Models TFP3000, TFPC3000, TFP3000HEPA, TFPC3000HEPA
Console Portable Models
TFPC3000 and TFPC3000HEPA
Table of Contents
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
TFP Questions & Answers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Materials Supplied . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Preferred Installation Options . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
C
US
Operation and Installation Manual
Supply
Air
Exhaust
Air
Whole House Models
TFP3000 and TFP3000HEPA
Type 1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
Type 2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Type 3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-10
Operating Instructions and Annual Check-up . . . . . . . . . . . . . . .11
Medical prescription . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
* LEAVE FOR HOMEOWNER
NOTE: Due to ongoing research and product development, specifications,
ratings and dimensions are subject to change without notice.
TFP-3000
1106
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lifebreath TFP3000
Summary of Contents for Lifebreath TFP3000
-
Page 1: Table Of Contents
Models TFP3000, TFPC3000, TFP3000HEPA, TFPC3000HEPA Operation and Installation Manual Supply Exhaust Console Portable Models Whole House Models TFPC3000 and TFPC3000HEPA TFP3000 and TFP3000HEPA Table of Contents Overview ..........2 Type 1 Installation . -
Page 2: Overview
Overview The Lifebreath TFP Air Cleaner uses "Turbulent Flow The quiet operating unit has a 2-speed selector switch, along with Precipitation" to remove the millions of dangerous airborne a high efficiency fan motor, and a foil faced insulated cabinet that particles in your home. -
Page 3: Tfp Questions & Answers
2 Collar Connections air creating health problems such as asthma, allergies, headaches, 4 Port Collar Screws and fatigue for the home's occupants. The Lifebreath TFP Air 8 Mounting Bracket Screws Cleaner will remove 99% of these polluting particles from your... -
Page 4: Specifications
150cfm @ .4" WC (High Speed) 75 cfm @ .4" WC (Low Speed) OFF/LOW/HIGH SWITCH Collectors Model TFP3000 - Two replaceable TFP collectors Model TFPC3000 CONSOLE - Two replaceable TFP collectors 14.5" 14.75" • Easy to remove for cleaning and replacement... - Page 5 Airflow 150cfm @ .4" WC (High Speed) OFF/LOW/HIGH 75 cfm @ .4" WC (Low Speed) SWITCH Collectors Model TFP3000 - One replaceable TFP collector and one replaceable HEPA filter 14.5" 14.75" 368 mm Model TFPC3000HEPA CONSOLE - One replaceable TFP...
-
Page 6: Type 1 Installation
TYPE 1 INSTALLATION - Option A Standard Design Supply Air Return Air Return Air Metal Hanging Straps (Supplied) & Mounting Bolts 7" Collar Forced Air Furnace Cleaner Foam Figure 2 Figure 1 TFP Directly Connected to Forced Air Heating NOTE: Do not support the weight of the TFP on the duct. Duct must be open and not pinched. - Page 7 TYPE 1 INSTALLATION - Option B Horizontal Design Use Option B when Option A is not practical. Supply Air Return Air minimum 40 inches Cleaner Forced Air ATTENTION Furnace The furnace fan and/or HRV must operate continuously for Type 1 and Type 2 installations. If they do not operate continuously, then interlocking them electrically with the TFP is acceptable.
-
Page 8: Type 2 Installation
TYPE 2 INSTALLATION To a Fully Dedicated HRV System Outdoors Breather Tube (Standard Galvanized "Tee" Fitting) Cleaner HRV/ERV Fresh Air Fresh Air Breather to House to House Stale Air from house Figure 3 TFP Connected to Heat Recovery Ventilator 3. A relief opening or breathing T is required to prevent pressure differences. -
Page 9: Type 3 Installation
TYPE 3 INSTALLATION Independent Duct System (No HRV) This installation configuration is recommended for homes without forced air systems (i.e. radiantly heated homes). The duct should be sized and designed to achieve a sweeping action from one end of the home to the other. - Page 10 TYPE 3 INSTALLATION Alternative Applications Office or Classroom Application Conditioned Space Office or Classroom Space Work Table Application...
-
Page 11: Operating Instructions And Annual Check-Up
2 years. As each home has differences of size, occupancy, location, Model TFP3000 - Two replaceable TFP collectors infiltration rates and homeowner needs, it is hard to estimate when Model TFP3000HEPA - 1 TFP Collector, 1 HEPA filter the collectors will need to be changed. -
Page 12: Wiring Diagram
Wiring Diagram DEFOND SWITCH Neutral WHITE BLACK HIGH SPEED 120 VAC 60 Hz Line BLACK BLUE Ground GREEN BLUE LOW SPEED DOOR SWITCH TRANSFORMER 370V~50/60H WHITE CAPACITOR BLACK WHITE BLACK BLACK BLACK BLACK BLUE TERMINAL BLOCK BLUE GREEN/YELLOW CAUTION /ATTENTION FAN MOTOR...
