Summary of Contents for Enhace E400 IP
- Page 1 E400 IP v.1.0 W h e r e S t o r a g e B e g i n s UltraStor Enterprise ES Series E400 IP 3U 16 disks iSCSI for High availablity RAID storage array Quick start guide Linux www.enhance-tech.com...
-
Page 2: Quick Start Guide
RAID storage system with a slick T shaped tray design, built in next generation hardware RAID controller, and a standard 300 watts 80+ green power supply. What is in the box? Carefully unpack your E400 IP storage system, and inventory the accessories according to your model type. E400 IP v.1.0 E400 IP... -
Page 3: Disk Installation
E400 IP Quick start guide Disk Installation Connecting Your E400 IP - Cable Connections If your system was purchased with capacity, please skip this section and - Option 1 immediately go to next section. If your system was purchased without disks, install each disk into the provided disk trays and fasten using the supplied Direct connect to the host computer with iSCSI cables. - Page 4 E400 IP Quick start guide Connecting Your E400 IP - Cable Connections - Option 2 Connect to the host computer via Ethernet Switch with iSCSI cables. Ensure that all of the connectors are properly secured & fastned. Most commom issues are related to poor cable connection. Do not force connector into place.
- Page 5 E400 IP Quick start guide Preparing E400 IP for Con guration Create a RAID Array After power-on, the power LED and hard disks LEDs will light up and your E400 You will be using the Quick Install function in the Web GUI to create a RAID and will display a message showing the system is booting then change to Initializing User Data Volume for your E400.
-
Page 6: Troubleshooting
E400 IP Quick start guide Format Volume for Linux OS Format Volume for Windows OS Please refer to your computer’s documentation for detailed information on Please refer to your computer’s documentation for detailed information on formatting and preparing volumes for use...
