DIGITAL VIDEO CAMERA

GR-D91

Please visit our Homepage on the World Wide Web for Digital

Video Camera:

http://www.jvc-victor.co.jp/english/cyber/

For Accessories:

http://www.jvc-victor.co.jp/english/accessory/

INSTRUCTIONS

CONTENTS

AUTOMATIC

DEMONSTRATION

GETTING STARTED

TAPE

RECORDING &

PLAYBACK

MEMORY CARD

RECORDING &

PLAYBACK

ADVANCED

FEATURES

REFERENCES

For Customer Use:

Enter below the Model No. and Serial

No. which is located on the bottom of the

camcorder. Retain this information for

future reference.

Model No.

Serial No.

LYT1072-001B

ENGLISH

7 – 11

12 – 16

17 – 22

23 – 40

41 – 55

Table of Contents

Need help?

Do you have a question about the GR-D91 and is the answer not in the manual?

Questions and answers

Summary of Contents for JVC GR-D91

Page 1: Digital Video Camera
DIGITAL VIDEO CAMERA GR-D91 Please visit our Homepage on the World Wide Web for Digital Video Camera: http://www.jvc-victor.co.jp/english/cyber/ For Accessories: http://www.jvc-victor.co.jp/english/accessory/ INSTRUCTIONS CONTENTS AUTOMATIC DEMONSTRATION GETTING STARTED TAPE RECORDING & PLAYBACK MEMORY CARD RECORDING & PLAYBACK ADVANCED FEATURES REFERENCES For Customer Use: Enter below the Model No.
Page 2: Table Of Contents
SAFETY PRECAUTIONS IMPORTANT PRODUCT SAFETY INSTRUCTIONS PROVIDED ACCESSORIES HOW TO ATTACH THE LENS CAP HOW TO ATTACH THE CORE FILTER AUTOMATIC DEMONSTRATION GETTING STARTED Power ... 7 – 8 Grip Adjustment ... 8 Viewfinder Adjustment ... 8 Shoulder Strap Attachment ... 9 Tripod Mounting ...
Page 3: Dear Customer
However, live recording and LCD monitor/viewfinder playback are possible anywhere. Use the JVC BN-V408U/V416U/V428U battery packs and, to recharge them or to supply power to the camcorder from an AC outlet, use the provided multi-voltage AC Adapter. (An appropriate conversion adapter may be necessary to accommodate different designs of AC outlets in different countries.)
Page 4: Important Product Safety Instructions
Do not point the lens or the viewfinder directly into the sun. This can cause eye injuries, as well as lead to the malfunctioning of internal circuitry. There is also a risk of fire or electric shock. CAUTION! The following notes concern possible physical damage to the camcorder and to the user. When carrying, be sure to always securely attach and use the provided shoulder strap.
Page 5: Provided Accessories
AC Adapter AP-V11U or AP-V13U Memory Card 8 MB (Already inserted in the camcorder) USB Cable AAA (R03) Battery x 2 (for remote control unit) Remote Control Unit RM-V717U NOTE: In order to maintain optimum performance of the camcorder, provided cables may be equipped with one or more core filter.
Page 6: How To Attach The Core Filter
Attach the Core Filter(s) (if provided with your model interference. Stopper Release the Run the cable through the Core Filter, leaving approx. 3 cm stoppers on both of cable between the cable plug and the Core Filter. Wind ends of the Core the cable once around the outside of the Core Filter as Filter.
Page 7: Getting Started
VU-V856 KIT : BN-V856U battery pack & AA-V80U AC Read the kit's instruction manual before using. Viewfinder on Also, by using the optional JVC VC-VBN856U DC 1 hr. 40 min. Cord, it will be possible to connect BN-V840U or BN-V856U battery packs to the camcorder and supply 3 hrs.
Page 8: Power ............................................................ 7
Since the AC Adapter processes electricity internally, it becomes warm during use. Be sure to use it only in well-ventilated areas. The following operation stops charging: • Set the Power Switch to “PLAY”, “ • Disconnect the AC Adapter from the camcorder. •...
Page 9: Shoulder Strap Attachment
Shoulder Strap Attachment Thread the strap through the eyelet back and thread it through the buckle. Repeat the procedure to attach the other end of the strap to the other eyelet located under the Grip Strap. Confirm the strap is not twisted. Tripod Mounting CAUTION When attaching the camcorder to a tripod, extend its...
Page 10: Date/Time Settings
It takes a few seconds for the cassette holder to open. Do not apply force. There may be a delay after you open the cassette holder cover until the cassette holder opens. Do not use force. If you wait a few seconds and the cassette holder does not open, close the cassette holder cover and try again.
