TW100-S4W1CA
DSL/Cable Broadband Router with 4-Port Switch
Quick Installation Guide
DSL/Cablu Broadband Router cu 4-Port Switch
Ghid rapid de instalare
Version 06.18.05
TRENDnet
TRENDware, USA
What's Next in Networking
Copyright ©2005.
All Rights Reserved.
TRENDware International, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TW100-S4W1CA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TRENDnet TW100-S4W1CA

Summary of Contents for TRENDnet TW100-S4W1CA

  • Page 1 TW100-S4W1CA DSL/Cable Broadband Router with 4-Port Switch Quick Installation Guide DSL/Cablu Broadband Router cu 4-Port Switch Ghid rapid de instalare Version 06.18.05 TRENDnet TRENDware, USA What's Next in Networking Copyright ©2005. All Rights Reserved. TRENDware International, Inc.

  • Page 2: Table Of Contents

    Table of Contents English ................... 1. Prepare for Installation ............2. Install Hardware ..............3. Configure the computer’s TCP/IP Settings ......4. Configure the Router .............. Româna ..................Pregatiti-va pentru instalare ............ 2. Instalarea Hardware ............... 3. Setarea TCP/IP ..............4.

  • Page 3: English

    English QIG 1. Prepare for Installation Thank you for purchasing the TW100-S4W1CA. This router will allow you to share your Internet connection with multiple users while its firewall protects your network from hackers. This guide will help you set up and configure your router. Following the installation instructions should be quick and easy.
  • Page 4 Collect Internet Service Provider (ISP) Information During the installation of your router the Set-Up Wizard will ask you for specific Internet Service Provider ISP information you should have been provided from your ISP to set up your Cable or DSL connection. The information is different based on your type of Internet Connection.

  • Page 5: Install Hardware

    4. Turn on your Cable/DSL modem. 5. Turn on your router. 6. Turn on your computer. TW100-S4W1CA POWER Verify Hardware Installation Verify that the following router front panel lights are on: Power, WAN, and one LAN port.

  • Page 6: Configure The Computer's Tcp/Ip Settings

    3. Double-Click the Network Icon and the Network Properties box will appear. 4. Under the General Configuration Tab, locate and select TCP/IP with the corresponding network card (such as TRENDnet TE100-PCIWN 10/100Mbps Network Adapter), and then click on the Properties button and the TCP/IP window will appear.
  • Page 7 5. Under the IP Address Tab, select Obtain an IP address automatically. 6. Now go to the Gateway tab and make sure no Gateways are listed in the Installed Gateway's section. If there is Gateway installed, click Remove to remove it. English...
  • Page 8 7. Go to the DNS Configuration tab and click Disable DNS. Then click OK. 8. Click OK on the TCP/IP Properties box. 9. Click OK on the Network Box. 10. At this point, the installation may require files from your Windows CD-ROM. If this happens, insert Windows 98 CD-ROM into your CD-ROM drive and select CD-ROM drive to load the files.
  • Page 9 OK. 13. The IP configuration box will appear. Choose your Network adapter from the dropdown box (such as TRENDnet TE100-PCIWN 10/100Mbps network adapter)and the current IP address information of your computer will show in the box, including the following: IP Address, Subnet Mask and Default Gateway.
  • Page 10 Windows 2000/XP 1. Click Start; click Settings, and click on Control Panel. 2. Double-click the Network Connections Icon. 3. Right-click on the Local Area Connection Icon, and then click on Properties. The Local Area Connection Properties box will appear. 4. Under the "General Configuration" Tab, locate and select TCP/IP and then click Properties.
  • Page 11 6. Click OK. 7. Click Close on the Local Area Connection Properties box. 8. Click on Start; click on Run. Then type cmd and click OK. 9. The Command Prompt window will appear. Type ipconfig at the C:\ prompt and press the Enter key. 10.

