Page 1 RHDM-2301 22.5" - LCD Broadcast Monitor User manual K5960012-04...
Page 2 Intentionally left blank Barco - RHDM-2301 - User manual...
Page 3: Introduction
Introduction 1 Introduction 1.1 Customer notice Thank you for buying Barco! Barco is a world leader in display and visualization solutions. We are convinced that you will enjoy our products. 1.2 Change record Revision Date Description November 2008 Initial release September 2009 Update for software V3.00...
Page 4: Contents Of The User Manual
Technical details: Check the “Addendum” for detailed and technical information on the display unit. Trough-out the manual, the reader may wonder about the use of a specific term. The frequently used terms are gathered in the chapter “Terminology” for the readers’ convenience. Barco - RHDM-2301 - User manual...
Page 5: Structure Of The User Manual
Chapter 8: List of abbreviations Chapter 9: Table of contents, list of figures and list of tables Barco - RHDM-2301 - User manual...
Page 6: About The Product
Introduction 1.4 About the product The RHDM-2301 is a reliable grade-1 reference monitor for color critical applications in the broadcast and post-production markets, such as: • camera control • program and distribution monitoring • signal QA (Quality Assurance) • technical room •...
Page 7 • Slot 4 – future option SDI module specifications • Possible inputs: 2 x SDSDI 2 x HDSDI 2 x 3Gb/s (option) Combination of 2 signals out of: SDSDI, HDSDI or 3Gb/s (option) 1 Dual Link (option) Barco - RHDM-2301 - User manual...
Page 8 • USB: host, peripheral and support of mass storage devices, mouse, etc… Feature packs and options • The RHDM-2301 comes in different flavors. Depending on the specific applications that are tar- geted by the user, different feature packs can be selected. Depending on the feature pack, addi- tional options can be available.
Page 9: Read Carefully
NOTE Notes – presented in this manual, provide information, which emphasize points, significant to understand and operate the unit. IMPORTANT Important – presented in this manual, provide information, which is important to highlight. Barco - RHDM-2301 - User manual...
Page 10: Copyright
During the warranty period, Barco n.v. will do all repairs free of charge (material and labor). The faulty parts or units have to be shipped freight prepaid to a Barco n.v. regional service center. Barco n.v. will pay the freight charges when the repaired parts are shipped back to the customer's site.
Page 11: Trademarks
• All software installed on the system, whether they are acquired from Barco n.v. or a third party. An exception is made for software delivered by Barco n.v. that would prove to be a cause for the malfunctioning of the hardware covered under this Agreement.
Page 12: Open Source License
The crossed-out wheeled bin symbol invites you to use those systems. If you need more information about the collection, reuse and recycling systems, please contact your local or regional waste administrator or Barco (www.barco.com). Barco - RHDM-2301 - User manual...
Page 13: Safety Precautions
• Do not use the display unit in a dusty or damp room. • Do not submit the display unit to heavy shocks and/or vibrations. • Do not cover the display unit while in operation to avoid overheating. • Do not expose to direct sunlight. Barco - RHDM-2301 - User manual...
Page 14: Requirement For Dusty Environments
8 or better according to ISO14644-1. If the room in which the display unit is installed does not comply with the dust class stated above, please contact Barco to discuss possibilities to protect the display unit against dust.
Page 15: Hazardous Materials
• Do not power the unit with other input sources as specified in the technical specifications: AC power source: 100-240 Vac, 50-60 Hz DC power source: 24Vdc • Do not push objects into ventilation openings of the display unit. Barco - RHDM-2301 - User manual...
Page 16: First Operation
The display unit is almost fully mounted when unpacked. Do not forget to connect the power and USB cable between the display unit and the control panel. 2.2 Overview locations for operation Figure 1: Overview of operational controls, indicators and OSD functionalities Barco - RHDM-2301 - User manual...
Page 17: Switch On The Display Unit
“full functionality description” to find detailed information on each part and each function of the display unit. Power LED (green or orange) Standby LED (green or orange) Calibration/Error LED (orange or red) Figure 2: Overview indicator lights Barco - RHDM-2301 - User manual...
Page 18 LED is green, check if the USB cable and the power cable between the display unit and the control panel are properly connected. For more informa- tion, please consult the installation instructions in the addendum to connect the control panel to the display unit. Barco - RHDM-2301 - User manual...
Page 19: How To Register The Display Unit
The remaining grace period is shown in the top right corner. To register the unit on the website, you will need the current pincode. To obtain it, press Menu and scroll down to the License submenu. The current pincode is displayed there. Barco - RHDM-2301 - User manual...
Page 20 • If the grace period has expired, you will see the “Welcome message” with instructions on the screen. Write down the pincode of the display unit that is displayed on the screen, you will need to register it on the website. Barco - RHDM-2301 - User manual...
Page 21 3. Register your products and licenses by entering their pincodes on the personalized webpage to obtain license files for your products (https://my.barco.com/productregistration/). In case my.barco.com is not available, please contact Barco service (see contact info mentioned in the above screenshot) 4.
Page 22 • If you already have an existing my.barco.com account, please click ‘Login’ and enter your exist- ing user name and password to proceed with the login. • Otherwise if you are a new customer, please sign up to open a my.barco.com account. (This step is done only once)
Page 23 First operation • The welcome screen appears. Click on the left tab ‘Register Pincodes’. Barco - RHDM-2301 - User manual...
Page 24 First operation 2. Register Pincodes • Add all pincodes of the new products and licenses to be registered Barco - RHDM-2301 - User manual...
Page 25 • When adding codes, the pincode appears in the list at the bottom of the window • When done entering, click on ‘Register’. • A new page (“Show Products”) will open with a list of all entered pincodes at the top: Barco - RHDM-2301 - User manual...
Page 26 Select the license you would like to assign to that monitor and click ‘Add Feature Pack”. • There is an overview of the assigned licenses at the bottom of the page. Barco - RHDM-2301 - User manual...
Page 27 4. Get License File • If you agree with this assignation, click on ‘Get License File’ • Following page with a link appears. Click the link ‘here’ and save the file on location of your choice. Barco - RHDM-2301 - User manual...
Page 28 Important note: Verify that the USB stick used to install the license file does not contain a RHDM software package (xxx.deb) or a 3D LUT file (3d.lut) in its root. Software updates always have priority and will prevent the license from being installed. Barco - RHDM-2301 - User manual...
Page 29 Generate a new pincode via the monitor’s OSD (see following section). Register this pincode on the website, as explained previously. The website will ‘release’ that particular monitor and the (wrong) license previously associ- ated with it Assign that license to the correct monitor. Barco - RHDM-2301 - User manual...
Page 30 • Click on “Generate new Pincode” in the “License” OSD menu: IMPORTANT Important note: Do not generate a new pincode unless you plan to install new licenses on your product. Generating a new pincode will disable the feature packs on your product! Barco - RHDM-2301 - User manual...
Page 31 First operation Figure 5: License OSD menu Confirming this dialog will remove all feature packs from the display unit and generate a new pincode. Barco - RHDM-2301 - User manual...
Page 32 • Generate a new license file. Place the license file on a USB stick and connect the USB stick to all display units that need to be updated with the new licenses. • The following message appears when the update is successful and the display unit will function immediately: Barco - RHDM-2301 - User manual...
Page 33: Concepts Of Operation
The function keys contain most of the settings of the display unit. It is important to understand the division of the function keys based on the effect that they have on the processing of the video signal. Figure 6: Function keys divided into categories Barco - RHDM-2301 - User manual...
Page 34 The image adjustment knobs control the settings of Background (1), Picture (2), Saturation (3) and Hue (4). Changing these settings will result in the display unit working out of the calibrated range. These settings apply to the each window separately. Barco - RHDM-2301 - User manual...
Page 35 The user can also decide to show only one of the 3 color channels or to convert the video signal to monochrome. In all these cases also the button will light up orange. Press ( ) the button to go back to the calibrated status of the display unit. Barco - RHDM-2301 - User manual...
