WIDE COLOR MONITOR
Display:
6.5 inch Liquid crystal panel
Number of Pixel:
280 800 pixels
(400 vertical × 234 horizontal × 3)
Drive Method:
TFT (Thin Film Transistor) active matrix
format
Dimensions (W × H × D):
184 mm × 124 mm × 31 mm
(7-1/4" × 4-15/16" × 1-1/4")
including Shroud
Mass: 325 g (0.52 lbs) including Shroud
MONITOR CONNECTION
UNIT
Input
Video: RCA pin × 2 circuits
1 V(p-p), 75 Ω
Audio: RCA pin × 2 circuits
0.5 V(rms)
Tuner: 8-pin DIN connector
(only for JVC's KV-C10)
Output
Display:
13-pin DIN connector
Video: RCA pin × 1 circuit
1 V(p-p), 75 Ω
Audio: RCA pin × 1 circuit
0.5 V(rms)
Dimensions (W × H × D):
108.5 mm × 28.5 mm × 78 mm
(4-5/16" × 1-1/8" × 3-1/8")
excluding projections
Mass: 160 g (0.36 lbs)

SPECIFICATIONS

GENERAL
Power Requirement
Operating Voltage:
DC 14.4 V (11 V to 16 V allowance)
Grounding System:
Negative ground
Allowable Operating Temperature:
0°C to +40°C (32°F to 104°F)
Allowable Storage Temperature:
–20°C to +80°C (–4°F to 176°F)
ACCESSORIES
Mounting spacer × 1
Shroud × 1
System cord × 1
Power cord × 1
Remote controller (with the battery) × 1
Paper pattern × 1
Design and specifications are subject to change
without notice.
Note:
The liquid crystal panel is built with very high
precision technology and has at least 99.99%
effective image pixels. Be aware that on 0.01%
of the panel there may be missing pixels or
constantly lit pixels.
15
