Assembly and Maintenance Instructions
THIS GAS APPLIANCE IS DESIGNED FOR OUTDOOR USE ONLY.
Model: WCIFAB-P Propane
WCIFAB-N Natural Gas
Model: WCIMPP-P Propane
WCIMPP-N Natural Gas
THESE INSTRUCTIONS SHOULD BE LEFT WITH
THE CUSTOMER. KEEP THESES INSTRUCTIONS
FOR FUTURE REFERENCE.
YOU MUST READ THIS OWNERS MANUAL BEFORE
OPERATING YOUR GAS GRILL.
3/14
Model: WCIMPB-P Propane
WCIMPB-N Natural Gas
PATRIOT SERIES
Owner's Manual
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. Open Lid.
4. If odor continues, immediately
call your gas supplier or your
fire department.
FOR YOUR SAFETY
1. Do not store or use gasoline or
other flammable vapors and liq-
uids in the vicinity of this or any
other appliance.
2. An LP cylinder not connected
for use shall not be stored in
the vicinity of this or any other
appliance.
FOR YOUR SAFETY
Follow all leak-test procedures
carefully in this manual before us-
ing. Do this even if the grill was
dealer assembled. Do not try to
light this appliance without read-
ing the "Lighting" instructions in
this manual.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MHP WCIFAB-P Propane
Summary of Contents for MHP WCIFAB-P Propane
- Page 1 THIS GAS APPLIANCE IS DESIGNED FOR OUTDOOR USE ONLY. FOR YOUR SAFETY If you smell gas: 1. Shut off gas to appliance. Model: WCIFAB-P Propane 2. Extinguish any open flame. WCIFAB-N Natural Gas 3. Open Lid. 4. If odor continues, immediately call your gas supplier or your fire department.
-
Page 2: Safety (Dangers & Warnings)
Improper assembly may be dangerous. Please carefully follow the assembly instructions in this manual. After a period of storage, and/or nonuse, the MHP Gas Barbecue Grill should be checked for gas leaks and burner obstructions before use. See instructions in this manual for correct procedures. -
Page 3: Table Of Contents
Annual Maintenance…………………………...................15 General Maintenance……………………….....................16 Tube Bending………………………………....................12 Cooking Techniques..........................17 Troubleshooting……………………………....................18 Parts Information……………………....................……19 MHP Grill Upgrade Options For Added Versatility, Convenience And Cooking Enjoyment. Stainless Steel Side Burner. Infra-Roast™ Rotisserie Burner The premium commercial grade System. Infra-red rear burner heats stainless steel side burner is... -
Page 4: Warranty
MODEL IDENTFICATION Your MHP Patriot Series Grill is identified by a model number and a serial number located on the left side of the control panel. Always use both the model and serial numbers when contacting Modern Home Products about your grill. For future... -
Page 5: General Instructions
Turn gas OFF at the LP cylinder (or at the shut OFF valve in the case and instructions to assemble your MHP Gas Barbecue Grill. of Natural Gas) when the MHP Gas Barbecue Grill is not in use. Do not store spare LP cylinders under the MHP Gas Barbecue Grill. -
Page 6: Mountings
Grill Assembly Section and assemble the grill head. In-Ground Mounting Assembly Instructions (MPP) •All MHP Grill Heads may be mounted on the 4 foot post for in- TUBE BENDING: For proper bending of the stainless steel tubing, ground installation. see page 12 for bending instructions. -
Page 7: Deck/Patio
1. Mark the location of the four holes at the outside corners of the patio base and drill four holes. The base will be fastened down with lag bolts (not supplied by MHP) after you have connected the gas supply line. The top post notch is the front and the rear ac-... -
Page 8: Portable Base
Mounting Fig. A Column/Portable Base Carton contains the following column and base components for Fig. B assembly: Please check to be sure that all parts are included before proceeding. Contact your dealer or the factory if any parts are missing. Column 3 (Front, 2 Sides) Tank Locking Bar (See Pre-Pack Below) -
Page 9: Grill Head Assembly
View of Grill Head Components Mounting Grill Lid Grill Head Assembly Thermometer Drop-Down Sta-Kool Side Shelf Handle Grill Bottom Ignitor Control Panel Left Side Right Side Burner Control Burner Control Nickel Plate Warming Rack Fig. 6 B. Connecting the Control Panel Support Brackets (Fig. - Page 10 Side Shelves Assembly Mounting Fold-Down Shelves Parts And Hardware: Right Brackets (2), Left Grill Head Assembly Brackets (2), Shelves (2), 1/4 x 20 x 3/4 Bolts (4), 1/4 x 20 Kep Nuts D. Orifice Engagement (Fig. 9) (4) and 10 x 24 Nylock Nuts (2) At the top end of each valve there is a tiny gas opening known as the STEP 1 orifice.