Page 36: How To Setup The Display Unit
Select the type of input that is connected to the input board (Single or Dual link). When the signal description in this submenu is not correct, override the signal detection and set the input signal properties manually. E.g. for Dual Link: RGB, 4:4:4, 10 bit and Seg- mented frame. Barco - RHDM-2301 - User manual...
Page 37: How To
3.2 How to change the license installed on the display unit Activate the “Admin mode” that you can find in the main menu • Press ( to open the OSD menu • Provide the administrator password: Barco - RHDM-2301 - User manual...
Page 38 When you have generated a new pincode by acci- dent, follow the instructions below to reinstall the license and the feature packs on the display unit. Figure 9: License OSD menu Barco - RHDM-2301 - User manual...
Page 39 It is recommended to deactivate the admin mode after removing the feature packs from the display unit. With the newly generated pincode, you can assign new/other licenses to the product on the Barco website (https://my.barco.com). Barco - RHDM-2301 - User manual...
Page 40: How To View Signals Connected To The Sdi Input Board
How to • Generate a new license file on my.barco.com. • Place the license file on a USB stick and connect the USB stick to all display units that need to be updated with the new licenses. • The following message appears when the update is successful and the display unit will operate normally immediately: 3.3 How to view signals connected to the SDI input board...
Page 41 ) the same button to toggle between the input options. The selected input is shown instantaneously. To change the active window, press ( ) the button of the other window. The other window will be activated instantaneously. Barco - RHDM-2301 - User manual...
Page 42 Figure 12: Zoom in of the status bar at the top of the screen NOTE Input settings are connected to the window. When input settings are changed for a specific window, they are stored instantaneously. Barco - RHDM-2301 - User manual...
Page 43: How To Change The Color Working Space
The newly selected color working space is applied instantaneously to the output on the screen and always applies to both windows. The color working space which is currently used to display the image on the screen, is shown in the status bar. Barco - RHDM-2301 - User manual...
Page 44: How To Visualize The Dark Levels
By increasing the value of the background, the information in the footroom of the video signal (below 0% video signal) becomes visible. clipping bright levels 100 % Visualize super bright Visualize Black super dark offset Black White Video signal 100 % clipping dark levels Barco - RHDM-2301 - User manual...
Page 45: How To Maximize Contrast
“0” on the numeric keypad to set the value to 0% press ( or ( to confirm the value • Move with the trackball down to the “Uniformity” and uncheck the box by pressing ( Barco - RHDM-2301 - User manual...
Page 46: How To Correct The Black Level
( or ( to select the value move with the trackball up or type “100” on the numeric keypad to set the value to 100% press ( or ( to confirm the value Barco - RHDM-2301 - User manual...
Page 47: How To Enable Native Interlaced Mode (Black Line Insertion)
The aspect ratio is applied instanta- neously to the window. • Press ( to open the aspect ratio mode selection toolbox. • Select the aspect ratio using the trackball. • Press ( or ( to confirm the selection. Barco - RHDM-2301 - User manual...
Page 48: How To Select A Color Channel
• Select the color channel Move with the trackball to highlight a color channel Press ( or ( to select a color channel. The setting is applied immediately to the selected window. Barco - RHDM-2301 - User manual...
Page 49: How To Show Two Input Signals Next To Each Other
3.11 How to show two input signals next to each other • Press ( WINDOW 1 WINDOW 2 WINDOW 1 WINDOW 2 SINGLE INPUT PAN&ZOOM DUAL VIEW Figure 17: View mode functionality pointer double arrow Barco - RHDM-2301 - User manual...
Page 50: How To Pan The Image
In the dual view mode , the two inputs are scaled to fit the new window size. The aspect ratio remains unchanged while up- or downscaling. 3.12 How to pan the image Track ball Figure 18: Location of buttons to pan the image Pointer – can be used for panning Barco - RHDM-2301 - User manual...
Page 51: How To Zoom In On The Image
• Pan the image to the appropriate position on the screen. • Press to select the magnifying glass. • Move the magnifying glass (using the trackball) to the location where the video signal has to be zoomed in. Barco - RHDM-2301 - User manual...
Page 52: How To Work With Presets
Basically it allows you to return to current active / last loaded preset. IMPORTANT Pressing will remove all uploaded 3D-LUTs and custom color spaces if they are not stored under a preset. Barco - RHDM-2301 - User manual...
Page 53: Loading/Storing & Erasing Presets
, or move with the trackball to the right to open the “Presets” menu • Move with the trackball to “Load”, “Store” or “Erase”, depending on the desired action and press or ( to open the submenu. Barco - RHDM-2301 - User manual...
Page 54 • Go to “Preset to load” to load either the factory preset or one of the 5 user presets. • Go to “Store Current Settings as” to store the current settings to one of the 5 user presets. • Go to “Preset to remove” to remove a selected preset. Barco - RHDM-2301 - User manual...
Page 55 How to Barco - RHDM-2301 - User manual...
Page 56: Preset Names And Filenames
<name>: The name of the preset as shown in the Load/Store submenu or when defining the name in the Store submenu. Example: So preset 1 with name 'Test 1' will be represented by a file with name '1-Test 1.pre'. Barco - RHDM-2301 - User manual...
Page 57: Transferring Presets Over Usb
'4-some_name.pre' then by invoking this option, presets 1 and 4 on the display will be replaced by those on the USB stick. Note that installing presets from a USB stick also reloads the current active preset. Barco - RHDM-2301 - User manual...
Page 58 • Select “Preset management” from the selection menu on the left hand side of the webpage. • Go to “Download presets” to download presets from the monitor into your PC. • Go to “Preset to upload” to upload a preset file from your PC to the monitor. Barco - RHDM-2301 - User manual...
Page 59 How to Barco - RHDM-2301 - User manual...
Page 60: How To Use The 3D-Lut Feature
Give the monitor 15s time to copy the file before removing the USB stick To use the new user 3D-LUT file, the file should be activated via the “Input settings” OSD menu or via the web interface. Barco - RHDM-2301 - User manual...
Page 61: Lut Upload Via Web Interface
Information” toolbox. Write down the IP address of the corresponding ethernet port. Open a browser window and type in the Address bar: “http://” + the IP address + “/” (e.g. “http://150.158.200.140”). The web interface of the display unit will open. Barco - RHDM-2301 - User manual...
Page 62 Browse for a User 3D-LUT file by clicking on the Browse... button. Note that the file can have any name and doesn't have to be name 3d.lut. Hit the upload button to upload the file to the monitor. Barco - RHDM-2301 - User manual...
Page 63: Lut Activation
• Select “User 3D LUT” from the selection menu on the left hand side of the webpage. • Check “LUT active on window 1” to activate the 3D-LUT file on window 1 • Check “LUT active on window 2” to activate the 3D-LUT file on window 2 Barco - RHDM-2301 - User manual...
Page 64: How To Upload New Software
(e.g. from 1.xx to 2.xx) while a minor software update is marked by a change in the second order digits (e.g. from 1.00 to 1.01). IMPORTANT It is not possible to downgrade the software version of the display unit with a major software revision. Barco - RHDM-2301 - User manual...
Page 65: Software Upload Via Ethernet
2. Connect with the pc to the display unit • Check the IP address that is assigned to the ethernet port. Press ( to open the “Display Information” toolbox. Write down the IP address of the corresponding ethernet port. Barco - RHDM-2301 - User manual...
Page 66 How to • Open a browser window and type in the Address bar: “http://” + the IP address + “/” (e.g. “http://150.158.200.140”). The web interface of the display unit will open. Barco - RHDM-2301 - User manual...
Page 67 • An authentification will be requested. To enter the Admin section: User name: “admin” Password: “admin117234” • When the valid user name and password are entered, the Admin section will be opened in the webpage. • Click on “Upgrade firmware” Barco - RHDM-2301 - User manual...
