- Page 2 PREFACE Thanks for purchasing a MF150QT-21. We sincerely hope you will be another happy MotoFino customer. To enjoy safe and pleasurable driving, please familiarize yourself with the manual before driving. Your personal safety depends not only on your vigilance and operation skills, but also relates to whether you are familiar with the mechanical capabilities of the scooter.
-
Page 3: Table Of Contents
Catalog I. Notice items for safely driving The rules for riding safely ………………………1 Riding operation ………………………………15 Load ………………………………………………2 Brake operation ……………………………..…15 VARIOUS PARTS NAMES AND INSTRUCTIONS Turning off the engine …………………………16 VARIOUS PARTS NAMES …………………….3 Stop operation …………………………………16 Instrument and indicator ………………………5 MAINTENANCE AND SERVICE... -
Page 4: Load
7. When driving, keep both hands on the handlebars and place feet on the footrest. Payload a) WARNING Only put light goods in luggage box or other compartments. The maximum weight to conform to the following table 1: Table: 1 Luggage Box Weight (Lbs.) 10 lbs. - Page 5 Fig.2 Rear brake grip Seat Lock Carrier rack Fuel Tank Air filter Footrest Kick-starter Side stand BROKEN LINE （ … … ） I NDICATES THE HIDEN PARTS - 4 - Speedometer and indicator light (Fig 3) ⑴ S peedometer Fig.3 ⑵...
-
Page 6: Emergency Cut-Off Switch
gas. Fig.5 Fuel Gage (Fig.5) Fuel gauge (4) indicates the approximate remainder of fuel. When the pointer points to (F), it indicates full fuel volume 1.5 Gal. When the pointer gets close to the red section, it indicates that the remainder volume is 0.3 Gal (about enough to go 10 miles or less). -
Page 7: Seat Lock
Seat Lock (Fig.10) Put the key into the seat lock and turn clock-wise to open. Press down the seat until it makes a clicking sound, then pull the back of seat to confirm it has been locked and remove the key. Fig.10 Glove box (Fig.11) 。... - Page 8 Check the oil level of the engine (Fig 11,Fig 12) Use the center stand to support the vehicle on smooth level ground, unscrew the dipstick from engine block (1) clean the oil dipstick with a clean cloth, then, reinsert the dipstick back into the engine block ( do not screw it in) remove and check the oil level.
- Page 9 Tires Check the tire pressure regularly and adjust as needed. · · · · Check while the tire are cool. · · · · Inspect to see if there is any metal, trash, or gravel in the groove of the tires. ·...
-
Page 10: Riding Operation
Riding Scooter WARNING: Wear trousers to avoid touching the exhaust pipe and getting burned. Always wear a helmet. All riding apparel must be worn according to all requirements of the traffic laws. Take a safety riding course. NOTICE: Control the speed and load during the first 500 miles of break in period. Load should be within 350lbs(including driver). -
Page 11: Stop Operation
Notice: Don’t modify your scooter. Use good quality spare parts if replacement parts are needed. Use of bad quality .—Motofino OEM Parts 706 733 1355 spare parts could compromise the safety of motorcycle Warning: Turn off engine when doing maintenance or making repairs. Always place scooter on center stand on level ground. -
Page 12: Spark Plug
Maintenance table (do all at set up and at 150 miles) I: check and adjust when necessary C: clean R: change Cycle （ ） speedometer x 500 miles Item page Every month Fuel pipe lin ﹡ peration ﹡ Throttle Air filter Note1 C/500 miles, if need: R ﹡... - Page 13 2. If the bike is used often perform this check more often. 3. Change seasonally. Simple trouble shooting Trouble primary reason Solution phenomenon Spark plug wear Change/check ENGINE Ignition coil wire Change/check Spark plug CAN NOT Change/check no spark START Blown fuse Change/check Emergency switch on...
- Page 14 Change battery Lack of Electric power Adjust Turning radius too wide Riding Keep tires inflated to correct pressure Lack of tire pressure unsteady Replace or adjust shocks Front and rear shock HOW TO CLEAN THE AIR FLITER （ （ （ （ F ig21 ）...
- Page 15 The carburetor adjusted perfectly from the factory, if the carburetor comes out of adjustment; have it adjusted by a professional. Warm up engine very well before starting. Idle adjust screw (1) turn to right to speed up turn to left to slow down. After adjusting the idle, adjust throttle handle cable to free path for 2-4mm, use adjustor (2) to adjust, screw down nut, then tighten set nut (3).
-
Page 16: Fuse Replacement
Change gear oil （ （ （ （ F ig26 ） ） ） ） Suggestion engine oil No: SAE 80W/90 Oil Capable Resolving capacity ： . 10 quart Changing capacity ： . 10 Quart Park the bikes with the main stand Take out the gearbox drain bolt (2), and the refill bolt (1). -
Page 17: Vehicle
Vehicle Storage Storage For a motorcycle not to be used for a long period of time, for example, in winter or fall, some steps should be taken to prevent malfunction of and damage to components, which might be caused by long storage. Maintenance must be preformed before the long storage, for fear that it might be forgotten when vehicle is put back into use after storage. - Page 18 Wrench bar 18.5*17 wrench Program5 Main Specifications Item Item Parameter Specifications Front Tire 100/80-16 × × H (mm)m 2101 × 6 84 × 1 168 110/80-16 1418 Rear Tire Wheel Base Pressure Of Front Tire Ground Clearance 34PSI Pressure Of Rear Tire 36PSI Dry Weight Transmission...
-
Page 19: Wiring Harness
整 流 调 压 器 磁 电 机 左 综 合 开 关 总 成 变 光 开 关 喇 叭 按 钮 转 向 开 关 蓄 电 池 起 动 电 机 Motofino USA, Inc. - 33 -... -
Page 20: Limited Warranty
(30) days from the date of purchase for the component parts (except as noted below). Motofino, if notified of a defect in material or workmanship during the period of the warranty, will repair or replace, at its option, the defective part at no charge, other than the reasonable charges for labor and shipping, if necessary to perform a warranty repair. - Page 21 Motofino makes no other warranty of any kind, express or implied. All warranties of merchantability and fitness for a particular purpose which exceed the obligations and time limitations specified in the warranty above are hereby disclaimed by Motofino and excluded from this warranty.
- Page 22 I UNDERSTAND THAT ALTHOUGH THIS VEHICLE HAS BEEN INSPECTED FOR SAFETY AND PROPER OPERATION, IT IS MY RESPONSIBILITY TO PERFORM THESE CHECKS EACH TIME BEFORE OPERATION BY OTHERS OR MYSELF. CUSTOMER SIGNATURE: ___________________PRINT: ________________DATE: ______________ PLEASE RETURN THIS WITH YOUR WARRANTY CARD WWW.MOTOFINO.COM - 39 -...
- Page 23 - 40 -...