- Page 11 Attaching the Grill Lid Mounting Grill Head Assembly 1. Attach the grill lid to the grill head bottom using the two Hinge Pins and Hinge Clips. (Fig. 16) Grates, Briquettes and Cooking Grids cont. Porcelain Rock Fig. 16 Fig. 18 Connect the Handle 1.
-
Page 12: Gas & Lp Tank Connections
Gas & LP Tank Connections LP Gas Cylinder Requirements: (The LP-Gas Cylinder is not sup- GAS & LP CYLINDER plied with your MHP Grill.) Check Local Codes The LP cylinder should be equipped with an OPD (Overflow Preven- Consult your local LP dealer or Natural Gas Company for recom- tion Device) and a QCC! Or Type 1 (CGA810) cylinder connection. - Page 13 Use this grill outdoors in a well-ventilated area. Do not use wise). Your MHP Grill comes with a Type I connector, also known as a in a garage, building, or any other enclosed area. “Quick Connect Valve” connection. It has a large plastic (coupling nut”...
-
Page 14: Leak Testing & Lighting The Grill
Leak Testing & Lighting Lighting Your Grill ALWAYS OPEN GRILL BEFORE LIGHTING THE Leak Testing BURNER. DO NOT LEAN OVER AN OPEN GRILL. KEEP YOUR LEAK TEST ALL GAS CONNECTIONS BEFORE USING HEAD AND BODY AT LEAST ONE FOOT AWAY WHEN YOUR GRILL. -
Page 15: Maintenance
Then it can be recoated with a high quality heat resistant paint similar to MHP’s BF-1 Paint, available in spray cans from your dealer. Inspect the hose and gas fittings. Remember to leak check every time you disconnect and reconnect a gas fitting. -
Page 16: General Maintenance
3. Commercial stainless steel cleaners and polishers also work ate the ignitor. Check for spark. well, such as MHP’s Stainless Steel Cleaner (Part #SSC). If there is no spark replace the Note: Over time the stainless steel will turn a mild gold Rotary Ignitor. -
Page 17: Cooking Techniques
Cooking Techniques More Versatile than your kitchen oven...your MHP Gas Grill roasts, sears, broils, spit-roast, bakes, steams and smokes. The eating enjoyment of each cooking technique will result in a distinctive flavor for entertaining friends or a welcomed treat for a family meal. -
Page 18: Troubleshooting
On natural gas, inadequate pressure at 2. Check pressure. Should be at or near grill. 7" water column. Incorrect orifice. 3. Check orifice size. CAUTION: If problems can not be corrected using these methods, contact your local MHP dealer for assistance. -
Page 19: Parts Information
Patriot Grill Parts Information Quantity Item Code Description GGTC3 Grill Lid Casting GGBC3 Bottom Grill Head Casting EDLB Burner GGBQ3R Porcelain Briquettes GGCIGRID Porcelain Cast Iron Cooking Grids GGCP Control Panel GGCPB Control Panel Brackets GGDEF Control Panel Deflector Shield GGDV13 Burner Venturi Tubes GGGRATEP... - Page 20 Replacement Parts MHP Grills are covered by U.S. Patent Nos. D 326,207 and D 359,877; Burners by U.S. Patent Nos. 4,267,506; 4,373,505: 4,267,816: 4,488,534 MHP configuration, Chef’s Choice, BBQer’s Choice, SearMagic, Flavor Master, New Phoenix, ProFire, Duro-Cart and Infra-Roast are trademarks of Modern Home Products Corporation.
