Installing the Kurta IS/ONE

300
The Kurta IS/ONE digitizer tablet was shipped with older Designer's Work-
sheet systems.
Follow these steps to install and configure your Kurta IS/ONE Designer's
Worksheet:
1. Insert the 9-pin serial connector of the Designer's Worksheet cable
into the console or Remote Interface connector labeled Digitizer.
2. Insert the plug end of the pointing device (pen or stylus) in the IS/ONE
connector labeled Pen/Cursor .
3. Attach the pen holder to the upper left or right hand corner of the
Worksheet by removing the protective paper from the base and
pressing the adhesive to the tablet.
4. Place one printed template sheet under the clear plastic flap on the
digitizer.
5. Set the voltage selection switch to match your electrical outlet . In the
US, set the voltage switch to 110 .
6. Plug the power cord into the back of the Worksheet and into an elec-
trical outlet or a surge protecting power strip.
Note: Additional pads of Designer's Worksheet templates are available
from your dealer or ETC.
7. Set the three sets of DIP switches on the Worksheet as indicated in
the chart below.
1 2
Set A Down Down Down Down Up
Set B Down Up
Set C Up Up
8. Turn the Worksheet power on by pressing the on/off switch . The LED
labeled Indicator (on the back panel) is lit when power is on . If the
LED blinks four times after you turn the power on, the interface cable
is not connected correctly.
9. Press [Setup], and select 1, System Settings .
3 4 5
Down Up Down Down Up
Down Down Down Down Up
6 7 8
Up Up Up
Up
Down
