- Page 1 Complete Compatible w ith… Operating Compatible w ith… Instructions 70294...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction Package Contents Features Consumer Guide to Product Safety Know Your Monitor Know Your Camera Powering Up Monitor/Camera Operation 7-10 Troubleshooting Radio Interference Advice Warranty LIST OF FIGURES Fig. 1 – Signal Strength Fig. 2 – Secure Start Monitor Fig. -
Page 3: Introduction
® *for Monitor only NOTE: If you find any of the contents are missing or should you need to order replacement parts, please contact Mobi Technologies, Inc., Monday through Friday between 8am and 5pm PST at 1.877.662.4462, or visit www.getmobi.com. -
Page 4: Features
FEATURES • 2.0” LCD Color High Resolution TFT LCD Display • Voice Activated Picture & Sound with Auto Mute • Transmission Range up to 400Ft • Up to 20 Ft Night Vision Range • 2.4 GHz Private Digital Transmission • No installation needed—ready to use • Compact design for easy portability • Auto Mute with Voice Activation • Audio Only Option • Low Battery and Out of Range Indicators • Rechargeable Batteries Included for the Monitor • AC/DC Adaptors included for Monitor and Camera... -
Page 5: Consumer Guide To Product Safety
CONSUMER GUIDE TO PRODUCT SAFETY Please read this instruction manual before using your Mobi Secure Start sys- ® ™ tem. When using electrical appliances, basic safety precautions should always be followed. Note: Please keep this manual for future reference. • This product is not intended to be used as a medical monitor and its use should not replace adult supervision. -
Page 6: Know Your Monitor
• Remove the batteries from the Monitor during long periods of nonuse, as batter- ies can leak. • Unplug the AC adaptors from the Monitor and the Camera during periods of nonuse. To disconnect from the power supply, grip the transformer and pull from the power socket. Never pull by the cord. • Only use the Monitoring System with the supplied power adaptors. KNOW YOUR MONITOR Button & LED Functions: (Fig. 4) Two-Way (TALK) Button 2 Power Selector (OFF • AUDIO • ON) Belt Clip Power ON Indicator Volume Up ( + ) Button... -
Page 7: Know Your Camera
KNOW YOUR CAMERA Button & LED Functions: (Fig. 7) Light Sensor Power ON Indicator Speaker LINK Button Power Selector OFF / ON (Fig. 8) AC/DC Adapter Jack Camera Stand Stand Mounting Socket... -
Page 8: Powering Up
POWERING UP The Mobi Secure Start Camera is powered by an AC/DC Adapter while the ® ™ Monitor can be powered by either rechargeable batteries or an AC/DC Adaptor (both provided). Using the AC/DC Adaptors: • Plug the connector of the AC/DC Adaptors into the DC Jacks on the Monitor and Camera units (Fig. 5; no. 9 and Fig. 6; no. 18). Both AC/DC Adapters are the same and are interchangeable between the Monitor and the Camera. -
Page 9: Monitor/Camera Operation
MONITOR / CAMERA OPERATION Monitor Power ON/OFF Switch the Power ON/OFF Selector (Fig. 4, no. 2) to the ON position. The power indicator light (Fig. 4, no. 4) will turn on indicating the Monitor is ON. Volume Adjustment Press the Volume Up ( + ) Button (Fig. - Page 10 VOX mode allows your Monitor to go into standby which conserves battery power. While in VOX mode your Monitor will stop transmitting audio and video. However, whenever the Camera picks up noise (like your baby or anything else) in the room, the Monitor will automatically begin transmitting video and sound. Once the room is quiet again the Monitor with return to the power-saving VOX mode unless you have switched off the VOX feature.
-
Page 11: Fig. 9 - Volume Adjustment Menu Display
Audio Only Mode Your Monitor features an Audio Only mode option. This option allows you to conserve battery power while transmitt- ing and receiving only audio, leaving the video off. To select this option switch the Power Selector (OFF • Audio • ON) (Fig. 4; no. 2) to Audio. This message (Fig. -
Page 12: Fig.11 - Vox Enabled Display
Brightness Level To adjust the brightness level on your Monitor press the Menu Button and use the “+” and “-” Buttons to select Bright- ness (Fig. 18). Press the Menu Button again to select that option which shows the Brightness level scale (Fig. 19). Use the “+” and “-” Buttons to select the desired level and then the Menu Button again to set the level. -
Page 13: Troubleshooting
TROUBLESHOOTING Problem Solution Monitor will not turn on • Check AC/DC Connection • Confirm power outlet is working properly. • Charge Battery Pack Monitor does not show • Confirm audio only mode is not selected an image • Confirm VOX mode if OFF • Confirm there are no obstructions in front of Camera Monitor only transmitting • Confirm audio only mode is not selected audio Camera will not turn on • Check AC/DC Connection • Confirm power outlet is working properly. Battery does not recharge • AC/DC adaptor has not been connected • Check battery pack connection to Monitor. • Confirm power outlet is working properly. • Confirm batteries are placed correctly in Monitor. Connection is lost • Confirm Monitor and Camera are ON. • Confirm AC/DC adaptor is connected properly. • Place Camera and Monitor near each other and press camera link button... -
Page 14: Radio Interference Advice
RADIO INTERFERENCE ADVICE FCC Statement 15.19: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence and (2) This device must accept any interference received, including inter- ference that may cause undesired operation. -
Page 15: Warranty
WARRANTY Mobi Technologies, Inc. warrants this product to be free from defects in mate- rial and workmanship for a period of ninety (90) days from the date of purchase. Should this product prove to be defective at any time during the warranty period, Mobi Technologies, Inc. - Page 16 Mobi Technologies, Inc. 5913 Blackwelder St Culver City CA 90232 Toll Free Number (877) 662-4462 www.getmobi.com Mobi and Secure Start are registered trademarks of Mobi Technologies, Inc. © 2012 Mobi Technologies, Inc. All Rights Reserved...
