16SR 3 Quick Guide
Customer Support Information .........................................2
Camera Left & Front........................................................3
Camera Right & Back .....................................................4
1. Quick Specs.................................................5
2. Loading Magazines .....................................6
4. Power On, Camera RUN, Inching.................9
5. Changing Fps ............................................10
6. Changing Shutter Angle.............................11
7. Timecode Sensitivity Table .........................12
7/97a
Advertisement
Table of Contents
Related Manuals for ARRI 16SR 3
Summary of Contents for ARRI 16SR 3
-
Page 1: Table Of Contents
16SR 3 Quick Guide Customer Support Information .........2 Camera Left & Front............3 Camera Right & Back .............4 1. Quick Specs..........5 2. Loading Magazines ........6 3. Mounting the Magazine onto the Camera ..8 4. Power On, Camera RUN, Inching....9 5. Changing Fps ..........10 6. -
Page 2: Customer Support Information
We strongly recommend that you also acquaint yourself with the full 16SR 3 instruction manual. • Assembly and initial operation should only be carried out after carefully reading the instructions and familiarizing yourself with the equipment and the assembly procedures! •... -
Page 3: Camera Left & Front
Locking slider Running light SET button RUN button SEL button Mirror shutter adjustment tool NORM - PS/CCU switch MODE button Friction adjustment Image rotation release Image rotation knob PL mount Accessory shoe Arriflex 16SR 3 Quick Guide, 7/97a, Page 3... -
Page 4: Camera Right & Back
Main power on/off switch Pitch adjustment RS receptacles (remote RUN & 24 V dc) Mechanical film counter (shows remaining unexposed film) Heated eyecup cable receptacle CCU receptacle ACC receptacle BAT receptacle (power input) Arriflex 16SR 3 Quick Guide, 7/97a, Page 4... -
Page 5: Quick Specs
Asynchronous camera operation Camera ran out of film fps blinking ESU is not receiving a valid signal More detailed specifications can be found in the "Technical Data" section of the 16SR 3 manual. Arriflex 16SR 3 Quick Guide, 7/97a, Page 5... -
Page 6: Loading Magazines
• Lock the magazine door. Ensure that the magazine door is closed and locked by pulling up on it. Retaining levers Film core adapter Guide roller arm in open position Guide roller Arriflex 16SR 3 Quick Guide, 7/97a, Page 6... - Page 7 • Hang the film loop between the four guide pins on the film pressure plate (two shaped as claws). Magazine drive gear Guide pins Magazine drive gear Take-up channel; push film end in here. White index line Arriflex 16SR 3 Quick Guide, 7/97a, Page 7...
-
Page 8: Mounting The Magazine Onto The Camera
Mounting the Magazine Note: You can use SR 1 and 2 magazines on the 16SR 3, and SR 3 magazines on the 16SR 1 and 2, but: - Don't use high speed magazines on standard cameras or standard magazines on HS cameras. -
Page 9: Power On, Camera Run, Inching
Turning Camera Power On The main power on/off switch for the ARRIFLEX 16SR 3 is located on the camera's right side. When a battery is attached to the camera and the main power switch is turned on, you should see characters appear on the LCD display on the camera's left side. -
Page 10: Changing Fps
24, 25, 29.97 and 30 fps. In the PS/CCU position, any speed from 5.000 to 75.000 fps can be achieved on the 16SR 3 (5.000 to 150.00 fps on the 16SR 3 HS). All speeds set on the camera are crystal speeds. -
Page 11: Changing Shutter Angle
Note: When you close the shutter down, you have to compensate your exposure. Open up the lens aperture one stop for a 90° and two stops for a 45° shutter angle. Manual inching knob Mirror adjustment tool Adjustment screw Arriflex 16SR 3 Quick Guide, 7/97a, Page 11... -
Page 12: Timecode Sensitivity Table
B/W Reversal 8670 Color Negative 7279 Color Reversal 7287 Color Negative 8671 Color Negative † 7292 Color Negative 7293 Color Negative 7296 Color Negative 7297 Color Negative 7298 Color Negative 7620 Color Negative Arriflex 16SR 3 Quick Guide, 7/97a, Page 12...
