- Page 1 RGBW PENDANT LIGHTING MANUAL Coloronix, Inc. 5461 West Jefferson Boulevard Los Angeles, California 90016 (323) 677-4242 http://www.rgbw.com Page 1—Coloronix RGBW Pendant Lighting Manual V1.0...
- Page 2 According to copyright laws, this manual may not be copied—partially, or wholly— without the written consent of Coloronix, Inc. Despite full effort to avoid any clerical or printing inaccuracies, Coloronix, inc. accepts no responsibility for any such inaccuracies to be found in this manual.
-
Page 3: Table Of Contents
Quick Step-by-Step Instructions 6 Setting Color Mode 7-8 DMX Color Mode 7 Color Ray Stand Alone Mode 8 Install Fixture 10 Troubleshooting Guide 11 Further Troubleshooting 11 Replacing Failed Fixture 11 Warranty Information 12 Page 3—Coloronix RGBW Pendant Lighting Manual V1.0... -
Page 4: Summary
Who Is This Manual Intended for? This manual is intended for electrical contractors, electrical engineers, and licensed electricians. Additional Supplies DMX control cable: Belden 9841 or CAT5 RJ45 Cable DMX512 compatible controller or Coloronix Color Ray Device (optional) Page 4—Coloronix RGBW Pendant Lighting Manual V1.0... -
Page 5: Safety
Power Consumption: 0.1-9W Environment: Dry Location L70 Life: 35,000 Hours. Temperature Rating: 35°F - 120°F Ambient LED Die Colors: Red (620-635nm) Green (520-535nm) Blue (450-465nm) Neutral White (4000k) Safety: UL 8750 and UL 1598 Page 5—Coloronix RGBW Pendant Lighting Manual V1.0... -
Page 6: Planning For Installation
To successfully install RGBW Pendants, the steps are: 1. Setting Color Mode or Setting Stand Alone Color Ray mode 2. Mounting and Alignment of Fixture 3. Installing Power Connections 4. Installing Data Connections 5. Install Pendant Ready to Go! Page 6—Coloronix RGBW Pendant Lighting Manual V1.0... -
Page 7: Setting Color Mode
197-200 1,3,5,7 85-88 1,4,7,8 201-204 1,4,5,7 89-92 1,3,4,7,8 205-208 1,3,4,5,7 93-96 1,5,7,8 209-212 1,6,7 97-100 1,3,5,7,8 213-216 1,3,6,7 101-104 1,4,5,7,8 217-220 1,4,6,7 105-108 1,3,4,5,7,8 221-224 1,3,4,6,7 109-112 1,6,7,8 225-228 1,5,6,7 113-116 1,3,7,6,8 229-232 Page 7—Coloronix RGBW Pendant Lighting Manual V1.0... -
Page 8: Color Ray Stand Alone Mode
Neon Green, Fuchsia, Repeat olor Ray Remote Control or remote control of the Co lorRay setting, use SCC5-In-Wall Receiver and remote control. All programs and static colors can be set via remote control. Page 8—Coloronix RGBW Pendant Lighting Manual V1.0... - Page 9 Page 9—Coloronix RGBW Pendant Lighting Manual V1.0...
-
Page 10: Install Fixture
In order that they may be easily accessed from the room once construction is complete, secure data cables in the immediate proximity of the housings. Coloronix strongly recommends clearly marking communication cables near the RJ45 connectors (or end of cables) in such a way to indicate the correct order of connection. -
Page 11: Troubleshooting Guide
Disconnect the DMX input at the junction box of the fixture needing replacement. Disconnect DMX output. Replace fixture. Reconnect power negative. Reconnect power positive. Reconnect DATA output. Reconnect DATA input. Reconnect power. Make sure the replaced fixture and the entire system is in working order. Page 11—Coloronix RGBW Pendant Lighting Manual V1.0... -
Page 12: Warranty Information
Warranty Information 3 YEAR PRODUCT LIMITED WARRANTY Coloronix, Inc. provides a warranty to LED fixtures in case of physical or assembly- related malfunctions. This warranty is valid up to three years from the product’s purchase date. Furthermore, Coloronix, Inc. offers to repair products with no charge for labor, or at its own discretion, may offer to replace parts at no charge.
