MHP TJK Assembly Instructions

Please check to be sure that all parts are included before proceeding with assembly. Contact your local dealer
if any parts are missing.
Note: The grill is partially assembled. The Burner, Spider Guards, Venturis, Ignitor Collector
Box and the Stainless Steel Handle are installed. Also, for LP units the Gaslow Regulator and
Hose are installed.
TJK Assembly Instructions

CARTON CONTENTS

MODEL TJK Grill
Parts
Top Lid Assembly
Bottom Casting (Grill Head)
Warming Rack
Bottom Grate
Stainless Steel Cooking Grids
Control Panel Brackets
Heat Shield
Grease Cup Holder
Control Panel Assembly
Valve Control Knobs
Ignitor Knob
Stainless Steel Side Shelf
Side Shelf Bracket
Condiment Holder
Venturi Tube Cleaning Brush
Bag of Briquettes (67 pieces)
Meat Probe
Forked Grid Cleaning Tool
Hardware
Connecting Wire for Ignitor
¼-20 x 1½" Rd. Hd. Sltd. Bolt
¼-20 x 1¼" Rd. Hd. Sltd. Bolt
10-24 x 1¼" Rd. Hd. Bolt
¼-20 x ¾" Hex Head Bolt
¼-20 x ½" Rd. Hd. Sltd. Bolt
10-24 KEP Nut
¼-20 KEP Nut
Keeper Washer
Flat Washer for Ignitor
1/8 – 27 Jam Connecting Nut
Lid Pivot Pin
Hitch Pin for Lid
19
Quantity
1
1
1
1
2 (SearMagic 3)
2
1
1
1
2
2
2
2
2
1
1
1
1 (SearMagic Only)
Quantity
1
2
4
8
3
2
8
11
2
1
1
2
2
