Window Kit Installation

Your window kit has been designed to fit most
standard "vertical"and "horizontal" window
applications. However, it may be necessary for
you to improvise/modify some aspects of the
installation procedures for certain types of
windows. Please refer to Fig. 2 & Fig. 2a for
minimum and maximum window openings.
Water Tank Safety Feature
This unit is equipped with a fail-safe switch
mechanism which prevents the unit from
condensing water in the event the water tank is
accidentally displaced, and / or FULL with water.
If this situation occurs, the LED window shows
"P1" and the WATER FULL indicator light will
flash red continuously until the water tank is
correctly positioned and/or emptied.
NOTE: The fan motor will continue to operate
under this condition. This is normal, but no
cooling or dehumidifying will occur until the
tank is emptied and/or correctly installed (It
may take several minutes before the
compressor resumes normal operation).

Operating Instructions

Before Starting This Unit
1) Select a suitable location, making sure you
have easy access to an electrical outlet.
2) Install the Flexible Exhaust Hose and the
Adjustable Window Slider Kit as depicted in
Fig. 3 & Fig. 3a.
3) Plug the unit into a 115V / 60Hz grounded
electrical outlet (Refer to the nameplate).
DO NOT USE AN EXTENSION CORD.
4) Make sure the Water Tank is correctly
positioned inside the cabinet otherwise the
unit will not operate. Fig 4.
5) To turn the unit on, press the POWER key
(On / Off Switch). Fig. 5.
Horizontal Window
Window Slider Kit
1
Minimum: 26 / " (67.3cm)
2
7
Maximum: 47 / "(121.6cm)
8
Vertical
Window
Fig. 3
5
Fig. 2a
Window Slider Kit
Minimum: 4"(10.1cm )
1
Maximum: 73 / "(186.7cm)
2
Fig. 3a
Fig. 2
Fig. 4
Fig. 5
