Model: SH-9525AU
Installation and Operating Instructions
FEATURES
• Automatically comes on when motion is de-
tected.
• Automatically turns light off.
• Photocell keeps the light off during daylight
hours.
• LED indicates motion was sensed (day or
night).
UNPACKING
Be sure to remove all contents from packaging
and verify all items are present before assembling
this light fixture. This package includes the fol-
lowing items:
• Security Light
• Canopy Extension with Rubber Gasket
• Rubber Plug
• Mounting Bolt
• Light Shield
• Owner's Manual
Before installation, record the model num-
ber listed inside the fixture. Attach receipt
in case of possible warranty issues.
Model Number:
© 2011 The Chamberlain Group, Inc
®
TM
Motion Sensing
Halogen Fixture
REQUIREMENTS
• The light control requires 230 volts AC.
• If you want to use Manual Mode, the control
must be wired through a switch.
• It is illegal for persons other than a licensed
electrician or person authorized by legislation
to work on fixed wiring or other electrical
installations.
Security Light*
*Note: Illustrations are for reference only and may
be different from actual product
201114-01A
Advertisement
Table of Contents
Related Manuals for Chamberlain Secure Home SH-9525AU
Summary of Contents for Chamberlain Secure Home SH-9525AU
- Page 1 Motion Sensing ® Halogen Fixture Model: SH-9525AU Installation and Operating Instructions FEATURES REQUIREMENTS • Automatically comes on when motion is de- • The light control requires 230 volts AC. tected. • If you want to use Manual Mode, the control • Automatically turns light off. must be wired through a switch. • Photocell keeps the light off during daylight • It is illegal for persons other than a licensed hours.
- Page 2 IMPORTANT SAFETY AND INSTALLATION INFORMATION Before installing security light, read all instructions carefully and keep owner’s manual for future reference. • WARNING: To prevent electric shock, please ensure that power is disconnected before installation. • WARNING: Risk of fire. Keep fixture at least 51 mm (2") from combustible materials. Do not aim at objects closer than 1 meter (3 feet). • CAUTION: Allow fixture to cool before touching. The bulb and the fixture operate at high temperatures. • CAUTION: Use only T3, 250W (maximum) tungsten halogen 230 VAC lamps. • CAUTION: Keep the sensor at least 25 mm (1") away from the bulb. • CAUTION: The sensor must be mounted below the lamp housing for wall installations. • This fixture must be connected to a 230V-240V ~ 50Hz power source. • The fixture must be properly grounded. • This fixture is designed for outdoor installation and should be mounted to a wall or eaves. • To achieve best results, this fixture should be mounted 2.4 meters (8 feet) above the ground. Note: If fixture is mounted higher than 2.4 meters (8 feet), aiming the sensor down will reduce coverage distance. • Do not use dimmer switches or timers with this fixture. • Replace any cracked or broken safety shield. The sensor on this light fixture detects “motion” by the movement of heat across the coverage area. How- ever, following are examples of objects that also produce heat and can cause the sensor to trigger: • Pools of Water • Air Conditioners • Dryer Vents • Animals • Heating Vents • Automobile Traffic If you suspect that a heat source of this type is triggering the sensor, reduce the sensitivity. The sensor on this fixture is more sensitive to the movement of heat moving across the coverage area and less sensitive to the movement of heat directly towards it. Motion Motion Sensor Least Sensitive Most Sensitive Wall Mount Eave Mount Note: Light fixture and sensor should be mounted as shown above when installed (depending upon type of installation).
-
Page 3: Installation
INSTALLATION Canopy Extension This light fixture must be installed by a licensed electrician or other person autho- rized by legislation to work on fixed wiring or other electrical installations. WARNING: Turn power off at circuit breaker or fuse. Place tape over circuit breaker switch and verify power is off at Rubber Gasket the fixture. -
Page 4: Final Assembly
WIRING FINAL ASSEMBLY 1. Double check all wiring connections. 2. Verify the rubber gasket is properly seated WARNING: Turn power off at circuit around the edge of the canopy extension (see breaker or fuse. Place tape over circuit Figure 6). breaker switch and verify power is off at 3. Align the center hole on the fixture canopy the fixture. with the center hole on the canopy extension and attach using the mounting bolt removed 1. Connect the house wires to the terminal block... - Page 5 BULB INSTALLATION AND Caulk Upper Half of Canopy Extension REPLACEMENT CAUTION: When replacing bulb, turn power off and let the fixture cool. Canopy Important: Use a clean glove or cloth when Extension handling the new bulb. Use isopropyl (rubbing) alcohol to clean the bulb if it is touched with Rubber Plug your bare hands.
