Summary of Contents for Premier TV-4327LED
-
Page 3: Characteristic Functions
Characteristic Functions 1. LED panel with no glint and low radiation can ease eyes' fatigue and protect eyes. 2. High-quality LED backlight panel is adopted with high brightness, high contrast, wide viewing angle, and super fast response time. Super fast response time can greatly eliminate the shadow of moving images. - Page 4 Important Safety Instructions ● The slots on the case is designed to release heat so as to assure that all inside components will not reach an extra high temperature and can work normally for a long time. Please do not cover the holes while place it.
-
Page 6: Technical Specifications
Technical Specifications Panel size 37" Max. Resolution 1920×1080 Best Resolution 1920×1080@60Hz Pixel Pitch 0.42675mm×0.42675mm Active Area 819.36mm×460.89mm Color 1.06 Billion Power Supply 100V-240VAC 60/50Hz Power Consumption of Speaker 8W+8W Unpacking: 898×572×47mm Net Weight: 11.0Kg Excluding base Packing: 1000×680×135mm Gross Weight: 13.5Kg Unpacking: 898×624×47mm Net Weight: 12.0Kg Dimension (L×H×W) and Weight... -
Page 7: Power Management
Technical Specifications Panel size 55" Max. Resolution 1920×1080 Best Resolution 1920×1080@60Hz Pixel Pitch 0.63mm×0.63mm Active Area 1209.6mm×680.4mm Color 1.06 Billion Power Supply 100V-240VAC 60/50Hz Power Consumption of Speaker 8W+8W Unpacking: 1301×807×48mm Net Weight: 22.0Kg Packing: 1420×930×153mm Gross Weight: 27.0Kg Excluding base Dimension (L×H×W) and Weight Unpacking: 1301×807×48mm Net Weight: 22.0Kg... -
Page 8: Installation And Connection
Installation & Connection Base Assembly Installation Fasten the base supporting cover to the back cover of machine (It needn't to operate this step when base support cover had been installed.), and then Insert base assembly to supporting shield hole of complete machine back cover as illustrated direction of arrow, to make supporting shield and supporting hole center in the same line, finally fasten the screw. - Page 9 Installation & Connection Power Connection Plug one end of the power cord into the input port of the machine's power supply and then insert the other end into the socket of the electrical source (AC 100V-240V, 60/50Hz). Notes: 1. When connecting the power cord, be sure to turn off the machine and other equipment's power.
-
Page 10: Position Of Control Keys
Position of Control Keys 1) Remote Receiving Sensor. 2) Power Indicator. 3) SOURCE: Press this key to enter the menu of signal source and choose signal source. 4) CH+/CH-: Press these two keys to select the channel, and adjust the options you need under OSD operation. -
Page 11: Special Attention
Remote Control Telecontrol battery installation method Take off the cover of battery box, fix two AAA batteries with 1.5 volt, and conform with the polarity of remote control battery box. Note: Appearance of the remote control may be different from this picture, please according to practicality. -
Page 12: Remote Control Shortcut Keys
Basic Operation Instruction Menu Operation Instruction Press ''MENU'' key on the remote control or on the control panel. The TV will display the main menu. 1. Press ''Left/Right'' key on the remote control or ''VOL+/ Picture Mode Soft VOL-''key on the control panel to select the adjustment Contrast sort menu, which includes 4 sorts: PICTURE, SOUND,... - Page 13 Basic Operation Instruction Option Description Function Aspect Ratio Select picture scale "Full, "4:3", "Subtitle", "Film" four modes Color Temp Select color temperature mode There are three Color Temperature modes, of the picture "Standard", "Warm", "Cool ". Noise Reduction Select model of 3D NR "Middle", "High", "Off","Low".
- Page 14 Basic Operation Instruction Function Description Option OSD Transparency Adjust halftone of OSD menu Increasing analog value increases halftone; Decreasing analog value decreases halftone(0-100). Blue Screen Open or close blue screen "On/Off", two states. Sleep Time Set sleep time of the machine "Off, 15M, 30M, 45M, 60M,90M, 120M, 240M", unit: minute.
- Page 15 Basic Operation Instruction ●TV-RATING After selecting TV-RATING, press "Right" key on the remote control or "VOL+" key on the control panel to enter TV-Y TV-RATING submenu. Select one item: TV-Y, TV-Y7, TV-G, TV-Y7 TV-G TV-PG, TV-14, TV-MA by pressing "Up/Down" key on the TV-PG remote control or the "CH+/CH-"...
-
Page 16: Usb Signal Source Operation
Basic Operation Instruction Fine Tune Select to enter the submenu of . Then press ''Up/Down'' key on the remote control or ''CH+/ CH-'' on the control panel to select '' Fine Tune ''. Press ''Left/Right'' key on the remote control to adjust from low frequency or high frequency. - Page 17 Basic Operation Instruction ★Remote Control Shortcut Keys USB 2.0 The last two row keys on the remote control are used for USB operation. PHOTO Select to enter the PHOTO submenu. Select your mobile U disk or hard disk, and press "OK" PHOTO MUSIC MOVIE...
- Page 18 Basic Operation Instruction MUSIC The operations are similar to the "PHOTO".Please refer to "PHOTO" options. Basic Function Press "Left/Right" key on the remote control to select this function, press "OK" key to fast back. Press "PLAY"key to play normally. Press "Left/Right"...
-
Page 19: Simple Troubleshooting
Simple Troubleshooting Symptom Factor Solution 1.Antenna cable connector is loose, 1.Check the antenna cable connector plug whether or cable is damaged. not loose, cable whether or not perfect. 2.Antenna cable type is not matching. Snowflake speckle and 2.Check antenna cable type(VHF/UHF) 3.Direction or position of antenna sound noise.