Page 68 If the upload of the new software would fail or would be interrupted, the display unit will reboot into the failsafe mode. The software version of the failsafe mode is the most recent software version that was uploaded success- fully. Barco - RHDM-2301 - User manual...
Page 69: Software Upload Via Usb
• The display unit will automatically start the software upload after 10 seconds unless the display unit is powered off or the USB stick is removed. When the display unit is busy with the upload of the new software, the following warning is shown on the screen: Barco - RHDM-2301 - User manual...
Page 70 USB stick at each power up or activation from hard standby. The display unit will then start the automated firmware update process. This does not happen after the reboot resulting from the software update! Barco - RHDM-2301 - User manual...
Page 71: Full Functionality Description
Figure 20: Overview of operational controls, indicators and OSD functionalities Different operation interfaces: 1) Status bar 2) OSD menu 3) Toolbox 4) Under Monitor Display bar / Picture Adjustment bar 5) Indicator lights 6) Control panel Barco - RHDM-2301 - User manual...
Page 72: Operational Mode Overview
Full functionality description 4.1.2 Operational mode overview The operational status of the display unit can be summarized in the figure below: Figure 21: Operational mode overview Barco - RHDM-2301 - User manual...
Page 73: Indicator Lights
Green and orange are both on – yellow color observed: Display unit performs a power over- load test. This occurs when the display unit is switching internally from the 100-240Vac power supply to the 24Vdc power supply. Barco - RHDM-2301 - User manual...
Page 74: Control Panel
The control panel allows the user to change a wide variety of settings in a clear and easy way. To apply the desired settings, the control panel is equipped with: • a USB port • press buttons • press and rotary knobs • a trackball Barco - RHDM-2301 - User manual...
Page 75: Usb Port
• Image adjustment bar visible: value that corresponds to the rotary knob is set to its default and calibrated value. 4.1.4.5 Trackball The trackball allows the operator to move the pointer or navigate in the menus. Barco - RHDM-2301 - User manual...
Page 76: Leds
Background, Picture, Saturation, Hue, Gain, OETF setting, Gamma setting, Gamma signal range, Gamma headroom level, Gamma footroom level, Monochrome setting, Any setting related to the R-G-B button (Color Channel Selection), Color work space selection, Deinterlace mode, Black correction, User 3D lut enable Barco - RHDM-2301 - User manual...
Page 77: Status Bar
• Input board that is used to process the selected input signal • Input detection overrule indicator • Input signal description • OETF • Color subsampling • Encoding • Scale mode • Aspect ratio Barco - RHDM-2301 - User manual...
Page 78: Invalid Signal Indicator
4.1.7 Under monitor display bar (optional) Figure 26: Screenshot UMD bar with two tally lights The Under Monitor Display (UMD) bar is shown at the bottom of the screen and has two tally lights. Barco - RHDM-2301 - User manual...
Page 79: Picture Adjustment Bar
(status bar or picture adjustment bar), the “arrow” is shown. The following actions can be done: • Pressing ( toggles between the pointer and the magnifying glass. • Pressing ( activates the “action” property. Use the trackball to execute the action. Barco - RHDM-2301 - User manual...
Page 80: Toolbox
The trackball can be used to navigate in the menu and to select an option and/or setting. Moving up/down with the track ball will allow scrolling through the different options. Moving the track ball Barco - RHDM-2301 - User manual...
Page 81: Web Interface
The web interface can be loaded via a standard web browser by browsing to the IP address of the ethernet port of the display unit that is connected to the local network. Barco - RHDM-2301 - User manual...
Page 82: Settings Control Panel And Toolbox
Access to the display unit to upload new display firmware in an USB connector automated way. Allows the operator to switch the display unit on/off and set the Control buttons display unit to preset and calibrated values. Barco - RHDM-2301 - User manual...
Page 83: Control Buttons
The panel and backlight are disabled. • sets the display unit into hard standby mode. The panel, backlight and electronics are disabled. Only the button re- mains functional. Barco - RHDM-2301 - User manual...
Page 84: Screen Select Button
Resets Background, Picture, Hue and Saturation and RGB/ Calibration Mono select to the preset values. The button is connected with button. The last selected/saved preset in the color working space toolbox will be selected by pressing ( Barco - RHDM-2301 - User manual...
Page 85: Fault Led
When the display unit starts-up from a hard standby status, the Fault LED lights up during the initialization. When the control panel is fully operational and when the display unit did not detect problems during start-up, the Fault LED will go out. Barco - RHDM-2301 - User manual...
Page 86: Image Adjustment Knobs
The LED above the knob will light up orange. • The image adjustments knobs Background, Saturation and Hue act only on the active window. The Picture knob acts on the entire screen.. Barco - RHDM-2301 - User manual...
Page 87: Function Keys
For SDI signals the range can be set to 4-1019 (maximal). For DVI signals the input range can be extended to 0-1023 (maximal). Barco - RHDM-2301 - User manual...
Page 88 • Footroom level: custom setting of the footroom level. IMPORTANT The Gamma settings apply to the selected window only. All signals processed by that window ( ) will be subjected to the gamma settings defined by the customer. Barco - RHDM-2301 - User manual...
Page 89: View Mode Button
The scan mode is shown in the status bar. mode Scan mode selection toolbox appears: The possible selection of scan modes are: • Non-scanning backlight: The scanning backlight mode is switched off. • Scanning backlight: The scanning backlight mode is activated. Barco - RHDM-2301 - User manual...
Page 90: Color Working Space Button
Store, the values will be saved into a new color working space. The name of this color space will be “custom”, followed by an incremental number. • Remove: Removes the selected color space. Only custom defined color working spaces can be removed. Barco - RHDM-2301 - User manual...
Page 91 • Press ( to open the color working space toolbox. • Navigate with the trackball to the top of the toolbox “Select color space”. • Press ( or ( to change the color working space. Barco - RHDM-2301 - User manual...
Page 92 The standard defined color working spaces cannot be removed. When the selected custom color working space is removed, the next color working space in the list will be applied to the display unit. Barco - RHDM-2301 - User manual...
Page 93: Scale Mode Button
• OverScan : The inner 96% of the image is shown on the screen. • ViewPort : Allows the user to maximize a 16:9 central portion of a video signal full screen (e.g. to maximize a letter box content). Barco - RHDM-2301 - User manual...
Page 94: Aspect Ratio Button
• 4:3 : Display the image with an aspect ratio of 4:3 on the screen. • Pixel Map : Display the image in the native pixel aspect ratio. For SD signals this is different than 4:3 (e.g. 720:576, 720:480, …) Barco - RHDM-2301 - User manual...
Page 95: Safe Area Marker Settings Button
• Hor. and Ver . define the graphics safe area relative to the aspect ratio markers or image borders as a decrease expressed in percent. Barco - RHDM-2301 - User manual...
Page 96: Settings Of The Safe Area Markers
4.2.5.9 Settings of the safe area markers 4.2.5.9.1 How to use safe area markers Track ball Figure 34: Location of buttons to set/change safe area markers • Press ( to enable/disable the safe area markers Barco - RHDM-2301 - User manual...
Page 97: How To Set Crosshairs
“viewport”. In the latter case the aspect ratio markers are defined as if the input signal has an aspect ratio of 16:9. 4.2.5.9.4 How to set action safe area • Press ( to open the safe area settings toolbox Barco - RHDM-2301 - User manual...
Page 98: How To Set Graphics Safe Area
Move with the trackball to highlight one of the numbers behind “Hor” or “Ver” Press ( or ( to select the highlighted number To change the number, move with the trackball or type a number with the numeric keypad Barco - RHDM-2301 - User manual...
Page 99: How To Change The Look Of The Safe Area Markers
• To change the color of the shadow: Move with the trackball and highlight the “Color” option under the shadow checkbox Press ( or ( to change the color of the shadow To change the color, move with the trackball. Barco - RHDM-2301 - User manual...
