VCA MODE
1. Starting Patch.
2. In the Contour position, the Attack and Decay times are controlled by the
ATTACK and DECAY sliders.
3. Move the switch to KEYED center position. Play and release low C.
This note ends abruptly. In this mode, a note will only sound as long as
a pedal is held down.
4. In the third position BYPASS, the notes will continuously sound.
Move the switch back to the KEYED position to stop the notes
from playing.
ATTACK
10 —
O -
DECAY
SUSTAIN
CD
OUT IN
10 —
CONTOUR GENERATOR
CUTOFF EMPHASIS AMT
KEYBOARD
TRACK
—10
— 6
— 0
-<Ht
* Otoi Tip
In the CONTOUR modTth?ATTACK and DECAY sliders control
both the loudness and brightness of the sound.
FILTER SECTION
CUTOFF (Brightness)
1. Starting Patch.
2. Depress the low C pedal.
3. Move the CUTOFF slider to 10 and listen to the sound become much brighter.
Cutoff acts like a tone control for brightness. Experiment with
different settings.