Page 11: Getting Started 7
Loading A Memory Card The provided memory card is already inserted in the camcorder when you receive the camcorder. Make sure the camcorder’s power is off. Press the Monitor Open button LCD monitor, then open the card cover (MEMORY CARD) Insert the memory card clipped edge first.
Page 12: Tape Recording & Playback
Basic Recording Perform the procedures listed below before continuing. Power ( pg. 7) Grip Adjustment ( pg. 8) Viewfinder Adjustment ( Load A Cassette ( pg. 9) Recording Mode Setting ( Remove the lens cap. Press the Monitor Open button monitor and set the VIDEO/DSC Switch Set the Power Switch to “...
Page 13: Zooming
Journalistic Shooting In some situations, different shooting angles may provide more dramatic results. Hold the camcorder in the desired position and tilt the LCD monitor in the most convenient direction. It can rotate 270° (90° downward, 180° upward). Self-Recording You can shoot yourself while viewing your own image in the LCD monitor.
Page 14: Time Code
Time Code During recording, a time code is recorded on the tape. This code is to confirm the location of the recorded scene on the tape during playback. If recording starts from a blank portion, the time code begins counting from “00:00:00” (minute:second:frame). If recording starts from the end of a previously recorded scene, the time code continues from the last time code number.
Page 15: Blank Search
Speaker NOTES: If Stop mode continues for 5 minutes when power is supplied from a battery, the camcorder shuts off automatically. To turn on again, set the Power Switch to “OFF (CHARGE)”, then to “PLAY”. The playback picture can be viewed in the LCD monitor, viewfinder or on a connected TV ( You can also view the playback picture on the LCD monitor with it flipped over and pushed against the...
Page 16: Memory Card
Connections These are some basic types of connections. When making the connections, refer also to your VCR and TV instruction manuals. Make sure all units are turned off. Connect the camcorder to a TV or VCR as shown in the illustration. If using a VCR .
Page 17: Memory Card Recording & Playback
Basic Shooting (Snapshot) You can use your camcorder as a digital still camera for taking snapshots. Perform the procedures listed below before continuing. Power ( pg. 7) Grip Adjustment ( pg. 8) Viewfinder Adjustment ( pg. 8) Loading A Memory Card ( pg.
Page 18: Memory Card Playback
These thumbnail images cannot be transferred to a PC. Images shot with devices (such as JVC GR-DVM70) that are not compatible with DCF cannot be viewed with this camcorder; “UNSUPPORTED FILE!” will be displayed.
Page 19: Memory Card
& Auto Playback You can run through all the images stored on memory automatically. Perform steps 1 and 2 of “Normal Playback” pg. 18). Press 4/6 • If you press 2 during Auto Playback, images are displayed in descending order. •...
Page 20: Advanced Features
Protecting Files The Protect mode helps prevent the accidental erasure of files. Load a memory card ( Set the VIDEO/DSC Switch the Power Switch to “PLAY” while pressing down the Lock Button located on the switch. • A stored file is displayed. Press the MENU/VOLUME wheel Screen appears.
Page 21: Dubbing Still Images Recorded On A Tape To A Memory Card
Dubbing Still Images Recorded On A Tape To A Memory Card Still images can be dubbed from a tape to a memory card. Load a memory card ( pg. 11) and cassette pg. 9). Set the VIDEO/DSC Switch the Power Switch to “PLAY”...
Page 22: Making A New Folder
Select the number of prints by rotating the MENU/ VOLUME wheel and press it. Repeat steps 3 through 5 for the desired number of prints. • The number of prints can be set up to 15. • To correct the number of prints, select the image again and change the number.
Page 23: For Recording
Night-Alive Makes dark subjects or areas even brighter than they would be under good natural lighting. Although the recorded image is not grainy, it may look as if it is strobing due to the slow shutter speed. Set the Power Switch to “...
Page 24: Fade/Wipe Effects
Fade/Wipe Effects These effects let you make pro-style scene transitions. Use them to spice up the transition from one scene to the next. Fade or Wipe works when tape recording is started or when you stop recording. Set the VIDEO/DSC Switch the Power Switch to “...
