Page 3: Table Of Contents
Important Information Instructions for Models BSF / BCM / C / BAL Instructions for Models DAR / FAL / ICU / CUB Ducting Pieces Cleaning Guarantee & Exclusions Warranty Condor Rangehood Installation Instructions... -
Page 4: Important Information
IMPORTANT INFORMATION CONDARI PTY LTD makes over 120 different models of QASAIR and CONDOR Rangehoods plus many specials designed by architects and interior designers. It is important to follow the installation instructions for different models. The following is general advice for the installation of CONDOR Rangehoods and is meant as a guide. - Page 5 Live wires are encapsulated where possible to prevent user contact. If necessary drill from the inside out and only through single sheet material. 11. CONDARI PTY LTD can manufacture rangehoods to be used over commercial cookers in domestic applications. NOTE: Installation must comply with local State &...
-
Page 6: Bsf / Bcm / C / Bal
Rangehood to avoid sagging from wall. (Please 7. Fit off ducting as required. Condari will make special duct pieces on request. refer to Rangehood diagram for example of possible fixing points) 8. - Page 7 11. Fit stainless flue to top of hood with 4 supplied fixing screws while hood is on ground to avoid having to drop stainless flue down through hole in the ceiling and causing possible damage to the flue. (If using shroud it can be fitted either at this stage or carefully after hood is on wall) 12.
- Page 8 The flues available for BSF rangehoods are The flues available for BSF rangehoods All BSF rangehoods have 3 fans to model No DL-BC BSF and come in lengths of are model No DL-BC and come in lengths ensure all smoke from the barbecue 600, 900 or 1200mm.
- Page 9 BOSTON Specification Sheet BOSTON (BCM) Wall Mounted Top Ducted Top Ducted Back Ducted Top Ducted Power Entry. LED Lights Electrical connection is to be at the The flues available for BCM rangehoods are junction box inside the rangehood. The flues available for BCM rangehoods All BCM rangehoods have 3 fans to model No DL-BC BCM and come in lengths of are model No DL-BC and come in lengths...
- Page 10 CUBICA Specification Sheet CUBICA (C) - WALL MOUNTED Wall Mounted Switches on Right Hand End Panel. Back Ducted 500mm - Min 1160mm - Max Top Ducted LED Lights Electrical connection is to be at the junction box inside the rangehood. All island CUBICA rangehoods Have 3 fans to ensure all smoke from the barbecue is removed from the...
- Page 11 BALTIMORE Specification Sheet BALTIMORE (BAL) Wall Mounted Top Ducted Top Ducted Back Ducted Top Ducted Power Entry. LED Lights Electrical connection is to be at the junction box inside the rangehood. The flues available for BAL rangehoods are The flues available for Baltimore All BALTIMORE rangehoods have model No DL-BC BAL and come in lengths of rangehoods are model No DL-BC...
-
Page 12: Dar / Fal / Icu / Cub
INSTALLATION INSTRUCTIONS CONDOR RANGE To suit island models: • Darlington • Falcon • Cubica (Island) • Cubica (Undercupboard) It is recommended that the rangehood be mounted 100mm back from the edge of the benchtop. 1. The rangehood can be installed between 1000mm and 1400mm above the cooking surface. - Page 13 ISLAND CONDOR INSTALLATION DETAILS 8mm NUT CEILING JOISTS 8mm WASHER ALLTHREAD POWER ENTRY Condor Rangehood Installation Instructions...
- Page 14 DARLINGTON Specification Sheet Island Mounted DARLINGTON (DAR) Overall Width 500mm - Min 1160mm - Max Allthread Fixing Points. 240v Power Entry LED lights LED Lights. Electrical connection by 3-pin Electrical connection is to be at the plug and lead. junction box inside the rangehood. All DARLINGTON rangehoods have 3 fans to ensure all smoke from Minimum Height - 500mm.
- Page 15 FALCON Specification Sheet Island Mounted FALCON (FAL) 480mm - Min 1300mm - Max 120.0 Power Entry LED lights LED Lights Electrical connection by 3-pin Electrical connection is to be at the junction box inside the rangehood. plug and lead. All FALCON rangehoods have 3 fans to ensure all smoke from the All-thread barbecue is removed from the...
- Page 16 ISLAND CUBICA Specification Sheet Island Mounted CUBICA (ICU) - ISLAND Switches on Right Hand End Panel. 500mm - Min 1160mm - Max Alltread Fixing Points. Power Entry LED lights LED Lights Electrical connection by 3-pin Electrical connection is to be at the junction box inside the rangehood.
- Page 17 CUB Specification Sheet Cupboard Cavity Mounted CUBICA (CUB) - UNDERCUPBOARD Power entry LED lights Electrical connection by 3-pin plug and lead. 3 Fans, LED lights. Electrical Connection is to be at the Junction Box Inside the Rangehood. Condor Rangehood Installation Instructions Fixing Points Lights Light Centres...
-
Page 18: Ducting Pieces
CONDOR DUCTING All Condor ducting pieces are available in zincalume, stainless steel, colourbond material or powderkote colour. 400. DL-4 401. HB-450X250 DL-4 S/S HB-450X250 S/S DL-4 C/P HB-450X250 C/P 402. VB-450X250 403. HB-450X250/45 VB-450X250 S/S HB-450X250/45 S/S VB-450X250 C/P HB-450X250/45 C/P 404. - Page 19 CONDOR DUCTING All Condor ducting pieces are available in zincalume, stainless steel, colourbond material or powderkote colour. 406. BD/WV-V-450X250 407. RCB RCB S/S BD/WV-V-450X250 S/S RCB C/P BD/WV-V-450X250 C/P 408. RCBA 409. WVC-H-450X250 RCBA S/S WVC-H-450X250 S/S RCBA C/P WVC-H-450X250 C/P 410.
-
Page 20: Cleaning
3-4 weeks, or immediately after heavy use. You can do this by hand washing in warm soapy water, or by placing filtres in the dishwasher. Condari does not recommend the use of any citrus or caustic products as this can cause corrosion on the metal filters. -
Page 21: Guarantee & Exclusions
If there is a breach of this warranty, Condari will rectify, free of charge, at it’s nearest service centre or authorised service agency any fault caused by faulty workmanship or material at the time of manufacture occurring in the appliance within 36 months from the date of delivery of the appliance to the customer. - Page 22 EXCLUSIONS There are some exclusions from the Condari Pty Ltd Guarantee. (on previous page) CONDOR Rangehoods are designed to be used over all domestic barbecues available in AUSTRALIA. QASAIR Rangehoods are not to be used over barbecues approved for outdoor use only.
-
Page 23: Warranty
This form must be produced if and when a claim is made under this warranty. CONDOR Rangehoods are made in Ringwood, Australia. Tel: +61 3 9482 7088 Fax: +61 3 9482 7011 Email: sales@condari.com.au Condor Rangehood Installation Instructions... - Page 24 Fax: 03 9482 7011 Email: sales@qasair.com.au Singapore 238843 Tel: 03 9482 7088 Fax: 03 9482 7011 Email: sales@qasair.com.au Tel: +65 6743 8388 Fax: +65 6743 0202 CONDARI RESERVES THE RIGHT TO CHANGE SPECIFICATION WITHOUT NOTICE CONDOR RANGEHOODS MADE IN RINGWOOD 3134 www.condari.com.au...
