SoundStrip back panel
®
(Sample Illustration) Back panel connections
Item: Description:
9 OPTICAL IN jack (1) & (2)
10 AUX IN jack (L / R)
11 LINE IN jack
12 DC IN jack
13 HDMI ® IN jack (1) & (2)
14 HDMI ® OUT jack
SBX5065KU_IB_R6.indd 8
9
10
11
Functions:
Connects the optical audio input to another device, see
"Connecting to an Audio System" on page 14.
Connects other AV devices through the AUX IN jack, see
"Connect audio through an analog audio cable" section on
page 14.
Connects other AV devices through the LINE IN jack, see
"Connect audio through an analog audio cable" section on
page 15.
Connects to the power supply, see "Connecting to a switching
power supply (AC Adapter)" on page 15.
HDMI ® (High-Definition Multimedia Interface) cable
connects to devices that have an HDMI
Connecting to a compatible device section on page 13.
Audio Return Channel (ARC) enables the audio signal
of the TV to be sent to the SoundStrip
cable. See "Connecting to a TV using an HDMI
cable" on page 13.
14
13
15
®
® via the HDMI
output. See
®
® (ARC)