Page 100: Color Channel Selection Button
• Monochrome : Displays the selected color channel in grayscale. 4.2.5.11 Monochrome adjustment button Function Description Toggle between full color (Y’C ) and monochrome Monochrome adjustment (Y’ only). Barco - RHDM-2301 - User manual...
Page 101: Function Keys Tree
Full functionality description 4.2.5.12 Function keys tree Barco - RHDM-2301 - User manual...
Page 102 Full functionality description Barco - RHDM-2301 - User manual...
Page 103 Full functionality description Barco - RHDM-2301 - User manual...
Page 104 Full functionality description Barco - RHDM-2301 - User manual...
Page 105: Numeric Keypad
4.2.6.3 Special function key assignment Function key assignment Switch on/off black line insertion mode (Deinterlace mode in OSD menu) Swap field dominance of input channel 1 of the SDI input board Barco - RHDM-2301 - User manual...
Page 106: Navigation Pad
Menu button . The OSD menu is opened by pressing the menu button. Option button. Behaves like the right mouse button. This button calls for the options. E.g. choose between pan and zoom when working in Pan&Zoom-mode. Barco - RHDM-2301 - User manual...
Page 107: Settings Osd Menu
• Input detection: Settings related to the detection of the input signals. • Display settings: Shows information related to the calibration settings of the monitor. • Presets: Settings related to the storage of user settings in so-called presets Barco - RHDM-2301 - User manual...
Page 108: Osd Settings Menu
The status bar is considered to be an OSD menu and hides after the same time of inactivity if “hide after timeout” is checked. Wiggling the track ball activates the status bar. 4.3.3 UMD menu 4.3.3.1 UMD Main menu Barco - RHDM-2301 - User manual...
Page 109: Manual Settings
• Left lamp: Sets the color of the left lamp to the specified value. The possible values are: Red, Green, Amber, Off • Right lamp: Explanation of the setting are the same as for the Left lamp • Text: Explanation of the setting are the same as for the Left lamp Barco - RHDM-2301 - User manual...
Page 110: Gpi Settings Menu
The possible values are: Full, Half, 1/7, Dark. • Left lamp Controlled by: Selects the pin of the connector that controls the left lamp. The possible set- tings are: GPI 1, GPI 2, GPI 3 and GPI 4. Barco - RHDM-2301 - User manual...
Page 111: Input Settings
Input settings menu contains advanced settings that can influence the visualization of the selected input signals for window 1 and window 2. The settings that can be changed for the selected input signals are: General: Those settings apply for the 2 windows simultaneously Barco - RHDM-2301 - User manual...
Page 112 When this box is checked, the luminance uniformity correction is applied. The luminance uniformity correction can lead to a slight loss in contrast. Figure 37: Example of out of gamut indication (red squares have been replaced by yellow squares for black&white reproducability) Barco - RHDM-2301 - User manual...
Page 113 Autodesk. If such a 3D-LUT file is loaded into the monitor, the 3D-LUT can be enabled or disabled here. Second window: the explanations of the settings is the same as for window 1. Barco - RHDM-2301 - User manual...
Page 114: Resizer Settings Menu
Video Classic Data Sharp Normal Normal Sharp Sharpness Anti-aliasing Conservative Balanced Balanced Conservative Square Point Point Diamond Pixel Shape Linear Linear Nearest Linear Steepness Video Classic Data Preset Table 1: Resizer settings - presets Barco - RHDM-2301 - User manual...
Page 115 • Balanced (see figure below-b): This type of anti-aliasing is applied by most display units and results in a moderate setting. • Conservative (see figure below-c): This setting is preferred for video signals and results in a strong reduction of anti-aliasing effects while preserving good sharpness of the image. Barco - RHDM-2301 - User manual...
Page 116 Steepness: Sets the type of interpolation which is used for determining the values at the pixels of the resized image. Barco - RHDM-2301 - User manual...
Page 117 • Nearest (see figure below-c): No interpolation is applied. Down to sub-pixel level, the value of a sub-pixel is equal to the value of the nearest sampling point. Figure 39: “Steepness” settings in the OSD submenu “Resizer settings” Barco - RHDM-2301 - User manual...
Page 118: User 3D-Lut Menu
It is similar to a hardware / GPU alike rendering of 3D- LUT cube. Trilinear interpolations interpolates independently for R, G and B and is more similar to a software / CPU alike rendering. Barco - RHDM-2301 - User manual...
Page 119: Input Detection
• Dual link 1-AB: Submenu which allows verification of the input signal and adjustment of the input detection settings in case of a dual link SDI input on 1-AB. 4.3.5.2 Single link 1-A & 1-B Barco - RHDM-2301 - User manual...
Page 120 • Bit depth: sets the bit depth of the video signal. Possible settings are: 8, 10 or 12. • Video framing: sets the video framing of the video signal: Possible options are: Interlaced, Pro- gressive or Segmented. Barco - RHDM-2301 - User manual...
Page 121: Dual Link 1-Ab Menu
“Override signal detection” option. automatic detection of the input signal input signal is set manual: override signal detection is checked Barco - RHDM-2301 - User manual...
Page 122: Display Settings
This is a big problem in the current color industry but unfortunately it's not solved yet in a standardized way. In the lack of a better color system, Barco has done a perceptual matching to a Barco CRT (CVM model) and implemented this as a preset.
Page 123: Presets
Full functionality description • When the ' Barco CVM ' setting is chosen, the complete RHDM color space is changed so as to look perceptually alike a well-calibrated CVM monitor. In this mode we don't guarantee compli- ance to a technical specification.
Page 124: Load Presets
'Load failed': The loading failed because of another reason <blank>: The feedback/status field is by default blank and is also again blank after 15s. This means that its information is only shown for about 15s. Barco - RHDM-2301 - User manual...
Page 125: Store Presets
'Preset stored’: Indicates the preset was stored. 'Store failed': The storing failed. <blank>: The feedback/status field is by default blank and is also again blank after 15s. This means that its information is only shown for about 15s. Barco - RHDM-2301 - User manual...
Page 126: Erase Presets
This menu is mainly for maintenance purposes. 4.3.9 Temperature menu In this OSD menu, the temperature of different components is shown. Barco - RHDM-2301 - User manual...
Page 127: Faults And Warnings
This menu lists all faults and warnings which have occurred. When a fault occurs, the “FAULT” LED on the control panel and the “Cal/Err” LED on the bezel will light up red. To solve a fault or warning, please consult the troubleshooting section in the addendum. Barco - RHDM-2301 - User manual...
Page 128: License Menu
• Generate new Pincode: menu item to generate a new pincode. Please read the instructions in the section “how to change the license connected to your display unit” carefully. This item can only be unlocked by entering the “Admin mode” of the OSD menu. Barco - RHDM-2301 - User manual...
Page 129 As a result, you will not be able to use the display unit until you have generated a new pincode on my.barco.com. Please follow the instructions in the section “how to change the license connected to your display unit” to install the new pincode on your display unit.
Page 130: Osd Menu Tree
Full functionality description 4.3.12 OSD menu tree Barco - RHDM-2301 - User manual...
Page 131 Full functionality description Barco - RHDM-2301 - User manual...
Page 132 Full functionality description Barco - RHDM-2301 - User manual...
Page 133: Settings Web Interface
Figure 40: Web interface – home page Open a browser window and type in the Address bar: “http://” + the IP address + “/” to connect to the display unit via the web interface. Barco - RHDM-2301 - User manual...
Page 134: Input Selection Page
The input selection page allows the setting of the input selection for window 1 and window 2, in analogy with the “Input selection” toolbox. The current setting is shown when the page is opened or refreshed. Press “Apply” to send changes on the web page to the display unit. Barco - RHDM-2301 - User manual...
Page 135: Color Processing Page
Full functionality description 4.4.3 Color processing page Barco - RHDM-2301 - User manual...
Page 136 • YCbCr Channel selection – Monochrome: Same setting as applied by pressing ( ) the button. The current setting is shown when the page is opened or refreshed. Press “Apply” to send the changes on the web page to the display unit. Barco - RHDM-2301 - User manual...
