- Page 1 Sliding Gate Operator User's Manual ENVIRO 6 http://www.phoenixgaragedoors.com.au/...
-
Page 2: Table Of Contents
ENVIRO 6 SLIDING GATE OPERATOR OUTLINE 1. Products introduction 2. Important safety precautions 3. Main technical parameters 4. Mechanical Installation 5. Adjustment 6. Wire Connecting 7. Turning and operation 8. Programming Process 9. Maintenance 10. Trouble Shooting 11. Packing list... -
Page 3: Products Introduction
Gate Move speed 4. Mechanical Installation The ENVIRO 6 will handle gate weighting up to 500kg and up to 12m if the proper installation procedures have been followed. The ENVIRO 6 gate operator operates by forcing a drive rack by a drive gear. The entire configuration... - Page 4 Gate operator Fig.1 Gate preparation Be sure the gate is properly installed and slides smoothly before installing the ENVIRO 6 sliding gate operator. The gate must be plumb, level, and move freely. Conduit In order to protect the cable, use PVC conduit for low voltage power cable and control wires. Conduit must be preset into the concrete when it is poured.
- Page 5 ENVIRO 6 SLIDING GATE OPERATOR Gate operator Gear Spring washer Plain washer Groundsill Input power Fig.2 Operator base (see Fig.3) After the concrete has hardened, mount the gate operator base to the concrete pad. Verify that the base is properly leveled.
-
Page 6: Adjustment
ENVIRO 6 SLIDING GATE OPERATOR When the rack has been installed, to ensure it meshes correctly with the gear. The space between rack and gear is about 0.5mm. Fig.4 5. Adjustment Spring limit switch To ensure safety, it is recommended to install limit switches at both ends of the gate to prevent the gate from sliding out of the rails. -
Page 7: Wire Connecting
ENVIRO 6 SLIDING GATE OPERATOR M6X10 Fig.6 Manual operation In case of power failure use key unlock the lock and pull down the release bar about 90 degree to open or close gate manually, use the release key as follow: l... - Page 8 ENVIRO 6 SLIDING GATE OPERATOR Fig.8 Wiring notes of control board a. Power Input(X1):E (Earth),L (Live),N (Neutral). ENVIRO 6: AC220V b. Caution light: connect caution light wire toD1 and D2(terminal X3) ENVIRO 6: AC220V c. Output power supply: 24VDC, COM (COM), I.R. (N.C Infrared) If the infrared beam is interrupted during closing, the gate will reverse and open immediately.
-
Page 9: Turning And Operation
ENVIRO 6 SLIDING GATE OPERATOR Fig.9 infrared Schematic diagram d. Three-button switch / single-button switch (keypad): The ENVIRO 6 is equipped with interfaces for three-button switch and single-button switch (keypad). To install the keypad attach one lead of your keypad to ‘CLS’ of terminal X4 and the other to the ‘COM’. - Page 10 ENVIRO 6 SLIDING GATE OPERATOR buttons or three buttons together, but you need repeat the program/learn process if you want to use more than one button. Button 1 Button 2 Button 3 Button 4 Fig.12 Remote transmitter Adding extra remote controls (Learn): Remove the cover, press the learn button AN1 (Fig.8), then 2 (Fig.8) will be on and turn off, then press the remote control button which you want to use,...
-
Page 11: Programming Process
ENVIRO 6 SLIDING GATE OPERATOR 8. Porgramming Process Table of the DIP-switch Position DIP-switch Function SET Three-button switch Single-button switch(the CLS and COM), OPN and COM is “open door” function also. When the 2 and 3 all ON, the Controller haven’t Auto-close function. -
Page 12: Maintenance
ENVIRO 6 SLIDING GATE OPERATOR positions or during opening. l Open priority: The gate will return to open if press ‘OPEN’ button of external button switch during closing. l Limit switch: The switch is used to accurately stop the gate in the opened and closed positions. -
Page 13: Warranty Registration
ENVIRO 6 SLIDING GATE OPERATOR Item Quantity ENVIRO 6 sliding gate operator Transmitter Release key User s manual 12 . Warranty Registration For your operator warranty registration, please visit our website www.phoenixgaragedoors.com.au/warranty-registration/...
