T E C H N O L O G Y
WL-RX SUB
DESCRIPTION
The WL-RX SUB receiver works with the WL-3TX wireless transmitter to make any
powered subwoofer with a line level input into a wireless sub. This transmitter and
receiver combination will accurately reproduce low-frequency sounds and music
without interference or compression over distances up to 150 feet. The receiver's
compact size allows for easy and clean installation with almost any powered
subwoofer. Multiple subs can be used in a single system (by adding receivers), and
multiple systems can be used in the same home or building (by using 1-3 transmitters
set to di erent channels).
While the e ective range of the WL-3TX and WL-RX SUB is normally greater
other obstacles. Phase Technology recommends using the transmitter and receiver in
either the same or adjacent rooms for best results.
CONTENTS:
SAFETY PRECAUTIONS
INSTALLATION/SETUP INSTRUCTIONS
MULTIPLE SUBWOOFERS
TROUBLESHOOTING
SPECIFICATIONS
WARRANTY
WL-RX SUB FEATURES:
• Designed for use with the PHASE TECHNOLOGY WL-3TX wireless multi-channel
transmitter
•Usable with most powered subwoofer
•Signal sensing auto link-up indicator
•Selectable wireless 3-channel operation
•Interference free 2.4 GHz operation
•Long range operation
•Wireless uncompressed audio streaming
•Line level subwoofer output connection
•Allows multiple receiver/subwoofer operation from one transmitter
•Allows up to 3 di erent systems to operate independently.
Phase Technology
An MSE Audio Group company
R
Wireless Subwoofer Receiver
Owners Manual / Installation Instructions
Overland Park, KS 66210
www.phasetech.com
8005 W. 110th St., Suite 208
(855) 663-5600
www.mseaudio.com
2
3
3
3
4
4
Advertisement
Table of Contents
Related Manuals for Phase Technology WL-RX SUB
Summary of Contents for Phase Technology WL-RX SUB
- Page 1 (by using 1-3 transmitters set to di erent channels). While the e ective range of the WL-3TX and WL-RX SUB is normally greater other obstacles. Phase Technology recommends using the transmitter and receiver in either the same or adjacent rooms for best results.
-
Page 2: Safety Instructions
SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: To reduce the risk of electric shock, do not remove cover (or back). No user-serviceable parts inside. Refer servicing to qualified service personnel. Explanation of Graphical Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert you to the presence of un-insulated “dangerous voltage: within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. -
Page 3: Troubleshooting
(yellow) on the WL-3TX trans- mitter. 5. Set the channel selection switch on the WL-RX SUB receiver to the same setting as on the WL-3TX transmitter. This switch is located on the side of the receiver, and on the right rear corner of the transmitter. - Page 4 3.25” x 1.875” x 0.625” WARRANTY Phase Technology warrants its electronics to be free from defects in material and work - manship for a period of three (3) years for electronics products. Purchase must be made from an authorized Phase Technology dealer.
