- Page 1 User’s Manual...
- Page 2 MS-DOS, Microsoft, Windows NT/2000/XP/Vista/7 are trademarks of Microsoft Corporation. Apple, Macintosh and Mac are trademarks of Apple Computer. NexStar is a registered trademark of Vantec Thermal Technologies. *All other third-party brands and names are the property of their respective owners.
-
Page 3: Table Of Contents
Table of Contents: 1. Introduction 2. Specifications/Features 3. System Requirements 4. Parts Layout 5. LED Indicator 6. Installation 7. RAID Mode Guide 8. RAID Rebuild 9. Hardware Formatting Guide 10. Disconnecting the NexStar HX4R 11. Warranty 12. Contact Table of Contents... -
Page 4: Introduction
1.Introduction: Introducing the NexStar HX4R – a quad 3.5” SATA to USB 3.0 & eSATA External RAID Hard Drive Enclosure designed to keep all your hard drive safe and cool. This enclosure features a hard aluminum shell that effec- tively draws away the heat while an active... -
Page 5: Specifications/Features
Quad 3.5” SATA to USB 3.0 & eSATA External RAID Hard Drive Enclosure w/ Fan Features: • Aluminum Casing Cools Down Your Hard Drive • Vents To Intake Cool Air • Maximum Transfer Rates Up to 5 Gbps w/USB 3.0 •... -
Page 6: System Requirements
3.System Requirements: Microsoft Windows XP/Vista/7 Mac OS 10.6 & greater 1. For USB 2.0 speeds, the system must 1. For USB 2.0 speeds, the system must support USB 2.0 specifications support USB 2.0 specifications 2. For USB 3.0 speeds, the system must 2. -
Page 7: Parts Layout
4.Parts Layout: Power LED HDD1 LED HDD2 LED HDD3 LED HDD4 LED Parts Layout... -
Page 8: Led Indicator
5.LED Indicator: Quad 3.5” SATA to USB 3.0 & eSATA External RAID Hard Drive Enclosure w/ Fan General Operation: ON : Power on Power LED Green OFF: Power off ON : HDD inserted Flash Randomly: Accessing (Read/Write/Rebuild) HDD 1 LED Blue Flash Consistently (3 flashes per second): HDD error OFF: HDD not installed/Removed/sleep mode... -
Page 9: Installation
6.Installation: Quad 3.5” SATA to USB 3.0 & eSATA External RAID Hard Drive Enclosure w/ Fan WARNING: All data will be deleted on each hard drive during Hard Drive Mode change. Please back up your hard drive(s) before adjust- ing RAID mode. New hard drives must be formatted before use. *Refer 5.1.Hardware Installation: Installing the hard drive: (1) Push lock to the left to unlock... - Page 10 (3) Carefully install the hard drive into the tray. Be sure the fasten the NOTE: If necessary, please use the hard drive foam spacer if the hard drive cannot be mounted stably. Refer to image for foam spacer placement. (4) Reinsert the HDD tray into the case.
- Page 11 Connect the type (B) USB connector to the For new hard drives, you will need to initialize and NexStar and the type (A) USB connector to an partition your hard drive before it will appear in available USB port on your system.
-
Page 12: Raid Mode Guide
Normal JBOD Check and make sure all HDDs are installed and all LEDs light up. Connect the NexStar HX4R to the computer via USB 3.0 or eSATA cable. RAID 0 RAID 10 (1) Locate the RAID switch and select the designated HDD mode to configure the NexStar HX4R. - Page 13 Individual(Normal) Drive Mode: This mode enables each Hard Drive to be seen as separate single drives with separate Hard Drive capacities. ( figure 7-A) ( figure 7-B) NOTE: Normal If you are using Indvidual Drive Mode with eSATA interface, your eSATA port on the system must support Port Multiplier to see more than one drive.
-
Page 14: Jbod Mode
JBOD Mode: This mode concatenates a series of physical drives as a single large volume; Hard Drive 1 through 4 are combined into a storage capacity that is equal to the sum of each of the physical hard drives. Switching to this mode will prompt to initialize and format the hard disks. - Page 15 RAID 0 Mode (Striped): This mode splits data evenly across the four Hard Drives resulting in capacity that is the sum of 4 times the smallest volume. Data access speed is increased however at the cost of no data redundancy. Four equal hard drives: The capacity is equal to the sum of all hard drives.
- Page 16 RAID 10 (1) Mode (Mirror): This mode allows the device to automatically copy data to 2 sets of 2 hard drives running RAID 0. It stores all data in duplicate on the two sets of RAID to protect against data loss due to drive failure.
- Page 17 RAID 3 Mode (Byte-Level Striping) This mode performs a byte-level striping with a dedicated parity disk. This mode is generally used when application requires highest transfer rates in long sequential read and writes. Capacity is equal to the smallest multiplied by (4-1). ( figure 7-H) ( figure 7-I) RAID 3...
- Page 18 RAID 5 Mode: This mode uses block-level striping with parity data distributed across all disks. The capacity is equal to the smallest disk multiplied by (4-1). ( figure 7-J) ( figure 7-K) RAID 5 NOTE: All data previously stored on the hard drive will ( figure 7-J) be lost! Please back up all data to a separate storage before continuing.
-
Page 19: Raid Rebuild
1. Power off the NexStar HX4R. 2. Remove failed hard drive. 3. Install a functional hard drive. 4. Turn on the power and the NexStar HX4R will automatically start rebuilding. LED Configuration on Rebuild Process RAID 3/5: LED blinks irregularly... -
Page 20: Hardware Formatting Guide
9.Hard Drive Formatting Guide Quad 3.5” SATA to USB 3.0 & eSATA External RAID Hard Drive Enclosure w/ Fan • You may format your Hard Drive by using the USB connection. • Please make sure your External Enclosure is turned on and connected to the PC before formatting the Hard Drive. - Page 21 STEP3: Right-click on the “Unallocated” box and select “New Partition”. (Disk number may vary) STEP4: The “New Partition Wizard” will appear. Please follow the “New Partition Wizard” step by step instructions to complete the Hard Drive formatting procedure Hard Drive Formatting Guide...
- Page 22 STEP5: Once the Hard Drive formatting procedure is completed, the Hard Drive will be recognized as a “New Volume” (New Volume drive letter may vary i.e. “New Volume (Z:)” ) STEP6: Double-click “My Computer”. You will see “New Volume” appear on your PC (Drive letter may vary i.e.
- Page 23 For Mac Users: STEP1: When you connect the NexStar HX4R to a Mac with a new hard drive, the dialog “Disk Insertion” will appear. Please select “Initialize”. (A formatted HDD will not display this dialog) STEP2: Select which HDD you want to erase.
- Page 24 STEP3: Click “Erase” at the upper right side. Select which kind of format from Volume Format. Please input the name you wish to name your new Volume. Click “Erase” at lower right side. STEP4: After you hit “Enter”, the dialog “Erase Disk”...
-
Page 25: Disconnecting The Nexstar Hx4R
You may now safely turn off and disconnect the NexStar. WARING: NEVER remove the NexStar while the hard drive is in use. Doing so may corrupt the data on the hard drive or damage the hard drive, NexStar and the computer. -
Page 26: Warranty
11.Warranty: The NexStar HX4R comes with a 1 year limited warranty ( 90 day parts ) . If your unit should become defective within that time frame, please go to www.vantecusa.com for information on how to receive warranty exchange or repair.
