HWGWTR-1 REAR REGISTER KIT
INSTALLATION INSTRUCTIONS
Package Contents
REGISTER WITH DAMPER
Hardware Package
#10 X ½" PHILLIPS HEX HEAD SCREW (10)
#10 X 1" SLOTTED HEX HEAD SCREW (2)
Tools Needed
FLAT SCREWDRIVER
TAPE MEASURE
SNIPS
HAMMER
PRIVACY SHIELD
PHILLIPS SCREWDRIVER
SAW
DRILL
Reverso en español
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HouseWarmer HWGWTR-1
Summary of Contents for HouseWarmer HWGWTR-1
-
Page 1: Installation Instructions
Reverso en español HWGWTR-1 REAR REGISTER KIT INSTALLATION INSTRUCTIONS INSTRUCTIONS MUST BE LEFT WITH THE OWNER FOR FUTURE REFERENCE AFTER INSTALLATION. Package Contents REGISTER BOOT REGISTER WITH DAMPER PRIVACY SHIELD Hardware Package Note: Hardware NOT shown at actual size. Replacement screws and anchors can be bought at major hardware stores. - Page 2 Register outlet must be cut in wall before furnace is installed. There are two knock-outs on the inner casing of the furnace. On installed furnace, remove furnace in order to cut hole in wall 2. Remove outer knock-out (4 5/8" x 9 1/2") (117mm x 241mm) for register outlet.
