Device Programming

This menu is used to program keypads, receivers, and relay modules.
From Data Field Programming Mode, press #93 to display ZONE PROG?. Press 0 repeatedly to display
DEVICE PROG?.
It is very important that devices programmed into the panel in device programming MATCH what is
wired to the keypad connections. If a device is programmed into the panel, and is not physically
wired to the panel, it will cause the keypad to be sluggish .
DEVICE PROG?
1=YES 0=NO
DEVICE ADDRESS
01-31, 00=QUIT
Device Address 00 is always set as an alpha keypad assigned to Partition 1 with no sounder
suppression options, and these settings cannot be changed.
DEVICE TYPE
Alpha Keypad
KEYPAD PART.
Press 1 to enter Device Programming.
The device address identifies the device to the control. Enter
the 2-digit device address number to match the device's
physical address setting (01-30).
Press [ ] to accept entry.
Note: Device Address 04 must be used for the 4285/4286 Voice
Module, if one is installed. If not, it can be used for another
device type.
Select the type of addressable device as follows:
0 = device not used
1 = alpha keypad (6139/6139R)
3 = RF receiver (5881)
4 = output relay module (4204)
5 = Voice (VIP) Module (4285/4286)
6 = Long Range Radio
Press [ ] to accept entry.
If device type 1 (alpha keypad) is selected, this prompt will
appear. Enter the addressable device's default partition
number (01 to maximum number of partitions programmed for
system in field 2 00). This is the primary partition for which
the device is intended to be used. Enter 3 to make this keypad
a master keypad for the system.
Press [ ] to accept entry.
