Calypso CB-1000 Manual

Programmable ir 8 button panel
Hide thumbs

Advertisement

Table of Contents

Manual: CB-1000 Rev 1.0
IR 8
PROGRAMMABLE
BUTTON PANEL
Main Office
944 O Keefe Road
Hudson, WI 54016
(Tel) 715-381-9646
(Fax) 715-381-9647
Manual: CB-1000 Rev 1.0
www.calypsocontrol.com
sales@calypsocontrol.com
support@calypsocontrol.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CB-1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Calypso CB-1000

  • Page 1 Manual: CB-1000 Rev 1.0 IR 8 PROGRAMMABLE BUTTON PANEL Main Office 944 O Keefe Road Hudson, WI 54016 (Tel) 715-381-9646 (Fax) 715-381-9647 Manual: CB-1000 Rev 1.0 www.calypsocontrol.com sales@calypsocontrol.com support@calypsocontrol.com...

  • Page 2: Chapter 1: Introduction To The Cb-1000

    By utilizing rubberized tactile push buttons the CB-1000 combines a familiar and flexible interface with reliability, ease of use, and style. The CB-1000 functions as a stand-alone button panel with a single IR output, which can be split to control multiple devices, or can be used in combination with Calypso Pro I/O and ION controllers to add serial, relay or network control for any number of devices.
  • Page 3 Plug the 12vdc power supply into the TB-CW. NOTE: When launched the configuration utility tries to auto-connect to the CB-1000, and if successful the CB-1000 will beep. You can also manually select the com port from the pull down selection box.
  • Page 4 OS X. After installation: Insert the CD into your computers drive. Create a folder on you computer and place the CB-1000 config Zip file into this folder. Un-Zip the Zip file and copy all of the files into the newly created folder.
  • Page 5 When connected, the CB Config interface shown below will appear. Com Port Selection Initial Setup Set Passwords IR Edit Window IR Learning and Button Assignments Status Window Page 5...

  • Page 6: Chapter 2: Cb-1000 Setup

    Once serial communication is established, CB-1000 Software is used to configure and program the CB-1000. The upper section of CB Config sets CB-1000 options and facilities IR learning, while the lower section of the interface shows current CB-1000 settings and acknowledges each serial command as it is executed.
  • Page 7 The CB-1000 includes a timer feature, which allows it to automatically send out IR commands based on a set time. For instance, you can set the CB-1000 to always turn a projector off at 10:00PM. Each button can have a separate timed event attached to it. In addition, there are 4 extra virtual buttons available for timed events only.

  • Page 8: Chapter 3: Ir Learning

    When operating in Universal IR mode, IR codes must be learned by the CB-1000 and assigned to each button. Keeping in mind that the CB-1000 is capable of assigning up to 4 unique IR codes to each button (e.g., called actions ), one must (a) learn the IR code, typically using the original manufacturer s IR remote control, and then (b) assign that code to a combination of button and action numbers (e.g., button = 1, action = 1).
  • Page 9 Point the remote control through the IR Learner slot and press the desired button one time. When the code is successfully learned, the CB-1000 will beep one time, the red LED will turn off and the IR string will appear in the Edit Window of the CB-1000 Software Utility.
  • Page 10 3.1.3 Assign IR to Buttons / Actions. Use pulldown C and pulldown D to select a combination of button and action numbers. Clicking the Save IR button will save the codes and set up for the selected button. Button order for configuration 3.1.4 IR Repeat.

  • Page 11: Chapter 4: Changing Buttons

    Chapter 4: Changing Buttons 4.1 Installing and Replacing Buttons Unscrew the Decora faceplate Remove the white plastic button holder by squeezing the 2 white tabs on the back of the circuit board. Once the white plastic holder has been removed the buttons will now be loose and can be replaced.

  • Page 12: Chapter 5: Installation And Wiring

    Chapter 5: Installation and Wiring The CB-1000 fits into a standard, single-gang wall-mount electrical box (not provided) and comes with a 12v external power supply and two Phoenix-style, removable wiring blocks: one for power and one for IR. Also included is a terminal block that helps to simplify wiring.

  • Page 13: Chapter 6: Using Cirt (Calypso Ir Triggers) Codes

    IR then these codes should be used, they all already in memory. The important step to remember is that the CIRT code from the CB-1000 needs to match the CIRT code in the Calypso device. Below is the set of CIRT codes that can be pre-set to the CB-1000 buttons.
  • Page 14 This warranty is applicable to product sold or distributed to customer by an authorized Calypso Control Systems Dealer, OEM, Value Added Reseller or sold directly to the end user by Calypso Control Systems, LLC. This warranty becomes effective from the moment the end user completes purchase and receives product.
  • Page 15 (2) misuse, theft, vandalism, fire, water, or other peril; (3) alterations of or additions to the System or any element thereof performed by personnel not certified by Calypso Control Systems to perform such alterations and additions or (4) the Customer s failure to operate the product in conformance with Calypso Control Systems published operating parameters, including environmental specifications.