Page 137: User 3D Lut Page
Full functionality description 4.4.4 User 3D LUT page Figure 42: User 3D LUT page Barco - RHDM-2301 - User manual...
Page 138 It is similar to a hardware / GPU alike rendering of 3D-LUT cube. Trilinear interpolations interpolates independently for R, G and B and is more similar to a software / CPU alike rendering. Barco - RHDM-2301 - User manual...
Page 139: Scan Mode Page
Activate or deactivate the scanning backlight option. This setting is applied to window 1 and window 2 simultaneously. The current setting is shown when the page is opened or refreshed. Press “Apply” to send changes on the web page to the display unit. Barco - RHDM-2301 - User manual...
Page 140: Umd Page
Full functionality description 4.4.6 UMD page Figure 45: UMD web page Barco - RHDM-2301 - User manual...
Page 141 • Signal high: Select the color of the right lamp if the signal at the selected pin is high (Red, Green, Amber, Off) UMD text • Controlled by: Select the pin to control the color of the text on the UMD bar (GPI1, GPI2, GPI3 or GPI4) Barco - RHDM-2301 - User manual...
Page 142 Amber, Off) • Signal high: Select the color of the text if the signal at the selected pin is high (Red, Green, Amber, Off) Press “Apply” to send the new settings to the display unit. Barco - RHDM-2301 - User manual...
Page 143: Preset Management Page
Full functionality description 4.4.7 Preset Management page Barco - RHDM-2301 - User manual...
Page 144 Full functionality description Figure 46: Preset Management page Barco - RHDM-2301 - User manual...
Page 145: System Info Page
• Serial number • Version of the software • Build – date of the release of the software version The current setting is shown when the page is opened or refreshed and cannot be changed. Barco - RHDM-2301 - User manual...
Page 146: Power Management Page
Full functionality description 4.4.9 Power management page Figure 48: Power management web page Activates or deactivates the standby functionality (soft standby). Press “Apply” to send changes on the web page to the display unit. Barco - RHDM-2301 - User manual...
Page 147: Documentation Page
4.4.10 Documentation page Figure 49: Documentation web page This web page contains the weblink to the documentation explorer at my.barco.com. You can use the same ID and password as for the licensing of the display unit to access the documentation online.
Page 148: Support Page
4.4.11 Support page Figure 50: Support web page On this web page, the contact details of the Barco support teams in EMEA (Europe, Middle East & Asia) and the United States are given. Do not hesitate to contact them for technical assistance when necessary.
Page 149: Admin
• User name: admin • Password: admin117234 • This web page allows the user to update the software via the ethernet port. Please consult the “how to upload new software” for more details about this functionality. Barco - RHDM-2301 - User manual...
Page 150: Video Signal Processing
576i: EBU 3213 L to RGB Rec.709 Rec.709 SMPTE 240M Step 2 RGB to R’B’G’ ITU-R BT.601 (Rec. 601) Rec.709 SMPTE 240M Step 3 R’G’B’ to Y’C Table 2: Standards used for video signal generation Barco - RHDM-2301 - User manual...
Page 151 The Picture setting does not have any influence on the conversion of the video signal to the image on the screen. The Picture setting only drives the power of the backlight, and consequently, the brightness of the image. Barco - RHDM-2301 - User manual...
Page 152: General Definition Oetf
• b (the voltage up to which the transfer curve is linear) • b (the slope of the linear part: b =V/L ) • g (the gamma correction or exponent of the power function) Barco - RHDM-2301 - User manual...
Page 153: Video Encoding Functions
In general, we can write any of these encoding standards with the formula: ≤ < ⎧ ⎨ − − ⎩ ≤ ≤ − where 5.3 Video encoding functions 5.3.1 Rec.709 Figure 53: L-V’ for Rec.709 ≤ < ⎧ ⎨ − ≤ ≤ ⎩ Barco - RHDM-2301 - User manual...
Page 154: Smpte 240M
Figure 54: L-V’ for xvYCC xvYCC (based on ITU1361) is identical with Rec.709 in the legal range of Rec.709 (here the interval [0..1], but it extends the Rec.709 curve also outside the legal range: Barco - RHDM-2301 - User manual...
Page 155: Effective Gamma
0.52 (see figure below). We call this “best fit” the “ effective gamma ” . Figure 55: The Rec.709 encoding equation fitted with a power function Barco - RHDM-2301 - User manual...
Page 156: Rendering Intent
2.2, but rather to an “effective gamma” of around 2.0 (as discussed in the section “effective gamma” and illustrated in the figure below). Figure 56: The inverse of the Rec.709 encoding function fitted with a power function Barco - RHDM-2301 - User manual...
Page 157 “rendering intent”: the video is encoded in such a way (exponent 0.45, effective gamma 0.52), that when a CRT decodes it (with a gamma of 2.2-2.5), the end result has an end-to-end transfer gamma of around 1.2. Barco - RHDM-2301 - User manual...
Page 158: Selection Of Oetfs In The Rhdm
The rendering intent used in the display unit ensures that at a luminance level of 100 cd/m the lowest step in the Pluge pattern are just noticeable. Barco - RHDM-2301 - User manual...
Page 159 Background and the dark offset of the LCD panel. γ ⎡ ⎤ ⎛ ⎞ ⎜ ⎜ ⎟ ⎟ − ⎢ ⎥ ⎝ ⎠ ⎣ ⎦ inrw , i = R,G,B NOTE Increasing G or B will result in clipping of the highlights. Barco - RHDM-2301 - User manual...
Page 160: Terminology
8-bit steps. clipping bright levels 100 % Visualize super bright Visualize Black super dark offset Black White Video signal 100 % clipping dark levels Figure 57: Background control Barco - RHDM-2301 - User manual...
Page 161 For 10 bit signals, the headroom is defined between level 940 and level 1019. The hue control is similar to the hue setting on a CRT display unit. Hue affects the C and C components of the Y’C according to the following formula: Barco - RHDM-2301 - User manual...
Page 162 Nr of active lines + Scanning format + Vertical frequency e.g.: 720p23.98 can be translated to a format that has a resolution of 1280x720, a progressive scan format with a vertical frequency of 23.98 Barco - RHDM-2301 - User manual...
Page 163 Since the point may not be on a lattice point, the lattice values must be interpolated. Cubes may be of various sizes and bit depths. Often 17x17x17 cubes are used as 3D-LUTs. Barco - RHDM-2301 - User manual...
Page 164 Not only the white level, but also the black level is affected when the picture is adjusted. The value of the picture is expressed in cd/m for 100% video signal. Barco - RHDM-2301 - User manual...
Page 165 The RGB notation is used when the signals are proportional to the tristimulus values X, Y and Z. The R’G’B’ notation is used whenever we describe the gamma-corrected RGB components (using a power function such as e.g. ITU.709). Barco - RHDM-2301 - User manual...
Page 166 OSD menus. The main difference is that Picture drives the power of the backlights, while Video gain is a multiplication factor applied on the value of the video signal V . Increasing gain results in clipping of the highlights. Barco - RHDM-2301 - User manual...
Page 167 D65 (close to 6504 K) is the EBU and SMPTE broadcast standard. Color temperatures of 5400-5600 K are used in film post production and color temperatures of 9300 K are used in Asia (ARIB recommendation). Barco - RHDM-2301 - User manual...
Page 168: Addendum
Colors & Grayscale • Without dithering Color depth: 10 bit Grayscales: 1024 • With dithering Color depth: 12 bit Grayscales: 4096 7.1.1.1.5 Viewing angle • For contrast > 10:1 • Horizontal: 85° • Vertical: 85° Barco - RHDM-2301 - User manual...
Page 169: Reflection
When the luminance uniformity correction is active, the effective contrast ratio may decrease. 7.1.1.1.9 Black level • For HDSDI level 1019 calibrated at 100 cd/m , gamma=2.35, the black level is typical: 0.12 cd/ Barco - RHDM-2301 - User manual...
