- Page 1 Star Manufacturing Installation International Inc. Operating 10 Sunnen Drive St. Louis, MO 63143 Instructions Phone: (314) 781-2777 Fax: (314) 781-3636 2M-Z1383 Rev. B 3/27/03 STAR-MAX GAS CHARBROILER MODELS 6015CBA 6024CBA 6036CBA 6048CBA 6115RCBA 6124RCBA 6136RCBA 6148RCBA 6048 CBA...
- Page 2 SAFETY SYMBOL This symbol is intended to alert the user to the presence of important operating and maintenance instructions in the manual accompanying the appliance. RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability.
- Page 3 WARNING: Improper installation, GAS INPUT TO CHARBROILER: adjustment, alteration, service or maintenance Models 6015CBA and 6115RCBA 25,000 BTU/HR can cause property damage, injury or death. Models 6024CBA and 6124RCBA 50,000 BTU/HR Read the installation, operating and 25,000 BTU/HR/BURNER maintenance instructions thoroughly before Models 6036CBA and 6136RCBA 75,000 BTU/HR installing or servicing the equipment.
- Page 4 GAS PIPING CHECKING FOR GAS LEAKS Gas piping shall be of such size and so installed as to Soap and water solution or other material acceptable provide a supply of gas sufficient to meet the full gas for the purpose, shall be used in locating gas leakage. input of the appliance.
- Page 5 EXHAUST CANOPY ADJUSTING HEAT PATTERN Open hearth broilers inherently create a good deal of It is possible through this arrangement to have a high heat and smoke and should be installed under an heat or searing section, while having a low heat finishing efficient exhaust hood with flame proof filters.
- Page 6 Visit our Website at: www.star-mfg.com Email: service@star-mfg.com For Fax-On-Demand Literature: (800) 807-9814 THOROUGHLY INSPECT YOUR UNIT ON ARRIVAL This unit has been tested for proper operation before leaving our plant to insure delivery of your unit in perfect condition. However, there are instances in which the unit may be damaged in transit.
- Page 7 18 24 STAR MANUFACTURING INTERNATIONAL, INC. Model: 6015CBA, 6024CBA, 6036CBA, 6048CBA SK1554, Rev. A 11/28/2011 Updated 04-17-08 RB...
-
Page 8: Parts List
PARTS LIST November 2, 2011, Rev. B Updated 04-17-08 rb Star-Max Gas Lava Rock Charbroiler - 15”, 24”, 36”, 48” Model: 6015CBA, 6024CBA, 6036CBA AND 6048CBA Fig No Part No. Description Application 2R-Z0934 1/2/3/4 KNOB-CONTROL H3-Z1322 FRONT PANEL 6015CBA H3-Z1321 FRONT PANEL 6024CBA...
