Everstar MPK-10CR Use & Care Manual page 9

Air Conditioner Operating Instructions
(continuous drain)
7) This unit also has provisions for a continuous
"drain" option (for basement applications having
a floor drain). To connect the continuous drain
option, remove the drain plug from the back of
the unit, then install the drain hose. Please
remember to place the open end of the hose into
a bucket or floor drain failure to comply with
these procedures will result in flooding.
Fig13 &13a.
8) To adjust "air flow" direction , (up / down only)
move the louver wheel with finger to the desired
position. Fig.14.
Cooling stops automatically when the set
temperature is achieved. Cooling resumes when
the room temperature rises above the set
temperature level. The temperature has no effect
on the fan operation. Therefore, the fan will
operate continuously (after the compressor has
cycled off) to maintain optimal temperature control.
!
ATTENTION
Removal and/or partial displacement of the water
tank will cause the compressor to stop operating
(this is a safety feature). Under this condition the
"water full" light will flash (red) continuously until
the tank is corrected. The compressor cannot
operate during a flashing "red" light condition.
Check the following;
1. Is the water tank full?
Empty and re-install water tank.
2. Has the water tank been accidently displaced?
Re-Position water tank.
The "red" light will stop flashing automatically
When the water tank has been emptied and / or
correctly re-positioned.
Fig.13
Fig.13a
!
!
During cooling and dehumidifying modes, if the
compressor cycle is interrupted (unplugged, power
failure, etc.) And reinstated immediately thereafter (within
3-5 minutes), A "compressor protection circuit"is auto-
matically self-affected. The mode indicator light will flash
"green" for approximately 10 seconds, confirming the
protection circuit is activated. The compressor cannot
operate during a "compressor protection" condition (this is
normal). It may take 3-5 minutes before the "protection
circuit" self-deactivates.
DO NOT ATTEMPT TO START THE UNIT
(COMPRESSOR)DURING THIS PERIOD.
8
Remove the
drain plug
Connect the
drain hose
(included)
!
CAUTION
Fig. 14