Page 25: Snapshot (For Tape Recording)
Snapshot (For Tape Recording) This feature lets you record still images that look like photographs onto a tape. SNAPSHOT MODE SELECTION Set the VIDEO/DSC Switch the Power Switch to “ ” while pressing down the Lock Button located on the switch. Open the LCD monitor fully or pull out the viewfinder fully.
Page 26: Manual Focus
Manual Focus To obtain correct focus. If you are using the viewfinder, you should already have made the necessary viewfinder adjustments pg. 8). Set the Power Switch to “ down the Lock Button located on the switch, then press FOCUS pgs.
Page 27: Iris Lock
Iris Lock Use this function in the following situations: • When shooting a moving subject. • When the distance to the subject changes (so its size in the LCD monitor or the viewfinder changes), such as when the subject is backing away. •...
Page 28: Using Menus For Detailed Adjustment
For Recording Menu This camcorder is equipped with an easy-to-use, on-screen menu system that simplifies many of the more detailed camcorder settings ( Set the Power Switch to “ down the Lock Button located on the switch. Open the LCD monitor fully or pull out the viewfinder fully. Press the MENU/VOLUME wheel Screen appears.
Page 29: Snap Mode
SNAP MODE Refer to “Snapshot (For Tape Recording)” ( GAIN UP OFF: Allows you to shoot dark scenes with no picture brightness adjustment. [AGC]: The overall appearance may be grainy, but the image is bright. AUTO : The shutter speed is automatically adjusted (1/30 —...
Page 30: Camera Display
SYSTEM “ SYSTEM” functions which are set when the Power Switch is set to “ ” are also applied when the Power Switch is set to “PLAY” ( ALLY EMOTE EMO MODE R I OR I TY AM RESET RETURN BEEP OFF: Even though not heard while shooting, shutter sound is recorded on the tape.
Page 31: For Playback Menu
TIME CODE [OFF]: Time code is not displayed. ON: Time code is displayed on the camcorder and on the connected TV. Frame numbers are not displayed during recording. CLOCK ADJ. Allows you to set the current date and time ( QUAL I –...
Page 32: Video Display
VIDEO DISPLAY • Settings made in the “ VIDEO DISPLAY” Menu are effective only for tape playback. I V DEO D I SPLAY BR I GH ON SC TE / T I M RETURN BRIGHT DATE/TIME Refer to “ CAMERA DISPLAY” on page 30, 31. The factory-preset of “DATE/TIME”...
Page 33: Dubbing
Dubbing To Or From A VCR To Use This Camcorder As A Player Following the illustration, connect the camcorder and the VCR. Also refer to pg. 16. Set the VIDEO/DSC Switch the camcorder’s Power Switch pressing down the Lock Button switch, turn on the VCR’s power, and insert the appropriate cassettes in the camcorder and the VCR.
Page 34: Dubbing To Or From A Video Unit Equipped With A Dv Connector (Digital Dubbing)
( If the remote control is used when both the player and recorder are JVC video units, both units will perform the same operation. To prevent this from happening, press the buttons on both units.
Page 35: Using The Remote Control Unit
Make sure “REMOTE” in the SYSTEM Menu is set to “ON” ( pg. 30) and the remote control is pointed at the remote sensor beam’s approximate effective distance for indoor use is 5m (16ft). Slow-Motion Playback To allow slow-speed search in either direction during tape playback.
Page 36: Random Assemble Editing [R.a.edit]
MAGNAVOX PANASONIC MITSUBISHI USING THE REMOTE CONTROL UNIT Although the MBR is compatible with JVC VCRs and those of many other makers, it may not work with yours or may offer limited functions. NOTES: If the VCR’s power does not come on in step 1, try another code from the VCR CODE LIST.
Page 37 MODE – – – – : – – ~ Program T I ME CODE – – : – – TOTAL 0 : 00 Connector cover** S-VIDEO EDIT Editing cable (provided) S-Video cable Red to (optional) AUDIO R IN White to AUDIO L IN S-VIDEO IN To Remote PAUSE...
Page 38: For More Accurate Editing
If you select Sepia or Monotone mode from Program AE with special effects, you cannot use the Black & White Fader. In this case the Black & White indicator begins blinking. Once the next Edit-In point is registered, the effect is turned off. To combine these effects, use Sepia or Monotone during recording, then use the Black &...
Page 39: Audio Dubbing
Audio Dubbing The audio track can be customized only when recorded in the 12-bit mode ( pg. 28). NOTES: Audio Dubbing is not possible on a tape recorded in 16-bit audio, on a tape recorded in the LP mode or on a blank portion of a tape.