-
Page 6: Testing And Adjustments
TESTING AND ADJUSTMENTS 4. Loosen the clamp screw in the sensor Clamp 1. Turn on the circuit breaker and light ball joint and gently Screw switch. rotate the sensor. 5. Walk through the Ball minute warm up period Note: Sensor has a 1 Joint coverage area noting before it will detect motion. When first turned where you are when on wait 1 minutes. -
Page 7: Operation
OPERATION LIGHT SHIELD INSTALLATION If your light does not come on at dusk or turns Mode: On-Time Works: Day Night off unexpectedly, then another light source may Test 5 Seconds be activating the daytime shutoff feature. Possible 1, 5, or 10 Auto sources of light interference are street lights, land- Minutes scape lighting, other security lights or lanterns, or To Dawn* Manual an interior house light shining through a window. * resets to Auto Mode at dawn. It could also be reflective light, such as from a pool or light colored wall. Note: W hen first turned on wait about 1 minutes for the circuitry to calibrate. To install the light shield, follow these simple steps. 1. Remove protective backing from the bottom MANUAL MODE of the light shield. -
Page 8: Specifications
SPECIFICATIONS Range ..........Up to 21 m (70 ft.) [varies with surrounding temperature] Sensing Angle........Up to 180° Electrical Load ........Up to 250 Watt Maximum Halogen Replacement Bulb ......T3 250W (or less) halogen 230 VAC Power Requirements ......230 VAC, 50 Hz Operating Modes .......TEST, AUTO, and MANUAL MODE ON-Timer ..........1, 5, 10 minutes Test Timer ..........5 Seconds Manual Mode Timer ......Dusk-to-Dawn Ingress Protection .......IP43 TROUBLESHOOTING GUIDE SYMPTOM POSSIBLE CAUSE SOLUTION Light will not come 1. Light switch is turned off. 1. Turn light switch on. 2. Bulb is loose or burned out. 2. Check bulb and replace if necessary. 3. Fuse is blown or circuit breaker is turned off. 3. Replace fuse or turn circuit breaker on. 4. Daylight turn-off is in effect. - Page 9 CHAMBERLAIN LIMITED WARRANTY Lighting and Chime Products Chamberlain Australia Pty Limited / Chamberlain New Zealand Limited (Chamberlain) is committed to manufacturing and supplying high quality goods. As part of this commitment, we seek to provide reliable service and support for our goods and are pleased to provide you, the original purchaser, with this Chamberlain Limited Warranty. We also provide the following statement as required by the Australian Consumer Law: In Australia, in addition to your rights under this Chamberlain Limited War- ranty, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. Chamberlain’s warranty Chamberlain warrants to the original purchaser of the lighting or chime product (including any LED lights which are provided by Chamberlain as part of the goods) (Unit) that the Unit is free from defects in materials and workmanship for a period of 12 months from the date of purchase. During the applicable Chamberlain Limited Warranty period, if you are concerned that the Unit may be defective, contact your retailer who will provide you with a replacement Unit or refer you to our service centre for a factory repair or replacement. If your retailer refers you to us, call our service centre on the toll free number below and a Chamberlain technician will diagnose the problem. Once the problem has been diagnosed, subject to your rights under the Australian Consumer Law with respect to major failures, Chamberlain will provide you with shipping instructions for a factory repair or replacement.
- Page 10 NOTES__________ ________________ ________________ ________________ ________________ ________________ ________________ ________________ ________________ 201114-01...
- Page 11 NOTES__________ ________________ ________________ ________________ ________________ ________________ ________________ ________________ ________________ 201114-01...
- Page 12 NOTES__________ ________________ ________________ ________________ ________________ ________________ ________________ ________________ ________________ 201114-01...
