Remote Controller Features

The hand held remote units allows you to control
all operational aspects of your air conditioner from
the convenience of your favorite armchair. Here are
some things you should know about operating the
unit with the hand held remote.
Upper Control Buttons
TEMP Button : Push the button to
1
decrease the indoor temperature setting.
MODE Select Button: Each time you push the
2
button, a mode is selected in a sequence that
goes from AUTO, COOL, DRY and FAN, as
the following figure:
AUTO COOL
3 RESET Button: When the RESET button is
pushed, all of the current settings are cancelled
and the control will return to the initial settings.
4
LOCK Button: Push this button to lock in all the
current settings. When the function is set, there
will be a signal "
remote. To release settings, push again and the
signal will disappear as well.
TIMER ON Button: Press this button to preset
5
the time ON(start to operate). Each press will
increase the time ON setting in half an hour
increments. When the setting time displays
10, each press will increase the time ON setting
in an hour increments. To cancel the time ON
program, simply adjust the Time ON to 0.0.
6 TIMER OFF Button: Press this button to preset
the time OFF (turn off the operation). Each
press will increase the time OFF setting in half
an hour increments. When the setting time
displays 10, each press will increase the time
OFF setting in an hour increments. To cancel
the time OFF program, simply adjust the Time
OFF to 0.0.
ON/OFF Button: Push this button to start the
7
unit operation, push the button again to stop
the unit operation.
DRY
FAN
" shown on the screen of the
8 FAN SPEED Button: This button is used for setting
Fan Speed in the sequence that goes from AUTO,
LOW, MED to HIGH, then back to Auto. If fan
speed is set on AUTO, there will be no signal
beside LOW, MED and HIGH.
(The initial fan speed setting is AUTO.)
NOTE
In DRY mode, the actual fan speed will fix on
high speed, although the remote can be
selected in AUTO, LOW, MED or HIGH fan
speed.
TEMP Button : Push the button to increase the
9
indoor temperature setting.
AUTO
COOL
DRY
1
MODE
2
SPEED
8
3
Battery replacement:
Install / Replace Batteries
The Remote Controller uses two alkaline dry batteries
(AAA 1.5V).
1. To install batteries, slide back the cover of the
battery compartment and install the batteries
according to the directions (+ and -) shown on the
Remote Controller.
2. To replace the old batteries, use the same method
as mentioned above.
NOTE
1. When replacing batteries, do not use old batteries or a
different type battery. This may cause the remote
controller to malfunction.
2. If you do not use the remote controller for several weeks
remove the batteries. Otherwise battery leakage may
damage the remote controller.
3. The average battery life under normal use is about 6
months.
4. Replace the batteries when there is no answering beep
from the indoor unit or if the Transmission Indicator light
fails to appear.
15
o
SET TEMPERATURE(F )
FAN
HIGH
MED
LOW
TIMER ON OFF
TEMP
TIMER
ON/OFF
ON
5
FAN TIMER
OFF
6
RESET LOCK
4
Fig. 1
9
7