Page 40: System Connections
DV connector-equipped capture board. When using a DV cable, be sure to use the optional JVC VC-VDV206U or VC-VDV204U DV cable depending on the type of DV connector (4 or 6 pins) on the PC, or use the DV cable provided with the capture board.
Page 41: Troubleshooting
Before consulting your JVC dealer, please check the following to see if you can correct the problem yourself. The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from functioning properly. In such cases, first disconnect its power supply unit (battery pack, AC Adapter, etc.) and wait...
Page 42 • When the LCD monitor's fluorescent light reaches the end of its service life, images on the LCD monitor become dark. Consult your nearest JVC dealer. ¥ Adjust the brightness and angle of the LCD monitor pg. 12).
Page 43 If the indication remains even though you repeat the above two or three times, please consult your nearest JVC dealer. Do not eject the cassette. This will cause damage to the tape. An error indication (E03 or E04) appears.
Page 44: Cautions
American National Standard C73 series type use an AC plug adapter, called a “Siemens Plug”, as shown. For this AC plug adapter, consult your nearest JVC dealer. Plug adapter If there is dust or dirt on the AC Adapter, wipe it clean before using.
Page 45 20 seconds, it stops automatically. Also refer to the cleaning cassette’s instructions. If, after using the cleaning cassette, the problems still exist, consult your nearest JVC dealer. Mechanical moving parts used to move the video heads and video tape tend to become dirty and worn out over time.
Page 46: Cleaning The Camcorder
Serious malfunctioning If malfunctioning occurs, stop using the unit immediately and consult your local JVC dealer. The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from functioning properly.
Page 47: Specifications
Camcorder General Power supply : DC 11.0 V DC 7.2 V Power consumption LCD monitor off, viewfinder on : Approx. 3.4 W LCD monitor on, viewfinder off : Approx. 4.7 W Dimensions (W x H x D) : 76 mm x 94 mm x 143 mm (3"...
Page 48: Index
Controls, Connectors And Indicators Refer to this diagram while reading the instructions. LCD monitor Speaker Viewfinder Stereo microphone ( CHARGE ) PLAY Remote Control INDEX...
Page 49 • Remote Sensor The transmitted beam’s approximate effective distance for indoor use is 5m (16ft). The transmitted beam may not be effective or may cause incorrect operation outdoors or when the remote sensor is directly exposed to sunlight or powerful lighting. •...
Page 50: Blank Search
During Tape Recording Only SOUND b i t 15 : 55 During Memory Card Recording Only 1024 During Both Tape And Memory Card Recording & 0 x W BR I GHT INDEX LCD Monitor/Viewfinder Indications 3 4 5 6 1h50m # $ % ^ PHOTO 0 ’...
Page 51 Displays the selected Fade/Wipe effect ... Appears when in the Squeeze or Cinema mode Rotates while the tape is running ... Displays the recording mode (SP or LP) ... Displays the tape remaining time ... • “REC” appears during recording •...
Page 52: Indications
• Appears when the date/time is not set. • Appears when the built-in clock battery runs out and the previously set date/time is erased. Consult your nearest JVC dealer for replacement. LENS CAP Appears for 5 seconds after power is turned on if the lens cap is attached.
Page 53 Remove the power supply (battery, etc.) and wait a few minutes for the indication to clear. When it does, you can resume using the camcorder. If the indication remains, consult your nearest JVC dealer. E03 or E04 UNIT IN SAFEGUARD MODE EJECT AND REINSERT TAPE The error indications (E03 or E04) show what type of malfunction has occured.
Page 54: Terms
AC Adapter ... Analog Input ... Audio Dubbing ... Auto Date ... Auto Focus ... Auto Playback ... Auto Shut off ... Backlight Compensation ... Battery Low ... Battery Pack ... Beep ... Blank Search ... Brighten The LCD Monitor ... Channels (Left/Right) ...
Page 55 Picture Quality/Image Size ... Playback Special Effects ... Playback Zoom ... Power-Linked Operation ... Power Switch Position ... Program AE With Special Effects ... Protecting Files ... Provided Accessories ... Random Assemble Editing ... Record-Standby ... Recording Mode ... Remote Control ... Reset ...
