Konftel 300IP Installation Manual

REGISTER AN ACCOUNT
The conference phone can be registered in a company SIP switch or PBX or with a public IP
telephony service provider. You can store settings for two accounts in the Konftel 300IP. To
register your phone, you must have access to the account information and all the settings that
the SIP switch or service provider requires.
 Select Settings > SIP.
 Click Yes next to Enable account under Account 1.

Enter the account information you have received.

Account name: Here you choose the name or phone number you want to appear in the
phone's display.

Leave the default values if you have no other information.

Select a method of NAT traversal if this is required.
 Save the settings by clicking the Save button.
The Konftel 300IP responds by showing REGISTERING. If the registration is successful, your selected
account name appears at the bottom of the display with a shaded square in front of it.

In some cases, it may also be necessary for you to make security settings on the Media tab.
See "Installation and Administration of Konftel 300IP".
110046-61-001 Rev 1d
Konftel 300IP Installation Guide
This installation guide explains how to install the Konftel 300IP and make the basic settings.
For further instructions, please visit www.konftel.com/300ip where you'll find a user guide with
full details of all the features as well as the "Installation and Administration of Konftel 300IP "
manual with a detailed description of all connection options and settings.
Connecting
 Connect the Konftel 300IP to
the network as illustrated below.
Konftel 300IP supports PoE (Power
over Ethernet).
 If the network does not support PoE,
an optional Konftel AC adapter must
be used for connection to the mains.
 Place the conference phone in the mid-
dle of the table.
Ethernet and PoE connection
AC-adapter (Optional)
ENGLISH
Network cable port
SD memory card port
Expansion
microphone
port
AUX port
Security lock port
Power supply
Expansion microphone port
