usa-spec PA11-VOL Owner's Manual

Ipod to volvo car stereo interface
Hide thumbs Also See for PA11-VOL:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
Your iPod throught Volvo Car stereo System!

KEY FEATURES

This interface connects an iPod, iPhone, or iTouch directly to your Volvo
audio system with the following benefits:
Connects iPod's (includes iTouch and iPhone) audio output directly to car audio system
for optimal playback sound quality.
Offers two ways to access iPod music, namely Direct Mode and Playlist Mode.
Direct Mode: Search and select songs directly on iPod.
Playlist Mode: Select songs and Playlist on iPod with radio's CD buttons.
Charges iPod while it is playing and charging stops automatically half hour after iPod is
paused.
Connects an additional audio source such as Satellite radio, DVD player, etc. to the car
audio system through the RCA AUX input jack.
APPLICATIONS
PA11-VOL is applicable to the following vehicles:
MODEL
S40
V40
S60/S70/S80
XC70
V70
(1): PA11-VOL is compatible with 1st half of 2004 S40 and V40 only.
Note : vehicles with NAV system requires an additional CAS-VOL_NAV radio.
CAS-VOL_NAV cable must be purchased sepeprately from
@ 626 336 3836.
LTI Enterprises, Inc. 167 Mason Way, Unit A2. City of Industry, CA91746
www.usaspec.com or www.usaspec.net
YEAR
01 - 04
(1)
01 - 04
(1)
01 - 07
01 - 07
01 - 07
Tel(626)336-3836
techsupport@usaspec.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PA11-VOL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for usa-spec PA11-VOL

Summary of Contents for usa-spec PA11-VOL

  • Page 1: Key Features

    XC70 01 - 07 01 - 07 (1): PA11-VOL is compatible with 1st half of 2004 S40 and V40 only. Note : vehicles with NAV system requires an additional CAS-VOL_NAV radio. CAS-VOL_NAV cable must be purchased sepeprately from @ 626 336 3836.

  • Page 2: Section 1. About Your Interface Pa11-Vol

    SAFETY NOTE: You should always give full attention to driving. Do not operate the features or functions of PA11-VOL in such a way that may distract you while driving. !!!!!CAUTION!!!!! In general, iPod has not been designed to withstand temperature extremes in automobiles.

  • Page 3: Section 2. Direct Mode, Playlist Mode, And Aux

    XC70 01 - 07 01 - 07 (1): PA11-VOL is compatible with 1st half of 2004 S40 and V40 only. Note : vehicles with NAV system requires an additional CAS-VOL_NAV radio. CAS-VOL_NAV cable must be purchased sepeprately from @ 626 336 3836.
  • Page 4 PA11-HON provides two ways to control your iPod through the car radio, namely Playlist Mode and Direct Mode. 2-1 Direct Mode : Search and select music on iPod directly just as you would in portable use. The music will play back through your car stereo. Use the track up/down, fast forward/ reverse buttons on your radio to control music playback.

  • Page 5: Section 3. Wire Connection

    Step 7. Plug the 90 degree angled round din plug of the CAS-VO5i cable to the back of the radio. Step 8. Plug the other end of the CAS-VO5i cable to the PA11-VOL adaptor interface where it is labeled radio.

  • Page 6: Section 4. Connecting & Playing Ipod

    Synchronization time may vary from iPod to iPod. 4-2 When DIP Switch #1 is ON (RCA Disabled) When iPod is connected to PA11-VOL and the CD changer source is selected from the radio, iPod will automatically begin playing at DISC #5. iPod screen will show “ OK to Disconnect”...
  • Page 7 If your iPod has more then 4 Playlist, see Section 5: Playlist Naming. 4-2 When DIP Switch #1 is OFF (RCA Enabled) When iPod is connected to PA11-VOL and the CD changer mode is selected from the radio iPod will automatically begin playing at DISC #4. iPod screen will show “OK to Disconnect”...

  • Page 8: Section 5. Playlist Naming

    SECTION 5. PLAYLIST NAMING When iPod is connected to the PA11-VOL, the adapter scans all available Playlist on your iPod and will automatically assign the first 4 Playlists in alphabetical order to radio’s DISC #1 to #4. If you want the radio to access Playlists which are not the...

  • Page 9: Section 6. Playback Function Controls

    Note: iPod, iPhone, iTouch, and iTune are registered trademarks of Apple Inc. Sirius XM Online is registered trademark SIRIUS XM Radio, Inc. VOLVO is a registered trade mark of Volvo Group Design and specifications of PA11-VOL are subject to change without notice...
