5420 DANIELS STREET STE A, CHINO CA., 91786 · (800)634-9166 · (909)628-4722 · FACSIMILE (909)591-2198
TRS OFFROAD PERFORMANCE EXHAUST SYSTEM
03-09 SUZUKI LT-Z400
03-05 KAWASAKI KFX400
35
30
25
20
15
10
5
0
2500
3500
Note: Dyno graphs are for comparison use only. Actual results may vary depending on operating and motorcycle condition.
THIS PRODUCT IS DESIGNED FOR USE IN CLOSED COURSE
!
RACING AND IS NOT INTENDED FOR ANY OTHER USE.
CAUTION: The muffler packing on this system MUST be replaced every
6-8 hours of use, or after each moto. Failure to follow recommended
muffler re-packing interval can cause muffler damage and may void
the warranty.
NOTE: IN THE STATE OF CALIFORNIA, IT IS ILLEGAL TO MODIFY THE EMISSION CONTROL SYSTEM. WHICH INCLUDES THE CARBURETORS OF ANY VEHICLE.
RESEARCH&DEVELOPMENT OF AMERICA, INC.
www.yoshimura-rd.com
2175157
Stock
Yoshimura R&D of America
2002 SUZUKI LTZ-400
2175157 vs. Stock
4500
5500
6500
7500
8500
RPM x1000
2175152-SA
2175157-SA
30
2175157
25
20
15
10
5
9500
10500
2800
3800
TITANIUM PRO FULL SYSTEM WITH CARBON FIBER
TITANIUM PRO FULL SYSTEM WITH TITANIUM
Stock
Yoshimura R&D of America
2002 SUZUKI LTZ-400
2175157 vs. Stock
4800
5800
6800
7800
RPM x1000
8800
9800
!
Advertisement
Table of Contents
Summary of Contents for Yoshimura 03-09 SUZUKI LT-Z400
- Page 1 RESEARCH&DEVELOPMENT OF AMERICA, INC. 5420 DANIELS STREET STE A, CHINO CA., 91786 · (800)634-9166 · (909)628-4722 · FACSIMILE (909)591-2198 www.yoshimura-rd.com TRS OFFROAD PERFORMANCE EXHAUST SYSTEM 03-09 SUZUKI LT-Z400 2175152-SA TITANIUM PRO FULL SYSTEM WITH CARBON FIBER 03-05 KAWASAKI KFX400 2175157-SA...
-
Page 2: Tools Needed
Installation Steps: 1 Remove stock muffler. (See Fig. 1) 2 Remove heat shield from stock header and install onto Yoshimura header using stock bolts. (See Fig. 2) Fig. 1 3 Remove stock header and exhaust port gasket. NOTE: To remove stock header it is necessary to remove the radiator hose pictured in Fig. -
Page 3: Installation Procedures
See parts diagram on page 4 for Spacer Large Washer orientation. 8 Install Yoshimura tailpipe with muffler onto Yoshimura header. Install supplied springs onto header-tailpipe Stock Chassis Mounting 8mm x 65mm with supplied spring puller tool. (See Fig. 4) -
Page 4: Part List
Jetting recommendations with a TEC sound Spring Puller Tool ST-200 reducing insert installed are the same. Muffler Clamp Heat Insulator HT SHLD-14A Yoshimura Vinyl Sticker 17029 Nuts and Bolts Guide (Actual Size): 8mm x 65mm Flange Hex Bolt 8mm Large Flat Washer... - Page 5 4555 CARTER COURT, CHINO CALIF. 91710 · (800)634-9166 · (909)628-4722 · FACSIMILE (909)591-2198 www.yoshimura-rd.com T E C - S A S p a r k A r r e s t e r C l e a n i n g Information...
