop. You can also rotate the icon. Please click on the icon and input the name of the E Map file to save, and execute. Please click on the icon to exit program. -
Page 73: Estimator
To open the check .exe or .jpg file just click Load File button. To click the check button, you will get following message; Result: Verification OK ! Corrupted or Modified 10.4 Estimator When you set up CMS program, the application, Estimator will set up additionally. The operation screen is as follows. -
Page 74: Keyboard Controller
Keyboard Controller Advanced Keyboard Controller User’s Manual V2.04-2249 This document contains preliminary information and subject to change without notice. -
Page 75: Ptz/Dvr Control Mode
11.1 Keyboard Controller CP1200A(hereinafter CP) has two modes. (Direct Connect mode, Relay mode) “Mouse” button Short click: Control mode of keyboard is changed. (Direct connection, Relay) Long click: Mouse functions are performed through USB port. Direct Connect Mode: PTZ camera is connected directly to CP. Relay Mode: DVR is first connected to CP, and PTZ camera is connected to DVR. -
Page 76: Q/A
In DVR control mode, all buttons operate according to texts written underneath. The operations are the same as Front buttons of DVR as follows: DISPLAY: changes channel split screens in sequence of 1>4>9>16>1. SEQ: turns on/off Sequence function. SPOT: changes the channel of a screen connected to the Spot monitor. ARCHIVE: pops up Archive window. -
Page 77: When Tx Blinks Continually On The Led Window
Current Default password is 0000. [MAIN SETUP] PASSWORD [****] [MAIN SETUP] 1. VER : *.** [MAIN SETUP] 2. DATE: 20070519 [ TITLE SET ] << Ctring >> [MAIN SETUP] 3. TITLE SET Sets up identical with the connected camera ID (not DVR number) [MAIN SETUP] 4. -
Page 78: Keyboard System Connection
11.5 Keyboard System Connections Max. 255 devices DVR # 2 PTZ # 4 PTZ # 3 DVR # 1 PTZ # 2 PTZ # 1 11.6 CONSIDERATIONS SYSTEM ID: DVR identification number. It can be set up on SYSTEM ID of SETUP>SYSTEM>Information page. Camera ID: Camera identification number defined by the Camera jumper setting It should be set up with the identical ID on SETUP>DEVICES>Cam/PTZ page. -
Page 79: System Configuration Diagram
11.8 System Configuration Diagram 11.8.1 Configuration Diagram I ….. ….. Max 16 camera Multi port Multi port Tx +/- Tx +/- Max 16 DVR … … Rx +/- Rx +/- Multi port Trx +/-++/-... -
Page 80: Configuration Diagram Ⅳ
11.8.2 Configuration Diagram II Max 3 Camera Tx +/- Tx +/- 11.8.3 Configuration Diagram III – Single System Configuration (Camera 1, Keyboard 1, DVR 1) DVR PTZ Port RS485 RS485 Tx+ Tx- Rx+ Tx1+ Tx1- Tx2+ Tx2- Tx3+ Tx3- Trx+ Trx-... - Page 81 11.8.4 Configuration Diagram IV – Multiple System Configuration Max 16 camera RS485 RS485 RS485 RS485 … … Multi port Max 16 DVR … … DVR PTZ Port DVR PTZ Port Multi port 11.8.5 Configuration Diagram V – Single System Configuration (connected directly to PTZ) DVR PTZ Port RS485...
-
Page 82: Serial Ln
Serial In (POS / ATM) Serial In (POS / ATM) User’s Manual V2.04-2249 This document contains preliminary information and subject to change without notice. - Page 83 12.1 Set- up Methods Please click( ) “System>Devices>Serial-In”, then you will see the display below. (Note) The above menu is only available on the DVR model with Serial-In function. Port rs232 is used to connect serial devices. Press( ) the “Port Setting” button in order to set up the port. Default values are Baud rate 2400 bps, Data Bit 5 bit, Stop Bit 1 bit, Parity None.
-
Page 84: Search
After you release(□) the checked item on “Auto” item and click the button of “Pattern” item, you can analyze the serial information in more detail as following screen; Each item explains below: Start Pattern : Indicates the beginning of the new data when new designated data are received from a serial device. End Pattern : Indicates the end of the data when designated data are received from a serial device.
