Wide-i SeaCam
Operator's Manual
4033 Ruffin Road
San Diego, CA
T:
(858) 576-1261
92123- 1817 USA
F:
(858) 576-0219
®
Wide-i SeaCam
Record product serial number below as it appears on the nameplate.
Serial #
Connector Type
Pin-outs
● Ground = Pin
● PWR = Pin
● Video = Pin
www.deepsea.com
sales@deepsea.com
®
Original Instruction - 1
REV 8/7/13
