Summary of Contents for Body Champ BF 620
- Page 1 BF 620 Easy Body Rider * This item is for consumer use only and it is not meant for commercial use. OWNER’S MANUA L...
- Page 2 This page intentionally left blank...
-
Page 3: General Information
21717 Ferrero Parkway, Walnut, CA 91789 - 1 x Philips (”Crosshead”) Screw Driver Telephone: (888) 266 - 6789 Weight Limit Fax: (909) 598 - 6707 Email: info@bodyflexsports.com Your product is suitable for users weighing: 250 pounds or less. BF 620 Page 1... -
Page 4: Hardware List
#22. Nylon Nut (M8) [4 Pieces] [3 Pieces] Pre-assembled Knob #17. Knob Bolt (M12x65 mm) #18. Knob Bolt (M8x15 mm) [1 Piece] [1 Piece] Tool #38. Tool 1 (S6) #39. Tool 2 (S13-14-15) [1 Piece] [1 Piece] BF 620 Page 2... -
Page 5: Parts Listing
Washer (M8, OD16, T1.5) Bolt (M8x15 mm) Main Sensor Wire (Lower) Knob Bolt (M12x65 mm) Bushing (38x90 mm) Knob Bolt (M8x15 mm) Tool 1 (S6) Washer (M8,OD19 mm) Tool 2 (S13-14-15) Rectangular End Cap (36x16 mm) BF 620 Page 3... -
Page 6: Exploded Diagram
Please continue to the next page to begin the assembly process and use this page only as a reference guide for parts and hardware. BF 620 Page 4... -
Page 7: Assembly Instructions
Hardware & Tool Required Tool Bolt Washer #14. Arc Washer (M8) #13. Carriage Bolt (M8x60 mm) #15. Nut (M8) [4 Pieces] [4 Pieces] [4 Pieces] #39. Tool 2 (S13-14-15) [1 Piece] BF 620 Page 5... - Page 8 [4 Pieces] [1 Piece] on the Center Post (#06). Secure the L Shape Bolt Tool (#34) through a Washer (#35) and directly into the bracket on the Center Post (#06). #38. Tool 1 (S6) [1 Piece] BF 620 Page 6...
- Page 9 Do not remove the Seat (#08) for any reason after you have installed it. Exercising on this unit without the Seat (#08) can result in SERIOUS INJURY. Ensure the seat is locked in place by tightening the two knobs prior to use. BF 620 Page 7...
- Page 10 Connect the Main Sensor Wire (Middle) (33a) to the Wire on the Monitor (31) and then slide the Monitor (31) onto the computer bracket located on the Center Post (#06) until it clicks into place. STEP3: BF 620 Page 8...
- Page 11 Forward pedaling emphasizes your quadricep muscles (front thighs), while backward pedaling emphasizes your hamstrings (back thighs). The Easy Body Rider allows you to make your workout less fatiguing, more fun, and more effective with forward and backward movement functionality. BF 620 Page 9...
-
Page 12: Safety And Maintenance
Friction Belt rubs against. This will prevent the friction mechanism from working properly. Please contact our CUSTOMER SUPPORT if you have questions regarding the cleaning of your bike. BF 620 Page 10... -
Page 13: Computer Operation
Calories: Displays the amount of calories burned. Scan: Automatically alternates between the different functions. (Time, Distance, Calories) 4.BATTERY: This monitor requires one (or two) "AA" Battery(ies). You can replace the battery(ies) from the back of the monitor unit.. BF 620 Page 11... -
Page 14: Warm-Up Instructions
1. Lie on your back and raise your right leg as you clasp both hands under the back of the knee. Keep your left leg straight. 2. Gently pull your right leg toward your trunk without raising your upper body. Switch leg positions and repeat. BF 620 Page 12... - Page 15 Switch leg positions Reverse arm positions and and repeat. repeat. BF 620 Page 13...
-
Page 16: Proof Of Purchase
Proof of purchase Model Number BF 620 version: 12-07-2011 BF 620...
