Antec UCC 13#: 0761345-77099-6 Specification Sheet

C O O L I N G F A N S
Affordable and Effective CPU Cooling
The Performance CPU Cooler continues the tradition set by Antec CPU coolers of
offering affordable, yet effective cooling for today's modern processors.
CPU Cooler with
AMD bracket
UCC 13#: 0761345-77099-6
www.antec.com
1-800-22ANTEC (US) /+31 (0) 10 462-2060 (EU)
PERFORMANCE
C P U

Special Features:

• Lightweight copper heatpipe and aluminum fin
hybrid design
• Ball bearing fan for extended life
• Performance is compatible with:
– Intel® socket 478 Celeron®, Celeron® D, Celeron® M,
– AMD socket 754, 939 & 940 Sempron™, Turion™,
CPU Cooler with
Intel® bracket
COOLER
Pentium® & Pentium® M
Opteron™, Athlon™64 & 64FX
Model
Overall Dimensions
AMD:
Intel®:
Heatsink Dimensions
Net Weight
AMD:
Intel®:
Thermal Resistance
Fan Size:
Speed
Air Flow
Acoustic Noise
Static Pressure
Voltage & Current
Performance
100 x 80 x 74 mm
72.5 x 87.5 x 74 mm
45 x 80 x 74 mm
297 ± 5g
291 ± 5g
0.26 C/W
0
70 x 70 x 15 mm
3800 RPM
30 CFM
34.9 dBA (max)
0.138 inch-H O
2
12V / 0.30A / 3.6W
