- Page 1 SY-P290 PC/DVI to HDMI Scaler Box Operation Manual SY-P290...
- Page 2 Revision History Version No Date Summary of Change 20090106 Preliminary Release Precaution Failure to follow the precautions described below may cause damage to PC/DVI to HDMI Scaler Box and void the warranty. DO NOT open the case. Doing so will void the warranty. If you find ...
-
Page 3: Specifications
Table of Contents Introduction…………………………………………………..………. Application…………………………………………………....…. Contents………………………………………………......… System Require…………………………………….…………..……. Features……………………………………………..……..……… Operation Controls and Functions……………………………………. Front Panel ................Rear Panel …………………………………………..….….… Specifications……………………………………………...……….. Connection and Installation……………………………..……..…... - Page 4 1. Introduction This Scaler Box is design to display your PC/HD images on the HDTV with better viewing image. It can upscale PC/DVI input sources to HDMI output for wide- range PC/HD resolutions; the resolution support XGA/UXGA/720p/1080p. This unit allows user to select a variety of output resolutions and adjust for the best picture quality.
-
Page 5: Operation Controls And Functions
5. Features HDMI 1.2, HDCP 1.1 and DVI 1.0 compliant. Support PC/HD resolution input: DVI: VGA~WUXGA PC: VGA~WUXGA HD: 480i~1080p50/60Hz Scale any PC/HD resolutions to XGA/UXGA/720p/1080p resolutions. Support PC&DVI to HDMI output. Transfer L/R and coaxial sounds to HDMI. - Page 6 6.1 Rear Panel AUDIO IN HDMI INPUT OUTPUT COAXIAL AUDIO VIDEO TIMING ① Coaxial: Connect the coaxial audio cable from source device. ② L/R: Connect the L/R phone jack from the source device. ③ HDMI out: Connect the HDMI cable to HDTV of display. ④...
- Page 7 8. Connection and Installation MONITOR LCD TV 9. Support Resolution...
