  6. Installation & operation manual

Atra GZ 455 Westbrook Installation & Operation Manual

Gas fireplace
Hide thumbs
Table of Contents

Advertisement

Quick Links

WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
– Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
– Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
– In the Commonwealth of Massachusetts,
a carbon monoxide (CO) detector shall be
installed in the same room as the appliance.
This appliance may be installed in an aftermarket,
permanently located, manufactured home or mobile
home, where not prohibited by local codes.
This appliance is only for use with the types of gas
indicated on the rating plate.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Installation & Operation
Atra GZ 455 Westbrook
ATTENTION : CES INSTRUCTIONS DOIVENT
DEMUERER AVEC LE PROPRIÉTERE D'UNE
MAISON.
AVERTISSEMENT: Assurez-vous de bien suiv-
reles instructions données dans cette notice
pour réduire auninimum le risque d'incendie
ou d'explosion ou pour éviter tout dommage
matériel, toute blessure ou la mort.
– Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables
dans le voisinage de cet appareil ou de tout
autre appareil.
– QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE
GAZ:
• Ne pas tenter d'allumer l'appareil.
• Ne touchez à aucum interrupteur. Ne
pas vous servir des téléphones se trou-
vant dans le bâtiment où vous trouvez.
• Appelez immédiatement votre fournis-
seur de gaz depuis un voisin. Suivez les
instructions du fournisseur.
• Si vou ne pouvez rejoindre le fournis-
seur de gaz, appelez le service des incend-
ies.
– L'installatione l'entretien doivent être
assurés par un installateur ou un service
d'entretien qualifié ou par le fournisseur
de gaz.
139435_A GZ 455 DV 8/28/12
Manual
for the
Fireplace
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Atra GZ 455 Westbrook and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Atra Atra GZ 455 Westbrook

Summary of Contents for Atra Atra GZ 455 Westbrook

  • Page 1 139435_A GZ 455 DV 8/28/12 Installation & Operation Manual for the Atra GZ 455 Westbrook Fireplace WARNING: If the information in these ATTENTION : CES INSTRUCTIONS DOIVENT instructions is not followed exactly, a fire DEMUERER AVEC LE PROPRIÉTERE D’UNE or explosion may result causing property MAISON.