  • Page 12: Configure The Router

    4. Configure the Router The following set-up information is designed to help you to set-up your router to connect to the Internet. The set-up is different depending upon the type of Internet Connection you have with your ISP. If you're not sure what type of connection you have please contact your Internet Service Provider and collect “Prepare for Installation”...
  • Page 13 3. Click Quick Setup to configure your Router for Broadband Internet access. 4. Click on the dropdown menu to select the appropriate time zone. If your region runs on Daylight Savings Time, you should enable the “Set Daylight Saving” option and input the dates and times when Daylight Savings Time goes into and out-of effect.
  • Page 14 5. Select the appropriate WAN connection type by clicking on Dynamic IP, Static IP, PPPoE, or PPTP. Dynamic IP 1. Specify the Host Name, (if any) and Clone the MAC Address (if required by your ISP). Click Next. 2. Specify Primary and Secondary DNS addresses if you wish to use DNS addresses other than your ISP-provided DNS addresses.
  • Page 15 3. You may verify your Internet connection on the Status page by typing http://www.TRENDNET.com in your browser's address bar and hitting Enter. If the website appears, your router is configured properly. Static or Fixed IP Cable Connection 1. Enter the IP Address, Subnet Mask, and ISP Gateway Address provided by your ISP.
  • Page 16 3. You may verify your Internet connection on the Status page by typing http://www.TRENDNET.com in your browser's address bar and hitting Enter. If the website appears, your router is configured properly. NOTE: If the website does not appear, please verify your connection type with your ISP.
  • Page 17 ISP-provided DNS addresses. Click Finish. 3. You may verify your Internet connection on the Status page by typing http://www.TRENDNET.com in your browser's address bar and hitting Enter. If the website appears, your router is configured properly.
  • Page 18 PPTP 1. Enter your PPTP User Name and Password, and retype your password. Then, click Next. 2. Specify Primary and Secondary DNS addresses if you wish to use DNS addresses other than your ISP-provided DNS addresses. Click Finish. English...
  • Page 19 Enter. If the website appears, your router is configured properly. NOTE: If the website does not appear, please verify your connection type with your ISP. For detailed information about the TW100-S4W1CA's configuration and advanced settings, please refer to the Troubleshooting section, User's Guideor TRENDnet's website www.trendnet.com.

  • Page 20: Româna

    Troubleshooting sau la la Ghodul de Utilizare cu proceduri de instalare mai detaliate. Daca aveti de nevoie d mai mult ajutor tehnic, va rugam sa vizitati www.trendnet.com sau apelati la telefon pentru a suna. Verificati Continulul Pachetului...
  • Page 21 Colectarea Informatiilor Serviciilor Internet de la Provider In timpul instalarii routerului , Setup Wizard-ul va va cere informatia exacta cu privire la ISP ul Providerului dvs. Informatiilesunt diferite , in functie de tipul Conexiunii la Internet. Va rugam sa verificati tipul conexiunii dvs., si asigurati- va ca ca aveti urmatoarele informatii: Dynamic IP Cable Connection (IP-ul dynamic al Cablului de Coexiune) Nimic necesar.

  • Page 22: Instalarea Hardware

    4. Porniti modemul Cablu/DSL modem. 5. Porniti routerul. 6. Porniti calculatorul. TW100-S4W1CA POWER Verificarea Instalarii Hardware Verficati daca ledurile de pe panoul frontal ale routerului sunt aprinse : Power, WAN, si un port LAN (pentru fiecare computer conectat la router) POWER Româna...

  • Page 23: Setarea Tcp/Ip

    3. Dati dublu-click pe icounl Network si va aparea casuta Network Properties . 4. In tabul General Configuration, gasiti si selectati TCP/IP cu placa de etea corespunzatoare (de ex. TRENDnet TE100-PCIWN 10/100Mbps Network Adapter). Apoi dati click pe Properties si fereastra TCP/IP va aparea.
  • Page 24 5. In tab-ul IP Address , selectati Obtain an IP address automatically. 6. Acum, gasiti tab-ul Gateway si asigurati-va ca nici o Gateway (intrare) nu se gaseste in sectiunea Installed Gateways . In caz contrar, selectati Gateway- ul respective si selectati Remove (Indepartare). Româna...
  • Page 25 7. Gasiti tab-ul DNS Configuration si dati click pe Disable DNS. Apoi dati click pe OK. 8. Dati click pe OK tab-ul TCP/IP Properties . 9. Dati click pe OK in casuta Network . 10. In acest stadiu, este posibil ca instalarea sa necesite fisiere de pe CD-ul Windows.In acest caz, intruduceti in unitatea CD-ROM CD-ul Windows 98 si selectati CD-ROM drive pentru incarcare fisierelor respective.
  • Page 26 “winipcfg” iar apoi dati click pe OK. 13. Va aparea casuta de configurare a IP-ului.Alegeti adaptorul de Retea din casuta “dropdown” ( de ex. TRENDnet TE100-PCIWN 10/100Mbps network adapter) si va aparea informatia cu privire la IP-ul curent al calculatorului, inclusiv urmatoarele:: IP Address, Subnet Mask si Default Gateway.
  • Page 27 Windows 2000/XP 1. Dati Click pe Start; apoi dati click pe Settings, iarapoi pe Control Panel. 2. Dati dublu click pe icon-ul Network Connections. 3. Dati click-dreapta pe icon-ul Local Area Connection iar apoi pe Properties. Va aparea casuta Local Area Connection Properties . 4.
  • Page 28 5. Dati click pe Obtain an IP address automatically si Obtain DNS Server address automatically. 6. Dati Click pe OK. 7. Dati click pe Close din casuta Local Area Connection Properties . 8. Dati Click pe Start, iar apoi pe Run. Tastati cmd si dati click pe OK. Româna...
  • Page 29 9. Va aparea fereastra Command Prompt.Tastati ipconfig de la C:\prompt, si apasati tasta Enter. 10. Daca adresa dvs IP arata in felul urmator, calculatorul dvs este conectat la router in mod corect: IP Address: 192.168.1.x Subnet Mask: 255.255.255.0 Default Gateway: 192.168.1.1 NOTA: Daca informatiile nu corespund celor de mai sus, va rugam rebooati si refaceti pasii mentionati.

