ALSA 400 MCDSe User Manual

USER MANUAL FOR EXCELL 400 MCDSe
A
N.P.
G
H
HF LEAKAGE
CUT
COAG
PED
1

Control devices, Connection sockets, and Symbols

Alarm Led for the neutral plate safety circuit (red)
A
Area for memories setting (storage key
B
Area of selection and regulation
C
Area of selection and regulation
D
Area of selection and regulation
E
Area of selection and regulation
F
Alarm Led for the HF leakage currents control circuit
G
Setting of the standard twin foot-switch pedal functioning PED
H
Led for bipolar output
I
Socket PED for the twin foot-switch pedal connection (standard for the activation of the monopolar or bipolar currents)
1
Socket PED-BIP
2
Socket MAN-1
3
Socket MAN-2
4
Socket PED-1
5
Socket PED-2
6
Socket N.P
7
Socket BIP for the connection of the bipolar electrodes cable
8
b1 At disposal
b2 General mains switch (green-0/I)
b3 Socket for the mains cable with fuse block
b4 Plug for the equipotential connection
b5 Rotating regulator of the start delay of the bipolar Micro Auto coagulation (from instantaneous mode to 5sec max.)
b6 Rotating regulator of the acoustic signals intensity for the activation of the cut and coagulation
b7 Connector for interconnection to the Argon gas module
Earth protection (inside)
Apparatus of Class I Type CF, protected against the defibrillator effects (a CF type unit guarantees the highest safety level against direct and
indirect contacts, notably for the allowable leakage currents). The applied part type F (floating) is protected from the earth at high and low
frequencies. This kind of unit is especially indicated for direct heart application.
B C
PROGRAM MONOPOLAR
PURE FULG FORCED
BLEND-1 Pin Point Contact
BLEND-2 Soft
ENDO Spray
MONO MAN-1 MAN-2
PED
BIP PED-1 PED-2
MONOPOLAR
MAN-1
PED-1
3 5 4 6
and selection/shifting keys
of the Monopolar Cut/Coagulating Cut
of the Monopolar Coagulation
of the Bipolar Cut/Coagulating Cut
of the Bipolar Coagulation
for the twin foot-switch pedal connection (non standard, and only for the activation of the bipolar currents)
for the connection of the monopolar hand-switch handles
for the connection of the monopolar hand-switch handles
for the connection of the monopolar electrodes cables with activation by foot-switch pedals
for the connection of the monopolar electrodes cables with activation by foot-switch pedals
for the connection of the neutral electrode cable
Alternating current
D E
BIPOLAR
PURE
BLEND
MONOPOLAR
N.P.
MAN-2
PED-2
7
)
Attention: read the user manual
1
Veb- MN (Excell-MCDSe 400)#A(15-5-2007)(in).doc
F
EXCELL
MICRO
400 MCDS
e
MICRO AUTO
MACRO
BIP
BIPOLAR
CUT
BIPOLAR
COAG
COAG
PED-BIP
alsa
8 2
I
b7
b1
