Plug in VGA_port on Motherboard VGA
Connector or VGA Card
16
Plug in Floppy,Hardisk and CD_ROM on
Motherboard Connector
NOTE:
Primary IDE connect Hardisk
Secondary IDE connect CD_ROM
17
Plug in SWBO_ASUS on Motherboard Panel
Connector
NOTE:
Orient the red markings on the
PANEL ribbon cable to PIN 1
18
