USASPEC PA15-GM Owner's Manual

Ipod to gm car stereo interface
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Your
through GM Car Stereo System!
iPod
This interface connects an iPod, iPhone, or iTouch directly to your GM audio system
with following benefits:
Connect directly iPod's audio output to GM vehicle audio system for optimal sound
quality playback.
Displays text information on XM ready radios.
Retains XM receiver, CD changer, CD player, and DVD system.
Offers three ways to access your music on iPod: Direct Mode, Folder Mode and Playlist Mode.
Charges iPod battery while playing, charging automatically ends. half hour after iPod is paused.
Connects Satellite radio, DVD player or other audio sources through AUX Audio Input jack.
PA15-GM is applicable to the following GM vehicles: (Note: Radio must have AUX or SOURCE button).