Page 170: Resolution
• Maximum 12 defect dark or defect intermittent subpixels are allowed • Maximum 0 sets of two defect bright subpixels with same color at distance 6.5mm are allowed. (for each color) Barco - RHDM-2301 - User manual...
Page 171 • Maximum 5 clusters of 2 or more defect bright subpixels within a 5x5 pixel region are allowed. • Following table summarizes these conditions: • Following table summarizes the cosmetic specification (dust, impurities, scratches etc): Barco - RHDM-2301 - User manual...
Page 172: Image Specifications
Light Bluish Green 29.8 2087 4157 EBU 6 Light Violet 30.1 1813 5207 EBU 7 Foliage 3248 4974 EBU 8 Medium Red 19.4 1505 5329 EBU 9 Medium Green 1791 3706 EBU 10 Medium Blue 17.2 Barco - RHDM-2301 - User manual...
Page 173 (Relative to screen centre) 1 (screen centre) 2 and 5 ± 0.4H 9 and 12 ± 0.4H 3, 4, 6 and 7 ± 0.35H ± 0.2H 8, 10, 11 and 13 ± 0.4W ± 0.4H Barco - RHDM-2301 - User manual...
Page 174 0015 Typical: The tolerances apply for a temperature of 25°C. Luminance uniformity on black For all points, the measured luminance value deviates less than 50% from the luminance value measured at the center point. Barco - RHDM-2301 - User manual...
Page 175: Power Supply Specification
7.1.1.3.5 Earth / ground • Protective Earth = mechanical ground = chassis ground • Secondary electrical ground is connected to the chassis ground. 7.1.1.3.6 Input protection • T6.3 A / 250V internal line fuse Barco - RHDM-2301 - User manual...
Page 176: Connectors
7.1.1.4 Connectors 7.1.1.4.1 Input and output options 13 14 SDI input board Ethernet RJ45 (2 ports) SDI input board (optional) 24 Vdc in Optional slot 100 – 240 Vac in Optional slot Earth stud Barco - RHDM-2301 - User manual...
Page 177 • 2 USB ports (hosts) • 2 Ethernet (RJ 45) connectors Audio • First audio stereo pair out Power supply inputs • AC Power connector (IEC): 100-240 Vac • DC Power connector (XLR): 24 Vdc Barco - RHDM-2301 - User manual...
Page 178: Signal Inputs
In order to meet the EMI/EMC specifications as described in the environmental specifications paragraph, shielded network cables (Ethernet, Tally) should be used. 7.1.1.4.2 Signal inputs Connectors SDI module • 4 BNC connectors 7.1.1.4.3 Control RS485 Tally serial connector • RJ45 Pinning Signal Barco - RHDM-2301 - User manual...
Page 179 Addendum GPI Tally parallel connector • RJ45 Pinning Signal GPI 1 GPI 2 GPI 3 GPI 4 Barco - RHDM-2301 - User manual...
Page 180: Power
• Type A: host • Data rate: USB 1.1 – Full speed 7.1.2 Mechanical specifications 7.1.2.1 Dimensions Dimension Front (mm) Rear (mm) Total (mm) Width Height (+control panel) Depth 7.1.2.2 Weight • 20.5 kg Barco - RHDM-2301 - User manual...
Page 181: Construction Drawings
Addendum 7.1.2.3 Construction drawings Figure 62: RHDM-2301 Front view (metric units (mm)) Barco - RHDM-2301 - User manual...
Page 182 Addendum Figure 63: RHDM-2301 Top view (metric units (mm)) Barco - RHDM-2301 - User manual...
Page 183 Addendum Figure 64: RHDM-2301 Rear view (metric units (mm)) Barco - RHDM-2301 - User manual...
Page 184 Addendum Figure 65: RHDM-2301 Side view (metric units (mm)) Barco - RHDM-2301 - User manual...
Page 185 Addendum Figure 66: RHDM-2301 Auxiliary view (front) Barco - RHDM-2301 - User manual...
Page 186: Finishing
Addendum Figure 67: RHDM-2301 Auxiliary view (back) 7.1.2.4 Finishing Front • Priming coat: Beltical filler P1F6 • Top coat: 2-component purethane paint. • Color: Graphite grey RAL7024 Barco - RHDM-2301 - User manual...
Page 187: Environmental Specifications
• Color: Black RAL9005 • Screening: Silkscreening (white) 7.1.3 Environmental specifications 7.1.3.1 Random vibration • Barco Truck simulation procedure for random vibrations - 1gRMS / 10-500Hz for all three axes 7.1.3.2 Functional shock Operating: • 25 g – 6 ms •...
Page 188: En Norms
1 kV on lines & earth Level 3 EN 61000-4-5 Surges 1.5 kV Signal ports if out- door 1 kV line to line 2 kV line to earth Level 3 EN 61000-4-6 Conducted Common Mode 3 V level 2 Barco - RHDM-2301 - User manual...
Page 189: Fcc Norms
• Operating & storage: max 95% @ 35°C (95°F) 7.1.3.6 Altitude/Low pressure • Operating nom. 3000 m • Storage nom. 10000 m 7.1.3.7 Acoustic noise Location of measurements: at 1m of the display unit. Figure 68: Setup to measure noise levels Barco - RHDM-2301 - User manual...
Page 190: Dust Class
Unit meets following safety requirements and is labeled accordingly: • CE / EN 60950-1 • DEMKO / EN 60950-1 • IEC60950-1 • UL 60950-1 • C-UL CSA C22.2 No 60950-1 7.1.4.3 Workmanship • According to ANSI/IPC A-610A level II Barco - RHDM-2301 - User manual...
Page 191: Compliancy
7.2.1.1 Signal input • 4 BNC connectors 2 Inputs 2 Loop-through outputs • Accepts the input signals: 2 x SDI 2 x HDSDI 2 x 3Gb/s (optional) 1 x Dual link (optional) • Automatic input detection Barco - RHDM-2301 - User manual...
Page 192: Single Link Sd And Hd Timings
Addendum 7.2.1.2 Single link SD and HD timings Table 4: Single link SD and HD timings NOTE The SD and HD timings are supported by both the RHDM/B and the RHDM/P. Barco - RHDM-2301 - User manual...
Page 193: Dual Link Hdsdi Timings (Optional)
7.2.1.3 Dual link HDSDI timings (optional) Table 5: Dual link HDSDI timings NOTE SMPTE 372M Dual link HDSDI timings are supported by the RHDM/P. 1280x720 4:4:4 timings are not defined by any standard, and thus not supported. Barco - RHDM-2301 - User manual...
Page 194: 3Gb/S Timings (Optional)
NOTE The SMPTE 425M 3Gb/s timings are supported by the RHDM/P. All level-A and level-B dual link timings are supported by the RHDM/P. The level-B dual stream timings are not supported by the RHDM/P. Barco - RHDM-2301 - User manual...
Page 195: Latency
Display and backlight scan mode. The latency is measured in the middle of the screen according to EBU Tech 3325. The values presented in the table are typical values that can change with subsequent software updates. Barco - RHDM-2301 - User manual...
Page 196: Oetf (Opto-Electrical Transfer Function)
Video range: • 64-940 (legal Y’C • 64-1019 (Y’C with headroom) • 4-940 (Y’C with footroom) • 4-1019 (Y’C full range, R’G’B’ full range) • 0-1023 (DVI RGB) • 0-4095 (XYZ full range) • Custom Barco - RHDM-2301 - User manual...
Page 197: Color Spaces
• Custom in [x, y] The calibrated luminance (picture setting) is 100 cd/m2. This is the luminance of the maximum allowed video level in the selected video range. Selectable color spaces (primaries): • Rec.709 Barco - RHDM-2301 - User manual...
Page 198 RHDM and is not mentioned here. Table 9: Color space primaries The following table summarizes the recommended color space and white point for different signals. “R” stands for recommended and “a” stands for alternative. Table 10: Recommended color spaces Barco - RHDM-2301 - User manual...
