CONNECTIONS CHECKLIST — READ ME FIRST!
The Connections Checklist — Read Me First! section of this guide is a list of ideas to keep in mind
when you set out to perform your connections. It is designed to help us not-so-technically-
advanced individuals. If you read this section, and can't identify the plugs, connectors, and
components you have, do not be afraid to seek help.
1) Always refer to the connection instructions in the user's
guide for your components first! The manufacturer will
provide the most detailed information about their products.
2) Know your jacks and plugs — most are color coded:
• Yellow plugs are Video connections
• Red plugs are Right Audio connections
• White or black plugs are Left Audio (Mono) connec-
tions (if your VCR is mono, it will have a white or
black plug, no red)
3) Perform one hookup at a time. If you have many
accessories to connect, make sure each connection is
correct by checking to see that it works properly before
attempting the next connection.
4) Unplug the power cord between each connection.
5) In and Out Concept. Remember In and Out. The Output jack
f rom one piece will go to the Input jack of the other — read the
jack panels, they are all labeled.

FRONT PANEL DIAGRAMS

C O N N E C T I O N S
AV-27920 Front Panel
AV-20920 • AV-20921 • C-20910 Front Panel
C-13910 • C-13911 Front Panel
5
A/V input plug
RF Connectors
S-Video Plug
