Beresford TC-7533 Bushmaster Instruction Manual

Stereo audio digital-to-analogue converter
Hide thumbs
1
2
3
4
5
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
Bushmaster
TC-7533
Stereo Audio Digital-to-Analogue Converter

Overview

The TC-7533 Bushmaster is a reference-quality digital-to-analogue audio
converter featuring the latest DAC Audio technology, Direct Coupled output
stage, and Class-AB headphone stage. The Bushmaster is designed for
maximum transparency and critical playback in professional audiophile
applications.

Burn in

Many users report that the sound output develops in quality after a few days
of use. The Bushmaster can be left powered on and playing a music stream
with the volume turned down for a few days to speed up the burn in process.

Fixed Output Level connection

The Bushmaster Fixed Output is designed to connect to the CD or AUX
input of an amplifier.

Instruction Manual

Front Panel

Digital Inputs

Four digital input connectors (2 x coaxial and 2 x optical).

Input Status Display

Five LED's on the front panel indicate which digital input is selected and
when the Bushmaster is in AUTO or MANUAL mode.

Select Switch

The Select switch allows you to select between AUTO input signal detect,
Manual input channel selection, and LED sleep mode.

Stereo Headphone Socket

The stereo headphone socket mutes the fixed RCA/PHONO output when a
headphone plug is inserted

Headphone Amplifier

The Bushmaster headphone output is driven by a high-end headphone
amplifier. It is designed to drive loads between 12 to 600 Ohms.

Volume Control

The front-panel Volume Control sets the output level of the headphone.
.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC-7533 Bushmaster and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Beresford TC-7533 Bushmaster

Summary of Contents for Beresford TC-7533 Bushmaster

  • Page 1: Front Panel

    Instruction Manual Stereo Audio Digital-to-Analogue Converter Overview The TC-7533 Bushmaster is a reference-quality digital-to-analogue audio converter featuring the latest DAC Audio technology, Direct Coupled output stage, and Class-AB headphone stage. The Bushmaster is designed for maximum transparency and critical playback in professional audiophile applications.

  • Page 2: Digital Inputs

    Rear Panel Analogue Output The Bushmaster has a Left and Right Fixed Line output, terminated into a pair of RCA/PHONO sockets. The output is disconnected when a headphone is plugged into the headphone socket. In this condition the Bushmaster can be used as a headphone amplifier.

  • Page 3: Manual Mode

    AUTO MODE  1. Switch the DAC OFF via the front panel Power button. 2. Wait at least ten seconds. 3. Switch the DAC back ON via the Power button. 4. Whilst the LEDs are each lighting up one by one, press and hold down the SELECT button.

  • Page 4: Safety Information

    releasing the SELECT button, the DAC will switch from TOLSINK-1 to 6. Switch the DAC OFF via the Power button. TOSLINK-2, and then Coax-1 to Coax-2. 7. Wait at least ten seconds. 8. Switch the DAC back ON via the Power button. IMPORTANT: ...
  • Page 5 Notes on Warranty Repairs An RN (Returns Number) is required when sending products back. Goods for repair must be shipped to Beresford ME prepaid and preferably in their original shipping carton with the RN clearly visible on the exterior of the packaging.