Page 199: Mutual Effects Of Scaling And Aspect Ratio Settings
• For 16:9 signal formats and when the safe area markers are defined relative to the aspect ratio markers (1920x1080, 1280x720 and Wide SD): Table 12: Safe area markers defined for 16:9 formats and relative to ARM Barco - RHDM-2301 - User manual...
Page 200 SMPTE for safe area markers relative to the aspect ratio marker. 4:3 signal safe area markers note: The standards only define safe areas for 4:3 signals for retention of the 14:9 central zone. The Barco - RHDM-2301 - User manual...
Page 201: Installation
Depending upon the used means of transport, the written protest is subject to different time-rules: • by sea: the protest has to be issued against the captain and/or ship within 3 days of the delivery of the goods. Barco - RHDM-2301 - User manual...
Page 202: Storage
Width: 341 mm Length: 733 mm Total weight: 24.3 kg • An optional flight case is available for flexible demo purposes: contact Barco for more details. 7.8.2.5 Repack instructions CAUTION To repack the display unit, please use the original packaging material.
Page 203 Addendum • Mount the Barco stand and the control panel to the display unit. • Place one of the protective covers on the bottom of the box. Verify that the opening in the pro- tective cover, shown on the bottom of the image, is placed against the bottom side of the box.
Page 204 • Place the other protective cover on top. Verify that the protective cover is placed on the display unit in exactly the same way as the first protective cover was placed in the box. Include all orig- Barco - RHDM-2301 - User manual...
Page 205 User manual and guiding sheets. There is a place at the bottom side foreseen to store these items. • Seal the box with tape. • Place the box upright (on its bottom side) for transport. Barco - RHDM-2301 - User manual...
Page 206: Mounting Instructions
The display unit is delivered with the Barco stand already mounted. With the Barco stand, the display unit can be placed up-right in a safe way. The Barco stand is mounted on the VESA compatible mounting positions at the back side. The mounting positions are spaced by 100mm horizontally and 100mm vertically (see figure above).
Page 207: Install The Barco Stand
• Place the display unit with the front side on a horizontal, flat and stable table, covered with bub- ble wrap or a similar protective material. • Mount the Barco stand on the bottom 4 VESA mounting positions with the knurled screws pro- vided with the stand.
Page 208 Addendum Figure 71: Mounting of the Barco stand – rear view Barco - RHDM-2301 - User manual...
Page 209: Tiltable Stand (Option)
15° Figure 72: Variation of angles that can be reached with the tiltable stand To mount and/or to remove the stand, please follow the instructions as documented for the Barco stand. Figure 73: Rear side of the display unit with mounted tiltable stand...
Page 210: Control Panel
• Place the display unit with the front side on a horizontal, flat and stable table, covered with bub- ble wrap or a similar protective material. • Remove the Barco stand (if necessary) • Unplug the cables that connect the control panel to the display unit.
Page 211 Addendum • Mount the Barco stand (if necessary) Figure 75: Bottom view of the control panel and the display unit Barco - RHDM-2301 - User manual...
Page 212: Rack Mounting
Figure 76: Rack mounting of the display unit The display unit can be mounted in a standard 19 inch rack by using the rack brackets and the cover bracket. The display unit can be mounted with or without the control panel. Barco - RHDM-2301 - User manual...
Page 213 • Tighten the bolts to the rack to secure the display unit in the rack. CAUTION The cover bracket is necessary to allow sufficient ventilation of the display unit. Barco - RHDM-2301 - User manual...
Page 214 Addendum Side view Front view Top view Figure 77: Front, top and side view of the mounted rack and cover brackets Barco - RHDM-2301 - User manual...
Page 215 Addendum Figure 78: Installed display unit with control panel in an 19 inch rack Barco - RHDM-2301 - User manual...
Page 216: Connecting Signals And Power To The Display Unit
“Full functionality description” for more information. CAUTION Before connecting the display unit to mains, check if the power source voltage corresponds to the mains voltage marked on the identification label on the display. Barco - RHDM-2301 - User manual...
Page 217 To power-up the display unit: • Place the display unit up-right (on the Barco stand) or mount the display unit safely into a rack. • Connect the power cord of the appropriate power supply to the power connector at the back of the display unit.
Page 218: Instructions To Connect The Control Panel To The Display Unit
• Connect the USB cable (1) and the power cable (2) on the backside of the display unit and con- nect the other end on the back of the control panel. • Place the cables in the cable holders and provide enough cable length at both ends. Barco - RHDM-2301 - User manual...
Page 219: Cleaning Instructions
• “Nothing observed on the screen” fault finding tree: The display unit is powered but no image is shown on the screen. • “Verify input signal” fault finding tree: The display unit works correctly, but the applied input sig- nal is not recognized or not displayed on the screen. Barco - RHDM-2301 - User manual...
Page 220: Fault And Warning List
Addendum • Image displayed on the screen is distorted, shows bands or stripes. In this case something is wrong with the display unit. Contact Barco or your sales representative. 7.10.2 Fault and warning list All faults and warnings are shown in the “Faults and warnings” OSD submenu. The number of faults and warnings are generated with respect to a node.
Page 221 The warnings under node “1” can easily be solved by the user. These warning are related to the operation of the display unit out of the calibrated range. These warnings are considered as normal Barco - RHDM-2301 - User manual...
Page 222 The faults and warnings under node “3” and “4” cannot be solved by the customer. Please contact Barco customer service or your local sales representative for help. Barco - RHDM-2301 - User manual...
Page 223: No Power" Fault Finding Tree
Addendum 7.10.3 "No power" fault finding tree Barco - RHDM-2301 - User manual...
Page 224 Addendum Figure 81: “No power” fault finding tree Barco - RHDM-2301 - User manual...
Page 225: Nothing Observed On The Screen" Fault Finding Tree
Addendum 7.10.4 "Nothing observed on the screen" fault finding tree Barco - RHDM-2301 - User manual...
Page 226 Addendum Figure 82: “Nothing observed on the screen” fault finding tree Barco - RHDM-2301 - User manual...
Page 227: Verify Input Signal" Fault Finding Tree
Contact Barco Set the status bar to “Always visible” in the OSD menu Figure 83: “Verify input signal” fault finding tree Barco - RHDM-2301 - User manual...
Page 228: List Of Spare Parts
RHDM Power Interface Board RHDM HDSDI Input Board RHDM Communication Board RHDM Control box RHDM Accessory kit • RHDM Accessory kit – K5031250 Knobs VESA screws User manual USB cable Control box power cable Barco - RHDM-2301 - User manual...
Page 229: Contact Information
Phone: +32 56 262 350 Fax: + 32 56 233 013 United States Email: Helpdesk.BCDUSA@barco.com Phone: +1 866 992 2726 Fax: + 1 678 475 8124 Web sites Public Web site: http://www.barco.com Partner Web site: http://my.barco.com Barco - RHDM-2301 - User manual...
Page 230: Appendix A - Software License
GNU General Public License is intended to guarantee your freedom to share and change free software--to make sure the software is free for all its users. This General Public License applies to most of the Free Software Foundation's software and to any other program Barco - RHDM-2301 - User manual...
Page 231 Activities other than copying, distribution and modification are not covered by this License; they are outside its scope. The act of running the Program is not restricted, and the output from the Program is covered only if its contents constitute a work based on the Program (independent of Barco - RHDM-2301 - User manual...
Page 232 Thus, it is not the intent of this section to claim rights or contest your rights to work written entirely by you; rather, the intent is to exercise the right to control the distribution of derivative or collective works based on the Program. Barco - RHDM-2301 - User manual...
Page 233 License. Therefore, by modifying or distributing the Program (or any work based on the Program), you indicate your acceptance of this License to do so, Barco - RHDM-2301 - User manual...
Page 234 9. The Free Software Foundation may publish revised and/or new versions of the General Public License from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns. Barco - RHDM-2301 - User manual...
