- Page 1 40DQV INSTALLATION MANUAL...
- Page 2 40DQV DUCT MOUNTABLE CEILING UNIT...
-
Page 3: Table Of Contents
ENGLISH ENGLISH DUCT MOUNTABLE CEILING UNIT (cooling and heat pump heating mode only) Contents Page Safety precautions ..........Warnings: avoid . -
Page 4: Safety Precautions
• This manual describes the installation of (89/336 EEC). the indoor unit of a split system consisting It must be installed by qualified of two Carrier units. Coupling different personnel only. units equipped with different control The appliance must be installed in an... -
Page 5: Warnings: Avoid
ENGLISH • All materials used in the manufacture system and contains a refrigerant that and packing of this appliance are must be disposed of according to specific recyclable. procedures. At the end of the useful life of • Dispose of packing material and used the appliance, take it to a proper recycling batteries from the (optional) remote control or disposal centre or return it to the dealer... - Page 6 ... in cooling mode, direct entry of sunlight ... routing the condensate drain pipe to a into the room: draw the curtains. residential drain or sewer network without a ... installing in places near heat sources, siphon. The height of the siphon in relation which could damage the unit.
-
Page 7: Weights And Dimensions
ENGLISH Weights and dimensions Coil Condensate collection tray Drainage connection Ø AP Fresh air intake Electrical panel Unit frame Air filter Liquid Ø AM Gas Ø AN GB-5... -
Page 8: Technical Data
Table I: Weights and geometric dimensions 40DQV ØAM ØAN ØAP 1/4” 1/2” 3/8” 5/8” 110 - 130 3/8” 5/8” 40DQV 050 - 080 110 - 130 1325 1371 1265 1179 NB: All measurements are expressed in mm. Technical data Table II: Nominal data... -
Page 9: Items Supplied With The Unit
Operating limit voltage min 198 V - max 264 V 40DQV110 40DQV130 Table IV: Outdoor static pressure 40DQV Nominal static pressure (Pa) Maximum pressure (Pa) Refer to the “Installation” section” Items supplied with the unit Table V: Items supplied with the unit... -
Page 10: Installation
Do the following: POSITION • Select a position capable of supporting the weight of the operating unit. • The 40DQV unit is designed ducted • Leave sufficient space around the unit for installation in suspended ceilings. maintenance and free circulation of air •... - Page 11 ENGLISH INSTALLING THE UNIT CONDENSATE DRAINAGE Important: the unit must be correctly Important: do not lift the unit by means levelled. of the condensate drain pipe. Insert the 4 M8 threaded tie rods into the All units are equipped with a condensate ceiling.
- Page 12 During the operation, take the following precautions to avoid damaging parts of the AIR OUTLET CONFIGURATION unit: The Carrier 40DQV unit is predisposed for remove the filter. either side or front air outlet. Installation with front outlet The standard factory configuration is with...
- Page 13 ENGLISH The unit can be predisposed for ducting Each of the following configurations can be with circular conduits. executed with the items supplied with the unit. 40DQV050, 080 40DQV110, 130 GB-11...
- Page 14 Do not adopt configurations other than those indicated above, as this may compromise the correct operation of the unit. In particular, avoid operating the unit with just one aperture. After removing the cut-outs, make certain that the insulation covers all the parts in steel sheet.
- Page 15 ENGLISH The area of the panel which can be used After removal, make certain that the for fixing the 8” circular flanges (not insulation covers the steel sheet around supplied) is as shown in the figure. Avoid the cut area. drilling or fastening screws in the shaded area of the figure so as not to damage the unit’s tray.
- Page 16 FRESH AIR INTAKE • As far as possible, avoid bends near the unit’s air outlet. If this is not possible, the There is a cut-out on the side of the unit, radius of curvature must be as wide as which can be used as a fresh air intake. It possible;...
-
Page 17: Unit Specification Graphs
ENGLISH Unit specification graphs Warning! The unit is configured for three minimum counter-pressure at the outlet speeds, LO-ME-HI. On installations in must reach the value shown in the which it is necessary to set the speed S.HI diagrams below (see (see “electrical connections”... - Page 18 GB-16...
-
Page 19: Coolant Connections
ENGLISH Coolant connections Warning! Connect the indoor and outdoor units using copper pipes with flared connections (not supplied). For the lines, use insulated, unwelded, degreased and de-oxidised copper pipe, (Cu DHP type to ISO 1337), suitable for operating pressures of at least 4200 kPa and for a burst pressure of at least 20700 kPa. - Page 20 The flare must be free from burrs and imperfections. The walls of the flare must be of identical length. Adjustable wrench or torque wrench Indoor side Outdoor side Torque Pipe diameter setting inches 6.35 1/4” Lubricate the end of the pipe and the 9.52 3/8”...
-
Page 21: Electrical Connections
Communication (high voltage) Minimum section for conductors of connection cable between indoor and outdoor unit (mm Model 40DQV 050, 080, 110, 130 3 x 0.75 H03VVF Important: The earth conductor of the indoor unit - outdoor unit connection cable must be crimped to a ring terminal lug in tin-plated annealed copper predisposed for M4 screws. -
Page 22: Controls
Selecting S.HI speed the unit is configured for three speeds, LO- ME-HI. To select S.HI speed, proceed as follows: • open the cover of the unit’s electrical panel; • close the unit’s electrical panel again. • move the faston “A” connector (with the brown wire“B”), to faston “C”... -
Page 23: Error Code
ENGLISH Error code (with CRC control) For units with INFRARED REMOTE KIT, 2. The red LED indicates error codes refer to the manual supplied with the Kit above 10 as follows: itself for error codes. LED off for 4 seconds, followed by a The indoor unit is designed to intercept any number of flashes equal to the first digit system malfunction, shutting it down... -
Page 24: Operating Test
Operating test Operating test using CRC Note: After 30 minutes, if no other button is pressed, the CRC automatically exits from • Carry out the operating test once the the operating test menu and reverts to system has been installed and tested for normal operation. -
Page 25: Accessories
ENGLISH 2. The internal fan must work on low • At the end of testing, press the button speed. on the remote control to exit the test 3. The system must not signal any function. malfunction. Note: After 30 minutes, if no other button is If any of the above conditions is lacking, pressed, the remote control automatically check the system is installed properly. - Page 26 Filter removal with air intake from the rear Motor The motor is life-time lubricated. No lubrication is therefore necessary. DISPOSAL At the end of their useful life, the appliance and all its components must be disposed of at a suitably authorised differentiated disposal centre.
- Page 27 The manufacturer reserves the right to change any product specifications without notice.
- Page 28 L010126H96-0405 Via R. Sanzio, 9 - 20058 Villasanta (MI) Italy - Tel 039/3636.1...