  • Page 30: Configurarea Routerului

    4. Configurarea Routerului Urmatoarele informatii sunt menite sa va ajute in starea routerului dvs, pentru conectarea la internet. Pentru a incepe, trebuie sa stiti tipul de conexiune la intenet de care dispuneti. Daca nu sunteti sigur, va rugam contactati Privederul dvs de Internet si culegeti informatiile respective , ce se gasesc in sectiunea “Prepare for Installation”...
  • Page 31 4. Dati click pe meniul dropdown pentru a selecta ora cuvenita. Daca regiunea dvs se bazeaza pe Daylight Savings Time, ar trebui sa bifati optiunea “Set Daylight Saving” si sa setati data si ora cand setarile initiale isi “pierd” efectul. Apoi dati click pe Next. 5.
  • Page 32 Dynamic IP 1. Specificati Host Name (Numele-Gazda), (daca exista) si “Clonati” and Clone adtresa Mac (daca va este precizat de catre ISP-ul dvs). Dati Click pe Next. 2. Specificati adresele DNS Primare si Secundare daca doriti sa folositi alte adrese DNS decat cele asigurate de catre ISP-ul dvs. Dati click pe Finish. Româna...
  • Page 33 3. Va puteti verifica conexiunea prin pagina de satus, tastand http://www.TRENDNET.com in bara de adrese a browserului dvs de web, iar apoi apasand Enter.Daca site-ul apare, routerul dvs este configurat in mod corect. Cablul de Conexiune IP Static sau Fix 1.
  • Page 34 2. Specificati adresele dvs IDN Primare si Secundare daca doriti sa folositi alte adrese DNS decat cele asigurate de ISP-ul dvs. Dati click pe Finish. 3. Puteti verifica conexiunea dvs la situl de Status http://www.TRENDNET.com, si apasand tasta Enter. Daca site-ul apare, routerul dvs este configurat in mod corect.
  • Page 35 PPPoE 1. Tastati PPPoE User Name-ul dvs si Parola, si retastati parola. Apoi dati click pe Next. 2. Specificati adrsele DNS Primare si Secundare daca doriti sa folositi altele decat cele asigurate de ISP-ul dvs. Dati apoi click pe Finish. Româna...
  • Page 36 3. Va puteti verifica Conexiunea tastand http://www.TRENDNET.com si apasnd tasta Enter. Daca site-ul apare, routerul dvs este conectat in mod corect. NOTA: Daca site-ul nu apare , va rugam verificati tipul conexiunii cu ajutorul ISP-ului dvs. PPTP 1. Tastati PPTP User Name-ul dvs si Parola si retastati Parola, iar apoi dai click pe Next.
  • Page 37 NOTA: Daca site-ul nu apare , va rugam verificati tipul conexiunii cu ajutorul ISP-ului dvs. Penreu detalii si configuratii avansate despre setarea TW100-S4W1CA, va rugam apelati la sectiunea Troubleshooting sau la site-ul www.trendnet.com. Româna...

  • Page 38: Troubleshooting

    60 seconds. Next, turn on the router, wait 60 seconds, and turn on your PC. This simple power cycle normally helps the router connect to your Internet connection. Then, try accessing a website such as http://www.trendnet.com with your web browser.
  • Page 39 TRENDnet TRENDware, USA What's Next in Networking Product Warranty Registration Please take a moment to register your product online. Go to TRENDware’s website at http://www.TRENDNET.com TRENDnet Technical Support US/Canada Support Center European Support Center Contact Contact Telephone: Telephone 1(310) 626-6252...