Page 235: Gnu Library General Public License
Copyright (C) 1991 Free Software Foundation, Inc. 51 Franklin St, Fifth Floor, Boston, MA 02110-1301 Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. Barco - RHDM-2301 - User manual...
Page 236 Most GNU software, including some libraries, is covered by the ordinary GNU General Public License, which was designed for utility programs. This license, the GNU Library General Public License, applies to certain designated libraries. This license is quite different from the ordinary Barco - RHDM-2301 - User manual...
Page 237 Library or a portion of it, either verbatim or with modifications and/or translated straightforwardly into another language. (Hereinafter, translation is included without limitation in the term "modification".) Barco - RHDM-2301 - User manual...
Page 238 License, and its terms, do not apply to those sections when you distribute them as separate works. But when you distribute the same sections as part of a whole which is a Barco - RHDM-2301 - User manual...
Page 239 Library (because it contains portions of the Library), rather than a "work that uses the library". The executable is therefore covered by this License. Section 6 states terms for distribution of such executables. Barco - RHDM-2301 - User manual...
Page 240 Verify that the user has already received a copy of these materials or that you have already sent this user a copy. Barco - RHDM-2301 - User manual...
Page 241 11. If, as a consequence of a court judgment or allegation of patent infringement or for any other reason (not limited to patent issues), conditions are imposed on you (whether by court order, agreement or Barco - RHDM-2301 - User manual...
Page 242 For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will be guided by the two goals of preserving the Barco - RHDM-2301 - User manual...
Page 243 INACCURATE OR LOSSES SUSTAINED BY YOU OR THIRD PARTIES OR A FAILURE OF THE LIBRARY TO OPERATE WITH ANY OTHER SOFTWARE), EVEN IF SUCH HOLDER OR OTHER PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. END OF TERMS AND CONDITIONS Barco - RHDM-2301 - User manual...
Page 244 Currently the monitor supports three types of user 3D-LUT files: Truelight, Cinespace and Autodesk. Below you can find a sample of a valid file for each of the supported types: Autodesk sample Truelight sample Barco - RHDM-2301 - User manual...
Page 245 Addendum Cinespace sample Barco - RHDM-2301 - User manual...
Page 246: Abbreviations And Acronyms
Abbreviations and acronyms 8 Abbreviations and acronyms °C Degrees Celsius °F Degrees Fahrenheit ActEv Actions + Events (name of a Barco software product) Automatic Gain Control Automatic Light Control AMLCD Active Matrix Liquid Crystal Display ANSI American National Standards Institute...
Page 247 Electronic Industries Association EMI / EMC Electromagnetic Interference / Electromagnetic Compatibility European Norms EOTF Electro Optical Transfer Function Electrostatic Discharge Full Duplex FLIR Forward Looking Infrared FPDM Flat Panel Display Measurements General Purpose Interface Half Duplex Barco - RHDM-2301 - User manual...
Page 248 International Standard Organization Indium Tin Oxide International Telecommunications Union kilogram Luminance Liquid Crystal Display LCD Flicker Compensation Line Replaceable Unit Look Up Table Measure of illumination (lumens per meter squared) millimeter milliseconds MTBF Mean-Time-Between-Failures MTTR Mean-Time-To-Repair Barco - RHDM-2301 - User manual...
Page 249 Rack Mount Rotator RoHS Restrictions of Hazardous Substances Radiated Susceptibility Serial Digital Interface SDSDI Standard Definition Serial Digital Interface Symbol Generator SMPTE Society of Motion Picture and Television Engineers Separate Sync STANAG Standardization Agreement Barco - RHDM-2301 - User manual...
Page 250 SXGA Super eXtended Graphics Array To Be Confirmed To Be Defined To be Measured To Be Tested Transistor Transistor Logic Under Monitor Display Volts Direct Current VESA Video Electronics Standards Association VESA Mount Watt Barco - RHDM-2301 - User manual...
Page 251: Table Of Contents
2.3 Switch on the display unit ..............17 2.4 How to register the display unit............19 2.5 Concepts of operation ..............33 2.6 How to setup the display unit............36 3 How to ..................37 Barco - RHDM-2301 - User manual...
Page 252 4.1.2 Operational mode overview ............... 72 4.1.3 Indicator lights................. 73 4.1.4 Control panel ................... 74 4.1.4.1 Overview operation control panel ..........74 4.1.4.2 USB port ................75 4.1.4.3 Press buttons ............... 75 4.1.4.4 Press and rotary knobs ............75 Barco - RHDM-2301 - User manual...
Page 253 4.2.5.9.6 How to change the look of the safe area markers ....99 4.2.5.10 Color channel selection button ..........100 4.2.5.11 Monochrome adjustment button........... 100 4.2.5.12 Function keys tree.............. 101 4.2.6 Numeric keypad ................105 Barco - RHDM-2301 - User manual...
Page 254 4.4 Settings web interface ..............133 4.4.1 Home page of the display unit............133 4.4.2 Input selection page ................134 4.4.3 Color processing page ..............135 4.4.4 User 3D LUT page ................137 4.4.5 Scan mode page ................139 Barco - RHDM-2301 - User manual...
Page 255 7.1.1.1.9 Black level ..............169 7.1.1.1.10 Resolution ..............170 7.1.1.1.11 Pixel defects and cosmetic specs ........170 7.1.1.2 Image specifications............. 172 7.1.1.2.1 Response time .............. 172 7.1.1.2.2 Tolerances ..............172 7.1.1.3 Power supply specification............. 175 Barco - RHDM-2301 - User manual...
Page 256 7.1.3.8 Dust class ................190 7.1.4 Other specifications .................190 7.1.4.1 MTBF ................. 190 7.1.4.2 Safety ................190 7.1.4.3 Workmanship ..............190 7.1.4.4 Compliancy ................. 191 7.2 Timings ..................191 7.2.1 SDI input board ................191 Barco - RHDM-2301 - User manual...
Page 257 7.8.2.5 Repack instructions .............. 202 7.8.3 Mounting instructions...............206 7.8.3.1 Barco stand ................ 206 7.8.3.1.1 Barco stand ..............206 7.8.3.1.2 Remove the Barco stand ..........206 7.8.3.1.3 Install the Barco stand ........... 207 7.8.3.2 Tiltable stand (option) ............209 7.8.3.3 Control panel ..............210 7.8.3.4 Rack mounting ..............
Page 258 Figure 26: Screenshot UMD bar with two tally lights ............. 78 Figure 27: Screenshot Picture adjustment bar ............. 79 Figure 28: Control panel ..................82 Figure 29: Control buttons ..................83 Figure 30: Fault LED ....................85 Barco - RHDM-2301 - User manual...
Page 259 Figure 60: Pixel and subpixel definition ..............170 Figure 61: Location of connectors ................177 Figure 62: RHDM-2301 Front view (metric units (mm)) ..........181 Figure 63: RHDM-2301 Top view (metric units (mm)) ..........182 Figure 64: RHDM-2301 Rear view (metric units (mm)) ..........183 Figure 65: RHDM-2301 Side view (metric units (mm)) ..........184...
Page 260 Table of contents Figure 68: Setup to measure noise levels ..............189 Figure 69: Display unit mounted on Barco stand – VESA mount positions .......206 Figure 70: Mounting of Barco stand – screw location ...........207 Figure 71: Mounting of the Barco stand – rear view ............208 Figure 72: Variation of angles that can be reached with the tiltable stand ......209...
Page 261 Table of contents End of document Barco - RHDM-2301 - User manual...
Page 262 Table of contents Barco - RHDM-2301 - User manual...

Barco RHDM-2301 User Manual

1 Introduction

2 First Operation

3 How to

4 Full Functionality Description

5 Video Signal Processing

6 Terminology

7 Addendum

Appendix A - Software License

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Barco RHDM-2301

Summary of Contents for Barco RHDM-2301
