WAGNER 770 Owner's Manual page 23

Problem D: The PRIME/SPRAY knob is set to SPRAY and there is flow through the material return tube
Cause
1. The PRIME/SPRAY valve is dirty or worn
Problem E: The spray gun leaks
Cause
1. Gun filter housing is loose
2. Internal parts of spray gun are worn or dirty
Problem F: The spray tip assembly leaks
Cause
1. The spray tip was assembled incorrectly
2. Gun seal is worn
Problem G: The spray gun will not spray
Cause
1. The spray tip plugged
2. The spray gun filter is clogged
3. The spray tip is in CLEAN position
4. PRIME/SPRAY knob not set on SPRAY
Problem H: The spray pattern is poor (tailing)
Cause
1. The spray tip is plugged
2. The inlet filter is clogged
3. The spray gun filter is clogged
4. The spray tip is worn
5. The material is too thick
6. Pressure loss
* Special repair kits with instructions are available for these procedures. Refer to the Maintenance section of this manual for a list of the kits and their part numbers
** Additional parts are available for this procedure. Refer to the Accessories (page 74) section of this manual for a list of the parts and their part numbers
Daily Maintenance
The only daily maintenance necessary is thorough cleaning
Follow the cleaning procedures in this manual
Extended Maintenance
Some pump parts eventually wear out from use and must be
replaced. The following is a list of available repair kits. Pump
performance is the only reliable indicator of when to replace wear
parts. Refer to the Troubleshooting section for more information
on when to use these kits
English
Solution
Take sprayer to Wagner Authorized Service Center
Solution
Tighten handle
Take sprayer to Wagner Authorized Service Center
Solution
Check tip assembly and assemble properly see page 20, steps 8-9
Replace the seal*
Solution
Refer to Clear the Spray Tip see page 13
Refer to Clean the Spray Gun Filter see page 15. Keep extra filters on hand
Rotate spray tip to SPRAY position see page 13, step 9
Turn PRIME/SPRAY knob to SPRAY see page 9 Getting Material to Flow
Solution
Refer to Clear the Spray Tip see page 13
Refer to Clean the Inlet Filter see page 14
Refer to Clean the Spray Gun Filter see page 15. Keep extra filters on hand
Replace the spray tip
Thin material using appropriate thinning solution
Refer to Causes and Solutions for Problem C
Troubleshooting • Fixing Spraying Problems
Kit Part # Description
0515221 Inlet valve kit
0515237 Outlet valve kit
0501014 Saddle seat/seal kit
Troubleshooting
23
